DTC P0522: EOP Sensor Circuit Low Voltage Honda Pilot I рестайлинг

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 85

Scheme 86

Scheme 87

1. Turn the ignition switch ON (II).
2. Check the OIL PRESSURE SENSOR in the DATA LIST with the HDS. Is there about 0.18 V or less? YES - Go to step 3. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the oil pressure sensor and the PCM.
3. Turn the ignition switch OFF.
4. Disconnect the EOP sensor 3P connector.
5. Turn the ignition switch ON (II).
6. Check the OIL PRESSURE SENSOR in the DATA LIST with the HDS. Is there about 0.18 V or less? YES - Go to step 8 . NO - Go to step 7.
7. Measure voltage between EOP sensor 3P connector terminals No. 1 and No. 3. Is there about 5 V? YES - Go to step 16 . NO - Go to step 12 .
8. Turn the ignition switch OFF.
9. Jump the SCS line with the HDS.
10. Disconnect PCM connector C (44P).
11. Check for continuity between EOP sensor 3P connector terminal No. 2 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (C22) and the EOP sensor, then go to step 18 . NO - Go to step 25 .
12. Turn the ignition switch OFF.
13. Jump the SCS line with the HDS.
14. Disconnect PCM connector C (44P).
15. Check for continuity between the PCM connector terminal C13 and EOP sensor 3P connector terminal No. 1. Is there continuity? YES - Go to step 25 . NO - Repair open in the wire between the PCM (C13) and the EOP sensor, then go to step 18 .
16. Turn the ignition switch OFF.
17. Replace the EOP sensor (see «EOP SENSOR REMOVAL/INSTALLATION»(ref-243331-S18823069572006082300000) ).
18. Reconnect all connectors.
19. Turn the ignition switch ON (II).
20. Reset the PCM with the HDS.
21. Do the PCM Idle Learn Procedure (see «PCM IDLE LEARN PROCEDURE»(ref-243313-S13405059332006082300000) ).
22. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0522 is indicated, check for poor connections or loose terminals at the EOP sensor and the PCM, then go to step 1 . NO - Go to step 23.
23. Monitor the OBD STATUS for DTC P0522 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated «DTC'S TROUBLESHOOTING»(ref-243331-S34035497822006082300000) . NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EOP sensor and the PCM, then go to step 1 . If the screen indicates NOT COMPLETED, keep idling until a result comes on.
24. Reconnect all connectors.
25. Update the PCM if it does not have the latest software (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-243311-S19790429062006082300000) ), or substitute a known-good PCM (see «HOW TO SUBSTITUTE THE PCM»(ref-243311-S24543735662006082300000) ).
26. Start the engine, and let it idle.
27. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0522 is indicated, check for poor connections or loose terminals at the EOP sensor and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated «DTC'S TROUBLESHOOTING»(ref-243331-S34035497822006082300000) . NO - Go to step 28.
28. Monitor the OBD STATUS for DTC P0522 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated «DTC'S TROUBLESHOOTING»(ref-243331-S34035497822006082300000) . NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EOP sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «HOW TO SUBSTITUTE THE PCM»(ref-243311-S24543735662006082300000) ), then go to step 26 . If the PCM was substituted, go to step 1 . If the screen indicates NOT COMPLETED, keep idling until a result comes on.
