DTC B2625: Left Front Sensor Failure Honda Pilot II

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. Clear the DTCs with the HDS.
2. Turn the ignition switch to LOCK (0), and than back to ON (II).
3. Check for DTCs with the HDS. Is DTC B2625 indicated? YES - Go to step 4 . NO - Intermittent failure, the system is OK at this time.
4. Turn the ignition switch to LOCK (0).
5. Swap the left front corner parking sensor and the right front corner parking sensor.
6. Turn the ignition switch to ON (II).
7. Check for DTCs with the HDS. Is DTC B2625 indicated? YES - Go to step 8 . NO - Replace the left front corner parking sensor (see «PARKING AND BACK-UP SENSOR SWITCH TEST/REPLACEMENT»(ref-333635-S17908158862009072100000) ).
8. Turn the ignition switch to LOCK (0).
9. Disconnect the 6P connector from the left front corner parking sensor.
10. Disconnect the 16P connector from the parking and back-up sensor control unit.
