Specifications: Other — Honda Insight ZE2 (2009-2011)

Engine Electrical

Item	Measurement	Qualification	Standard or New	Service Limit
Ignition coil	Rated voltage		12V
Ignition coil	Firing order		1-3-4-2
Spark plug	Type		NGK:DILFR6F11G
Spark plug	Gap		1.0-1.1 mm (0.039-0.043 in)
Ignition timing	At idle Check the red mark	In N or P	10±2°BTDC
Drive belt	Tension		Auto-tensioner
Starter	Output		1.0 kW
	Commutator mica depth		0 40-0.50 mm (0.016-0.020 in)	015 mm (0.006 in)
	Commutator runout		0.02 mm (0.001 in) max.	0.05 mm (0.002 in)
	Commutator O.D.		28.0-28.1 mm (1.102-1.106 in)	27.5 mm (1.083 in)
	Brush length		11.1-11.5 mm (0.44-0.45 in)	4.3 mm (0.17 in)

ENGINE ELECTRICAL SPECIFICATION

Cylinder Head

Item	Measurement	Qualification	Standard or New	Service Limit
Head	Warpage		0.07 mm (0.0028 in)	0.08 mm (0.0031 in)
Head	Height		119.9-120.1 mm (4.720-4.728 in)
Camshaft	End play		0.05-0.15 mm (0.002-0 006 in)	0.3 mm (0.01 in)
	Camshaft-to-holder oil clearance		0.050-0.089 mm (0.0020-0.0035 in)	0.10 mm (0.004 in)
	Total runout		0.03 mm (0.001 in) max.	0.04 mm (0.002 in)
	Cam lobe height	Intake PRI	29.700 mm (1.1693 in)
		Intake SEC	35.854 mm (1.4116 in)
		Exhaust PRI	29.900 mm (1.1772 in)
		Exhaust SEC	35.470 mm (1.3965 in)
Valve	Clearance (cold)	Intake	0.15-0.19 mm (0.006-0.007 in)
	Clearance (cold)	Exhaust	0.24-0.28 mm (0.009-0.011 in)
	Stem O.D.	Intake	5.48-5.49 mm (0.2157-0.2161 in)	5.45 mm (0.215 in)
	Stem O.D.	Exhaust	5.45-5.46 mm (0.2146-0.2150 in)	5.42 mm (0.213 in)
	Stem-to-guide clearance	Intake	0.020-0.050 mm (0.0008-0.0020 in)	0.08 mm (0.003 in)
	Stem-to-guide clearance	Exhaust	0.050-0.080 mm (0.0020-0.0031 in)	0.11 mm (0.004 in)
Valve seat	Width	Intake	0.850-1.150 mm (0.0335-0.0453 in)	1.80 mm (0.071 in)
	Width	Exhaust	1.250-1.550 mm (0.0492-0.0610 in)	2.00 mm (0.079 in)
	Stem installed height	Intake	47.4-47.8 mm (1.866-1.882 in)	48.1 mm (1.894 in)
	Stem installed height	Exhaust	47.3-47.7 mm (1.862-1.878 in)	48.0 mm (1.890 in)
Valve spring	Free length	Intake (NIPPON HATSUJO)	53.25 mm (2.096 in)
		Intake (CHUO HATSUJO)	53.26 mm (2.097 in)
		Exhaust (SUN CALL)	57.32 mm (2.257 in)
		Exhaust (CHUO HATSUJO)	57.31 mm (2.256 in)
Valve guide	I.D.	Intake	5.51-5.53 mm (0.217-0.218 in)	5.55 mm (0.219 in)
	I.D.	Exhaust	5.51-5.53 mm (0.217-0.218 in)	5.55 mm (0.219 in)
	Installed height	Intake	16.25-16.75 mm (0.640-0.659 in)
	Installed height	Exhaust	16.25-16.75 mm (0.640-0.659 in)
Rocker arm	Arm-to-shaft clearance	Intake	0.017-0.045 mm (0.0007-0.0018 in)	0.08 mm (0.003 in)
Rocker arm	Arm-to-shaft clearance	Exhaust	0.017-0.045 mm (0.0007-0.0018 in)	0.08 mm (0.003 in)

