Engine Block: Diagnosis Honda Odyssey IV

Crankshaft Inspection

Out-of-Round and Taper

Scheme 695

Scheme 696

1. Remove the crankshaft from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-294717-S10761147132008081300000) ).
2. '08-09 models J35A7 engine: Remove the crankshaft position (CKP) pulse plate from the crankshaft (see «CKP Pulse Plate Replacement»(ref-294717-S30928522092008081300000) )
3. Clean the crankshaft oil passages with pipe cleaners or a suitable brush.
4. Check the keyway and threads.
5. Measure the out-of-round at the middle of each rod and the main journal in two places. The difference between measurements on each journal must not be more than the service limit. Journal Out-of-Round Standard (New): 0.005 mm (0.0002 in.) max. Service Limit: 0.010 mm (0.0004 in.)
6. Measure the taper at the edges of each rod and main journal. The difference between measurements on each journal must not be more than the service limit. Journal Taper Standard (New): 0.005 mm (0.0002 in.) max. Service Limit: 0.010 mm (0.0004 in.) Straightness
7. Place the engine block on a flat surface, crankshaft side up.
8. Lower the crankshaft into the engine block.
9. Measure the runout on allot the main journals. Rotate the crankshaft two complete revolutions. The difference between measurements on each journal must not be more than the service limit. Crankshaft Total Runout Standard (New): 0.025 mm (0.0010 in.) max. Service Limit: 0.030 mm (0.0012 in.)

Scheme 697

Scheme 698

Scheme 699

Scheme 700

1. Remove the pistons from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-294717-S10761147132008081300000) ).
2. Check the pistons for distortion or cracks.
3. Measure the piston diameter at a point 16.0 mm (0.63 in.) from the bottom of the skirt. Piston Skirt Diameter Standard (New): 88.975-88.985 mm (3.5029-3.5033 in.) Service Limit: 88.965 mm (3.5026 in.) Oversize Piston Skirt Diameter 0.25: 89.225-89.235 mm (3.5128-3.5132 in.)
4. Measure the wear and taper in direction X and Y at three levels in each cylinder as shown. If measurements in any cylinder are beyond the oversize bore service limit, replace the engine block. If the engine block has to be rebored, refer to step 7 after reboring. Cylinder Bore Size Standard (New): 89.000-89.015 mm (3.5039-3.5045 in.) Service Limit: 89.065 mm (3.5065 in.) Oversize 0.25: 89.250-89.265 mm (3.5138-3.5144 in.) Reboring Limit: 0.25 mm (0.01 in.) Bore Taper Limit: (Difference between first and third measurement) 0.05 mm (0.002 in.)
5. Hone any scored or scratched cylinder bores, (see «CYLINDER BORE HONING»(ref-294717-S19014145402008081300000) ).
6. Check the top of the engine block for warpage. Measure along the edges and across the center as shown. Engine Block Warpage Standard (New): 0.07 mm (0.003 in.) max. Service Limit: 0.10 mm (0.004 in.)
7. Calculate the difference between cylinder bore diameter and piston diameter. If the clearance is near or exceeds the service limit, inspect the piston and cylinder bore for excessive wear. Piston-to-Cylinder Bore Clearance Standard (New): 0.015-0.040 mm (0.0006-0.0016 in.) Service Limit: 0.08 mm (0.003 in.)

Scheme 701

1. Measure the cylinder bores (see step 4 on «BLOCK AND PISTON INSPECTION»(ref-294717-S30491181212008081300000) ). If the engine block is to be reused, hone the cylinders and remeasure the bores. Only scored or scratched cylinder bores must be honed.
2. J35A7 engine: Remove the oil jets (see «J35A7 ENGINE»(ref-294681-S15658100972008081300000) ).
3. Hone the cylinder bores with honing oil and a fine (400 grit) stone in a 60 degree Crosshatch pattern. NOTE: Use only a rigid hone with 400 grit or finer stone, such as Sunnen, Ammco, or equivalent. Do not use stones that are worn or broken.
4. When honing is complete, thoroughly clean the engine block of all metal particles. Wash the cylinder bores with hot soapy water, then dry and oil them immediately to prevent rusting. NOTE: Never use solvent, it will only redistribute the grit on the cylinder walls.
5. If scoring or scratches are still present in the cylinder bores after honing to the service limit, rebore the engine block. Some light vertical scoring and scratching is acceptable if it is not deep enough to catch your fingernail and does not run the full length of the bore.
6. J35A7 engine: Install the oil jets (see «J35A7 ENGINE»(ref-294681-S15658100972008081300000) ).

