Cooling System: Other Honda Pilot I рестайлинг

Belt Routing

For belt routing illustration, see COMPONENT LOCATION INDEX in CHARGING SYSTEM article.

Scheme 29

Scheme 30

1. Remove the radiator cap (A), wet its seal with engine coolant, then install it on a commercially available pressure tester (B).
2. Apply a pressure of 93-123 kPa (0.95-1.25 kgf/cm 2 , 14-18 psi).
3. Check for a drop in pressure.
4. If the pressure drops, replace the cap.

Scheme 31

1. Wait until the engine is cool, then carefully remove the radiator cap, and fill the radiator with engine coolant to the top of the filler neck.
2. Attach a commercially available pressure tester (A) to the radiator, and apply a pressure of 93-123 kPa (0.95-1.25 kgf/cm 2 ,14-18 psi).
3. Inspect for engine coolant leaks and a drop in pressure.
4. Remove the tester, then reinstall the radiator cap.

Scheme 32

1. Disconnect the 2P connectors from the radiator fan motor (A) and condenser fan motor (B).
2. Test each motor by connecting battery power to the B terminal and ground to the A terminal.
3. If either motor fails to run or does not run smoothly, replace it (see «RADIATOR AND FAN REPLACEMENT»(ref-243298-S00551056952006082300000) ).
