Automatic Transmission Shift Interlock Systems: Removal & Installation Honda Prelude V

Automatic Trans 3 illustrations ~543 words

REMOVAL & INSTALLATION

CAUTIONVehicles are equipped with a Supplemental Restraint System (SRS). When servicing vehicle, use care not to cause accidental air bag deployment. All SRS electrical connections and wiring harness are covered with Yellow insulation. Related components are located in steering column, center console, instrument panel and lower panel on instrument panel. DO NOT use electrical test equipment on these circuits. It may be necessary to deactivate SRS before servicing components. See AIR BAG DEACTIVATION PROCEDURES article in GENERAL INFORMATION.

Note. Honda Civic shift lock solenoid removal and installation procedures are not available from manufacturer.

  1. Remove center console. Disconnect harness connector at shift lock solenoid. Remove solenoid pin from shift lock solenoid. Remove mounting nuts and shift lock solenoid.
  2. To install, apply silicone grease to shift lock solenoid mating surfaces with shift lock extension. Install shift lock solenoid with NEW nuts snugly installed. Install pin, collar and harness connector.
  3. Turn ignition on. Depress brake pedal with accelerator pedal released. With shift lock solenoid energized (ON position), ensure clearance between top of shift lock lever and lock pin groove is.145-.185" (3.7-4.7 mm). (Scheme 58) Tighten mounting nuts to specifications. See «TORQUE SPECIFICATIONS»(ref-425-S04078972682000030800000).
  4. Turn ignition off and release brake pedal. Ensure lock pin is blocked by shift lock lever. (Scheme 58) Check solenoid operation several times to ensure proper operation.

Scheme 58

Scheme 58
Scheme 58
  1. Remove center console. Disconnect harness connector at shift lock solenoid. Remove gear shift knob. Remove lock nuts and through bolts, then remove A/T gear position panel. Remove mounting bolts and shift lock solenoid.
  2. To install, reverse removal procedure. Ensure there is clearance between stop pin and base bracket when solenoid is on and off. (Scheme 59) Tighten A/T gear position panel through bolt nut. Tighten shift lock solenoid mounting bolts to specifications. See «TORQUE SPECIFICATIONS»(ref-425-S04078972682000030800000).

Scheme 59

Scheme 59
Scheme 59
  1. Remove center console. Disconnect harness connector at shift lock solenoid. Remove solenoid pin from shift lock solenoid. Remove mounting nuts and shift lock solenoid.
  2. To install, on Acura Integra, apply silicone grease to shift lock solenoid mating surfaces with shift lock extension. On all models, install shift lock solenoid with NEW nuts snugly installed. Install pin, collar and harness connector.
  3. Turn ignition on. With shift lock solenoid energized (ON position), ensure clearance between top rear of shift lock lever and lock pin groove is.078-.118" (2.0-3.0 mm). (Scheme 60) Tighten mounting nuts to specifications. See «TORQUE SPECIFICATIONS»(ref-425-S04078972682000030800000).
  4. Turn ignition off. Ensure lock pin is blocked by shift lock lever. (Scheme 60) Check solenoid operation several times to ensure proper operation.

Scheme 60

Scheme 60
Scheme 60
  1. Turn ignition off. Remove instrument panel lower cover. Remove upper and lower steering column cover.
  2. Remove flange nuts and bolts securing steering column. Lower steering column. Disconnect shift lock solenoid and parking pin switch harness connectors. Remove shift lever assembly. Remove shift lock solenoid mounting screws. Remove shift lock solenoid.
  3. To install, align shift lock solenoid plunger joint with tip of shift lock extension. Install and tighten solenoid mounting screws to specifications. See «TORQUE SPECIFICATIONS»(ref-425-S04078972682000030800000) . Check shift lever operation and shift lock operation.
  1. Turn ignition off. Remove lower steering column cover. Disconnect shift lock solenoid harness connector. Remove spring clip securing shift lock solenoid. Remove shift lock solenoid.
  2. To install, reverse removal procedure. Align shift lock solenoid plunger joint with tip of shift lock extension. Check that shift lock stop does not protrude when shift lock solenoid is on. Ensure shift lock protrudes more than 0.30" (7.5 mm) when solenoid is off.
  1. Remove center console. Disconnect shift lock solenoid harness connector. Using a screwdriver, pry shift lock solenoid clamp, then remove shift lock solenoid.
  2. To install, align shift lock solenoid joint with tip of shift lock stop. Secure shift lock solenoid with clamp.