Scheme 702

Scheme 703

Scheme 704

1. Remove the pistons from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-294717-S10761147132008081300000) ).
2. Apply new engine oil to the piston pin snap rings (A) and turn them in the ring grooves until the end gaps are lined up with the cutouts in the piston pin bores (B). NOTE: Take care not to damage the ring grooves.
3. Remove snap rings (A) from both sides of each piston. Start at the cutout in the piston pin bore. Remove the snap rings carefully so they do not go flying or get lost. Wear eye protection.
4. Separately heat each piston and connecting rod assembly to about 158°F (70°C), then remove the piston pin.

Inspection

Note. Inspect the piston, the piston pin, and the connecting rod when they are at room temperature.

Scheme 705

Scheme 706

Scheme 707

Scheme 708

1. Measure the diameter of the piston pin. Piston Pin Diameter Standard (New): 21.962-21.965 mm (0.8646-0.8648 in.) Service Limit: 21.954 mm (0.8643 in.)
2. Zero the dial indicator to the piston pin diameter.
3. Check the difference between the piston pin diameter and the piston pin hole diameter on the piston. Piston Pin-to-Piston Clearance Standard (New): -0.0050 to +0.0010 mm (-0.00020 to +0.00004 in.) Service Limit: 0.004 mm (0.0002 in.)
4. Measure the piston pin-to-connecting rod clearance. Piston Pin-to-Connecting Rod Clearance Standard (New): 0.005-0.014 mm (0.0002-0.0006 in.) Service Limit: 0.019 mm (0.0007 in.)

Scheme 709

Scheme 710

Scheme 711

1. Install a piston pin snap ring (A) only on one side.
2. Coat the piston pin bore in the piston, the bore in the connecting rod, and the piston pin with new engine oil.
3. Heat the piston to about 158°F (70°C).
4. Assemble the piston (A) and the connecting rod (B) with the embossed marks (C) on the same side. Install the piston pin (D). NOTE: Apply new engine oil to the piston pin.
5. Install the remaining snap ring.
6. Reassemble the other pistons the same way.

Scheme 712

Scheme 713

Scheme 714

Scheme 715

Scheme 716

Scheme 717

1. Remove the pistons from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-294717-S10761147132008081300000) ).
2. Using a ring expander (A), remove the old piston rings (B).
3. Clean all the ring grooves thoroughly with a squared-off broken ring, or a ring groove cleaner with a blade to fit the piston grooves. File down the blade, if necessary. The top ring and second ring grooves are 1.2 mm (0.05 in.) wide, and the oil ring groove is 2.8 mm (0.11 in.) wide. Do not use a wire brush to clean the ring grooves, or cut the ring grooves deeper with the cleaning tool. NOTE: If the piston is to be separated from the connecting rod, do not install new rings yet.
4. Using a piston, push a new ring (A) into the cylinder bore 15-20 mm (0.6-0.8 in.) from the bottom.
5. Measure the piston ring end-gap (B) with a feeler gauge: If the gap is too small, check to see if you have the proper rings for your engine. If the gap is too large, recheck the cylinder bore diameter against the wear limits (see step 4 on «BLOCK AND PISTON INSPECTION»(ref-294717-S30491181212008081300000) ). If the bore is over the service limit, the engine block must be rebored. Piston Ring End-Gap Top Ring: Standard (New): 0.20-0.35 mm (0.008-0.014 in.) Service Limit: 0.60 mm (0.024 in.) Second Ring: Standard (New): 0.40-0.55 mm (0.016-0.022 in.) Service Limit: 0.70 mm (0.028 in.) Oil Ring: Standard (New): 0.20-0.70 mm (0.008-0.028 in.) Service Limit: 0.80 mm (0.031 in.)
6. Install the rings as shown. The top ring (A) has a 1D mark and the second ring (B) has a 2C mark (J35A6, '07 model J35A7 engine) or 2X mark ('08-09 models J35A7 engine). The manufacturing marks (C) must be facing upward. Piston Ring Dimensions: J35A6, '07 model J35A7 engines Top Ring (Standard) A: 3.1 mm (0.12 in.) B: 1.2 mm (0.05 in.) Second Ring (Standard) A: 3.4 mm (0.13 in.) B: 1.2 mm (0.05 in.) '08-09 models J35A7 engine Top Ring (Standard) A: 3.1 mm (0.12 in.) B: 1.2 mm (0.05 in.) Second Ring (Standard) A: 3.6 mm (0.14 in.) B: 1.2 mm (0.05 in.)
7. After installing a new set of rings, measure the ring-to-groove clearance: Top Ring Clearance Standard (New): 0.055-0.080 mm (0.0022-0.0031 in.) Service Limit: 0.15 mm (0.006 in.) Second Ring Clearance Standard (New): 0.030-0.055 mm (0.0012-0.0022 in.) Service Limit: 0.13 mm (0.005 in.)
8. Rotate the rings in their grooves to make sure they do not bind.
9. Position the ring end gaps as shown
