VTM-4 Control Unit Replacement
Note. The VTM-4 control unit must be initialized after replacement, other wise the VTM-4 system will not function.
Scheme 44
- Remove the left side trim panel.
- Remove the left side trim panel lid.
- Remove the three bolts (A) from the VTM-4 control unit (B).
- Disconnect the VTM-4 control unit connectors (C).
- Install the VTM-4 control unit in the reverse order of removal.
Scheme 45
- Remove the driver's dashboard lower cover (see «INSTRUMENT PANEL REMOVAL/INSTALLATION»(ref-333587-S31415692192009072100000) ).
- Remove the harness clip (A), then remove the auxiliary under-dash relay holder (B).
- Remove the VTM-4 relay (C) from the auxiliary under-dash relay holder.
- Install the VTM-4 relay in the reverse order of removal.
Scheme 46
Scheme 47
- Remove the cargo floor box. (see «TRIM REMOVAL/INSTALLATION - CARGO AREA»(ref-333585-S30179242372009072100000) )
- Remove the rear right side trim panel, (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(ref-333585-S17052326012009072100000) )
- Remove the breather hose clips (A), then disconnect the breather hoses (B).
- Remove the rear differential breather box clips (C) and the rear differential breather box (D).
- Install the breather box and the hose in the reverse order of removal.
