Design Specifications
| Item | Measurement | Qualification | Specification |
|---|---|---|---|
| DIMENSIONS | Overall length | 4,775 mm (188.0 in.) | |
| Overall width | 1,963 mm (77,3 in.) | ||
| Overall height | 1,793 mm (70.6 in.) | ||
| Wheelbase | 2,700 mm (106.3 in.) | ||
| Track | Front | 1,685 mm (66.3 in.) | |
| Rear | 1,690 mm (66.5 in.) | ||
| Ground clearance | 203 mm (8.0 in.) | ||
| Seating capacity | Eight | ||
| WEIGHT (U.S.A.) | Gross Vehicle Weight Rating (GVWR) | 5,950 lbs | |
| WEIGHT (CANADA) | Gross Vehicle Weight Rating (GVWR) | 2,700 kg | |
| ENGINE | Type | Water-cooled, 4-stroke SOHC VTEC V6 gasoline engine | |
| Cylinder arrangement | 60° V6-cylinder, transverse | ||
| Bore and stroke | 89.0 x 93.0 mm (3.50 x 3.66 in.) | ||
| Displacement | 3,471 cm 3 (m l ) (211.8 cu in.) | ||
| Compression ratio | 10.0 | ||
| Valve train | Belt driven, SOHC VTEC 4 valves per cylinder | ||
| Lubrication system | Forced, wet sump, with trochoid pump | ||
| Oil pump displacement | At 6,000 rpm | 58.4 l (61.7 US qt)/minute | |
| Water pump displacement | At 6,000 rpm | 172 l (182 US qt)/minute | |
| Fuel required | UNLEADED gasoline with 86 Pump Octane Number or higher | ||
| STARTER | Type | Gear reduction | |
| Normal output | 1.6 kW | ||
| Normal voltage | 12 V | ||
| Hour rating | 30 seconds | ||
| Direction of rotation | Clockwise as viewed from gear end | ||
| AUTOMATIC TRANSMISSION | Type | Electronically controlled automatic, 5-speed forward, 1 reverse | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 2.563 | |
| 2nd | 1.552 | ||
| 3rd | 1.021 | ||
| 4th | 0.727 | ||
| 5th | 0.520 | ||
| Reverse | 1.846 | ||
| Final reduction | Type | Single helical gear | |
| Gear ratio | 4.428 | ||
| STEERING | Type | Power-assisted rack and pinion | |
| Gear ratio | 42.3 | ||
| Overall ratio | 16.9 | ||
| Turns, lock-to-lock | 3.22 | ||
| Steering wheel diameter | 386 mm (15.2 in.) | ||
| SUSPENSION | Type | Front | Strut with "L" arm |
| Rear | Multilink with trailing arm | ||
| Shock absorber | Front | NWS twin tube gas | |
| Rear | SPV twin tube gas | ||
| WHEEL ALIGNMENT | Camber | Front | 0°30' |
| Rear | 0°30' | ||
| Caster | Front | 1°53' | |
| Total toe | Front | 0 mm (0 in.) | |
| Rear | 0 mm (0 in.) | ||
| SAI at camber (kingpin axis) | 11°54' | ||
| BRAKES | Type of service brake | Front | Power-assisted self-adjusting ventilated disc |
| Rear | Power-assisted self-adjusting solid disk | ||
| Type of parking brake | Foot type mechanical actuating, rear wheels | ||
| Pad friction surface area (swept area) | Front | 364.1 cm 2 (56.44 sq in.) | |
| Rear | 325.1 cm 2 (50.39 sq in.) | ||
| TIRES | Size of front and rear tires | P235/70 R16 104S | |
| Size of spare tire | T155/90 D16 110M | ||
| WHEEL | Size | Front and rear wheels | 16 x 6.5JJ |
| Spare tire wheel | 16 x 4T | ||
| AIR CONDITIONING | Cooling capacity | Front | 4,375 Kcal/h (17,300 BTU/h) |
| Rear | 3,119 Kcal/h (12,400 BTU/h) | ||
| Compressor | Type/Manufacturer | Swash plate/DENSO | |
| Number of cylinders | 10 | ||
| Capacity | 210 m l /rev. (12.81 cu in./rev.) | ||
| Maximum speed | 7,600 rpm | ||
| Lubricant capacity | 180 m l (6 fl oz) | ||
| Lubricant type | ND-OIL 8 | ||
| Condenser | Type | Corrugated fin | |
| Evaporator | Type | Corrugated fin | |
| Blower | Type | Sirocco fan | |
| Motor input (Front) | 228 W/12 V | ||
| Motor input (Rear) | 125 W/12 V | ||
| Speed control (Front: Auto A/C) | Infinite variable | ||
| Speed control (Front: Manual A/C) | 7-speed | ||
| Speed control (Rear: Auto A/C) | Infinite variable | ||
| Speed control (Rear: Manual A/C) | 3-speed | ||
| Maximum capacity (Front) | 490 m 3 /h (17,300 cu ft/h) | ||
| Maximum capacity (Rear) | 310 m 3 /h (11,000 cu ft/h) | ||
| Temperature control | Air-mix type | ||
| Compressor clutch | Type | Dry, single plate, Poly-V belt drive | |
| Electrical power consumption at 68°F (20°C) | 40 W maximum at 12 V | ||
| Refrigerant | Type | HFC-134a (R-134a) | |
| Quantity (Dual) | 750' 0 50 g (26' 0 18 oz) | ||
| ELECTRICAL RATINGS | Battery | 12 V - 20 AH/5 hours | |
| Starter | 12 V - 1.6 kW | ||
| Alternator | 12 V - 130A | ||
| Fuses | Under-hood fuse/relay box | 120A, 50A, 40A, 30A, 20A, 15A, 7.5A | |
| Driver's under-dash fuse/ relay box | 30A, 15A, 10A, 7.5A | ||
| Auxiliary fuse box | 40A, 20A | ||
| Passenger's under-dash fuse/relay box | 20A, 15A, 10A, 7.5A | ||
| Light bulbs | Headlight high/low beam | 12 V - 60/55 W (HB2) | |
| Front turn signal/hazard/ parking light | 12 V - 27/8 W (1157 NA) | ||
| Front side marker lights | 12 V - 5 W (168) | ||
| Rear turn signal/hazard/tail lights | 12 V - 21/5 W (7443) | ||
| Rear side marker lights | 12 V - 5 W (168) | ||
| Brake/Taillights | 12 V - 21/5 W (7443) | ||
| High mount brake light | 12 V - 18 W (921) | ||
| Back-up lights | 12 V - 18 W (921) | ||
| License plate light | 12 V - 5 W (168) | ||
| Tailgate light | 12 V - 5 W | ||
| Vanity mirror lights | 12 V - 1.1 W | ||
| Front individual map lights | 12 V - 6.2 W | ||
| Rear individual map lights | 12 V - 12.4 W | ||
| Courtesy light | 12 V - 3.8 W | ||
| Gauge lights | 12 V - LED Non-replaceable | ||
| Indicators | 12 V - LED Non-replaceable | ||
| Heater control panel lights LX | 14 V - 5.9 W | ||
| Climate control unit lights EX | 14 V - 3.4 W, 10 V - 1.8 W | ||
| Rear heater control panel lights | 14 V - 1.4 W | ||
| Glove box light | 12 V - 3.4 W | ||
| Console box light | 12 V - 1.4 W |
Design Specifications Table
