Engine Block: Component Locations Honda Odyssey IV

Mechanical 21 illustrations ~947 words

Crankshaft Bore Code Location

Letters or bars have been stamped on the end of the engine block as a code for the size of each of the four main journal bores.

Use them, and the numbers stamped on the crankshaft (codes for main journal size), to choose the correct bearings. If the codes are indecipherable because of an accumulation of dirt and dust, do not scrub them with a wire brush or scraper. Clean them only with solvent or detergent.

Scheme 744

Scheme 744: Crankshaft Bore Code Location
Scheme 744: Crankshaft Bore Code Location

Scheme 745

Scheme 745
Scheme 745

Main Journal Code Locations (Numbers or Bars)

Scheme 746

Scheme 746
Scheme 746

Scheme 747

Scheme 747: Connecting Rod Bearing Clearance Inspection
Scheme 747: Connecting Rod Bearing Clearance Inspection
  1. Remove the connecting rod cap and the bearing half (see «CRANKSHAFT AND PISTON REMOVAL»(ref-294717-S10761147132008081300000) ).
  2. Clean the crankshaft rod journal and bearing half with a clean shop towel.
  3. Place a strip of plastigage across the rod journal.
  4. Reinstall the bearing half and the cap, and tighten the bolts. NOTE: Apply new engine oil to the bolt threads and flanges. Do not rotate the crankshaft during inspection. Tightening Torque: 20 N.m (2.0 kgf.m, 15 lbf.ft)+90°
  5. Remove the rod cap and the bearing half and measure the widest part of the plastigage. Connecting Rod Bearing-to-Journal Oil Clearance Standard (New): 0.020-0.044 mm (0.0008-0.0017 in.) Service Limit: 0.050 mm (0.0020 in.)
  6. If the plastigage measures too wide or too narrow, remove the upper half of the bearing, then install a new, complete bearing with the same color code, and recheck the clearance. Do not file, shim, or scrape the bearings or the caps to adjust clearance.
  7. If the plastigage shows the clearance is still incorrect, try the next larger or smaller bearing (the color listed above or below that one), and check clearance again. If the proper clearance cannot be obtained by using the appropriate larger or smaller bearings, replace the crankshaft and start over (see «CRANKSHAFT AND PISTON REMOVAL»(ref-294717-S10761147132008081300000) ).

Connecting Rod Journal Code Locations

Numbers or bars have been stamped on the side of each connecting rod as a code for the size of the big end. Use them, and the letters or bars stamped on the crank (codes for rod journal size), to choose the correct bearings. If the codes are indecipherable because of an accumulation of dirt and dust, do not scrub them with a wire brush or scraper. Clean them only with solvent or detergent.

Scheme 748

Scheme 748: Connecting Rod Journal Code Locations
Scheme 748: Connecting Rod Journal Code Locations

Scheme 749

Scheme 749
Scheme 749

Connecting Rod Journal Code Locations (Letters or Bars)

Scheme 750

Scheme 750
Scheme 750

Scheme 751

Scheme 751: Oil Pan Removal
Scheme 751: Oil Pan Removal

Scheme 752

Scheme 752
Scheme 752

Scheme 753

Scheme 753
Scheme 753

Scheme 754

Scheme 754
Scheme 754
  1. If the engine is already out of the vehicle, go to step 6 .
  2. Raise the vehicle on the lift.
  3. Drain the engine oil (see «ENGINE OIL REPLACEMENT»(ref-294681-S40314378162008081300000) ).
  4. Remove the splash shield (see step 34 on «ENGINE INSTALLATION»(ref-294701-S13954887432008081300000) ).
  5. Remove exhaust pipe A (see step 38 on «ENGINE INSTALLATION»(ref-294701-S13954887432008081300000) ).
  6. Remove the rear warm up three way catalytic converter (rear WU-TWC) bracket.
  7. '08-09 models J35A7 engine: Remove the crankshaft position (CKP) sensor cover (A) and the bolt (B), then disconnect the CKP sensor connector (C).
  8. Remove the torque converter cover (A) and the four bolts (B) securing the transmission.
  9. Remove the bolts securing the oil pan.
  10. Using a flat blade screwdriver, separate the oil pan from the engine block in the places shown.
  11. Remove the oil pan.

