DTC P2647: VTEC System Stuck ON Honda Pilot I рестайлинг

Special Tools Required

1. Pressure gauge adapter 07NAJ-P07010A
2. A/T low pressure gauge w/panel 07406-0070300
3. A/T pressure hose 07406-0020201
4. A/T pressure hose, 2,210 mm 07MAJ-PY4011A
5. A/T pressure adapter 07MAJ-PY40120
6. Oil pressure hose 07ZAJ-S5A0200

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 93

1. Check the engine oil level. Is the engine oil level OK? YES - Go to step 2. NO - Adjust the engine oil to the proper level, then go to step 11 .
2. Turn the ignition switch ON (II).
3. Clear the DTC with the HDS.
4. Do the VTEC TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the EOP sensor, the rocker arm oil control solenoid (VTEC solenoid valve), and the PCM. NO - Go to step 5.
5. Turn the ignition switch OFF.
6. Remove the EOP sensor (A), install the special tools as shown, then install the EOP sensor in the oil pressure gauge adapter (B). NOTE: Install the sensor in the reverse order of removal with new O-ring.
7. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle for 2 minutes.
8. Check the oil pressure. Does the oil pressure increase to 392 kPa (4.0 kgf/cm 2 , 56.9 psi)? YES - Replace the EOP sensor (see «EOP SENSOR REMOVAL/INSTALLATION»(ref-243331-S18823069572006082300000) ), then go to step 9. NO - Replace the rocker arm oil control solenoid (VTEC solenoid valve) (see «ROCKER ARM OIL CONTROL SOLENOID (VTEC SOLENOID VALVE) FILTER REPLACEMENT»(ref-243331-S18407580522006082300000) ), then go to step 9.
9. Turn the ignition switch OFF.
10. Reconnect all connectors.
11. Turn the ignition switch ON (II).
12. Reset the PCM with the HDS.
13. Do the PCM Idle Learn Procedure (see «PCM IDLE LEARN PROCEDURE»(ref-243313-S13405059332006082300000) ).
14. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle for 2 minutes.
15. Check for Temporary DTCs or DTCs with the HDS. If DTC P2647 is indicated? YES - Check for poor connections or loose terminals at the rocker arm oil control solenoid (VTEC solenoid valve), the EOP sensor, and the PCM, then go to step 1 . NO - Go to step 16.
16. Monitor the OBD STATUS for DTC P2647 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated «DTC'S TROUBLESHOOTING»(ref-243331-S34035497822006082300000) . NO - If the screen indicates FAILED, check for poor connections or loose terminals at the rocker arm oil control solenoid (VTEC solenoid valve), the sensor, and the PCM, then go to step 1 . If the screen indicates NOT COMPLETED, keep idling until a result comes on..