Scheme 755

Scheme 755: Crankshaft and Piston Removal
Scheme 755: Crankshaft and Piston Removal

Scheme 756

Scheme 756
Scheme 756

Scheme 757

Scheme 757
Scheme 757

Scheme 758

Scheme 758
Scheme 758

Scheme 759

Scheme 759
Scheme 759

Scheme 760

Scheme 760
Scheme 760

Scheme 761

Scheme 761
Scheme 761

Scheme 762

Scheme 762
Scheme 762

Scheme 763

Scheme 763
Scheme 763

Scheme 764

Scheme 764
Scheme 764
  1. Remove the engine/transmission (see «ENGINE REMOVAL»(ref-294701-S37258878062008081300000) ).
  2. Remove the transmission (see «TRANSMISSION REMOVAL»(ref-372405-S08042130282010092500000) ).
  3. Remove the drive plate (see «DRIVE PLATE REMOVAL AND INSTALLATION»(ref-372405-S22173913832010092500000) ).
  4. Remove the cylinder heads: J35A6 engine (see «CYLINDER HEAD REMOVAL»(ref-294693-S22121878322008081300000) ) '07 model J35A7 engine (see «CYLINDER HEAD REMOVAL»(ref-294693-S25769468732008081300000) ) '08-09 models J35A7 engine (see «CYLINDER HEAD REMOVAL»(ref-294693-S00800205632008081300000) )
  5. Remove the timing belt drive pulley from the crankshaft. J35A6 engine (see «TIMING BELT DRIVE PULLEY REPLACEMENT»(ref-294693-S09745184712008081300000) ) '07 model J35A7 engine (see «TIMING BELT DRIVE PULLEY REPLACEMENT»(ref-294693-S21341346872008081300000) ) '08-09 models J35A7 engine (see «TIMING BELT DRIVE PULLEY REPLACEMENT»(ref-294693-S03108176922008081300000) )
  6. Remove the oil pan (see «OIL PAN REMOVAL»(ref-294717-S30541185262008081300000) ).
  7. Remove the engine block end cover.
  8. J35A6 engine: Remove the rocker arm oil control solenoid/oil filter assembly.
  9. J35A7 engine: Remove the oil filter base/oil filter assembly.
  10. Remove the oil screen (A), the baffle plate (B), and the oil pump (C).
  11. If you can feel a ridge of metal or hard carbon around the top of any cylinder, remove it with a ridge reamer (A). Follow the reamer manufacturer's instructions. If the ridge is not removed, it may damage the piston as it's pushed out.
  12. Remove the connecting rod caps after setting the crank pin at bottom dead center (BDC) for each cylinder. Remove the piston/connecting rod assembly by pushing on the connecting rod. Take care not to damage the oil jets, the crank pin, or the cylinder with the connecting rod. CORRECT INCORRECT
  13. Remove the bearing from the cap. Keep all caps/ bearings in order.
  14. Remove the upper bearing halves from the connecting rods, and set them aside with their respective caps.
  15. After removing a piston/connecting rod assembly, reinstall the cap on the rod.
  16. To avoid confusion during reassembly, mark each piston/connecting rod assembly with its cylinder number.
  17. Loosen the bearing cap bolts and bearing cap side bolts in sequence 1/3 turn at a time; repeat the sequence until all bolts are loosened.
  18. Remove the bearing cap bolts (A) and the bearing cap side bolts (B), then remove the bearing caps (C).
  19. Lift the crankshaft (A) out of the engine block, being careful not to damage the journals and the CKP pulse plate ('08-09 models J35A7 engine).
  20. '08-09 models J35A7 engine: Remove the CKP pulse plate from the crankshaft (see «CKP PULSE PLATE REPLACEMENT»(ref-294717-S30928522092008081300000) ).
  21. Reinstall the main caps and bearings on the engine block in the proper order.