CYLINDER HEAD SPECIFICATION

Engine Block

Item	Measurement	Qualification	Standard or New	Service Limit
Block	Warpage of deck		0.07 mm (0.003 in)max.	0.10 mm (0.004 in)
	Bore diameter		73.000-73.015 mm (2.8740-2.8746 in)	73.065 mm (2.8766 in)
	Bore taper	Limit: (difference between first and third measurement)		0.05 mm (0.002 in)
	Reboring limit			0.25 mm (0.010 in)
Piston	Skirt O.D. at 16 mm (0.6 in) from bottom of skirt		72.969-72.979 mm (2.8728-2.8732 in)	72.967 mm (2.8727 in)
Piston	Clearance in cylinder		0.021-0.046 mm (0.0008-0.0018 in)	0.05 mm (0.002 in)
Piston ring	Ring-to-groove clearance	Top	0.065-0.090 mm (0.0026-0.0035 in)	0.15 mm (0.006 in)
	Ring-to-groove clearance	Second	0.030-0.055 mm (0.0012-0.0022 in)	0.12 mm (0.005 in)
	Ring end gap	Top	0.15-0.30 mm (0.006-0.012 in)	0.60 mm (0.024 in)
		Second	0.30-0.42 mm (0.012-0.017 in)	0.65 mm (0.026 in)
		Oil	0.20-0.70 mm (0.008-0.028 in)	0.80 mm (0.031 in)
Piston pin	O.D.		17.996-18.000 mm (0.7085-0.7087 in)
Piston pin	Pin-to-piston clearance		0.010-0.017 mm (0.0004-0.0007 in)
Connecting rod	Pin-to-rod interference		0.019-0.036 mm (0.0007-0.0014 in)
	Small-end bore diameter		17.964-17.977 mm (0.7072-0.7078 in)
	Large-end bore diameter	Normal	43.0 mm (1.69 in)
	End play installed on crankshaft		0.15-0.35 mm (0 006-0 014 in)	0.40 mm (0.016 in)
Crankshaft	Main journal diameter		49.976-50.000 mm (1.9676-1.9685 in)
	Rod journal diameter		39.976-40.000 mm (1.5739-1.5748 in)
	Rod/main journal taper		0.005 mm (0.0002 in)max.	0.010 mm (0.0004 in)
	Rod/main journal out-of-round		0.005 mm (0.0002 in)max.	0.010 mm (0.0004 in)
	End play		0.10-0.35 mm (0.004-0.014 in)	0.45 mm (0.018 in)
	Runout		0.030 mm (0.0012 in)max.	0.040 mm (0.0016 in)
Crankshaft bearing	Main bearing-to-journal oil clearance		0.018-0.036 mm (0.0007-0.0014 in)	0.050 mm (0.0020 in)
Crankshaft bearing	Rod bearing clearance		0.026-0.044 mm (0.0010-0.0017 in)	0.050 mm (0.0020 in)

ENGINE BLOCK SPECIFICATION

Cooling System

Item	Measurement	Qualification	Standard or New
Radiator	Coolant capacities (including engine, heater, hoses, and reservoir)	Engine overhaul	5.04 L (1.332 US gal)
Radiator		Coolant change	4.55 L (1.202 US gal)
	Coolant type		Honda Long Life Antifreeze/Coolant Type 2
Coolant reservoir	Coolant capacity		0.44 L (0.116 US gal)
Radiator cap	Opening pressure		93-123 kPa (0.95-1.25 kgf/cm 2 , 14-18 psi)
Thermostat	Opening temperature	Begins to open	169-176 °F (76-80 °C)
	Opening temperature	Fully open	194°F(90°C)
	Valve lift at fully open		Above 8.0 mm (0.31 in)

COOLING SYSTEM SPECIFICATION

Fuel and Emissions

Item	Measurement	Qualification	Standard or New
Fuel pressure regulator	Pressure with fuel pressure gauge connected		260-310 kPa (2.7-3.2 kgf/cm 2 , 38-46 psi)
Fuel tank	Capacity		40 L (10.6 US gal)
Engine idle	Idle speed without load (IMA battery SOC higher than 30 %)	In N or P	750 ± 50 rpm
Engine idle	Idle speed with high electric load (A/C on, temperature set to max cool, blower fan motor on high, rear window defogger on, headlights on high beam, and IMA battery SOC higher than 30%)	In N or P	750 ± 50 rpm

FUEL AND EMISSIONS SPECIFICATION

CVT and CVT Differential

Item	Measurement	Qualification	Standard or New	Service Limit
Continuously variable transmission fluid	Capacity: Use genuine Honda CVTF	Fluid change	2.8 L (3.0 US qt)
Continuously variable transmission fluid	Capacity: Use genuine Honda CVTF	Overhaul	5.2 L (5.5 US qt)
Hydraulic pressure	Forward clutch pressure	At 1,700 rpm in D	1,570-1,840 kPa (16.0-18.8 kgf/cm 2 , 228-267 psi)
	Reverse brake pressure	At 1,700 rpm in R	1,570-1,840 kPa (16.0-18.8 kgf/cm 2 , 228-267 psi)
	Drive pulley pressure	At 1,700 rpm in N	240-540 kPa (2.4-5.5 kgf/cm 2 , 34-78 psi)
	Driven pulley pressure	At 1,700 rpm in N	830-1,130 kPa (8.5-11.5 kgf/cm 2 , 120-164 psi)
	Lubrication pressure	At 3,000 rpm in N	250-400 kPa (2.5-4.1 kgf/cm 2 , 36-58 psi)
Stall speed	Check with vehicle on level ground	D, S, and L positions: Standard or new	1,900 rpm
		D, S, and L positions: Service limit	1,700-2,000 rpm
		R position: Standard or new	2,500 rpm
		R position: Service limit	2,400-2,600 rpm
Clutch	Clearance between clutch end-plate and top disc	Reverse brake	0.55-0.70 mm (0.022-0.028 in)
	Clutch return spring free length	Reverse brake	18.1 mm (0.71 in)	16.1 mm (0.63 in)
	Clutch disc thickness	Reverse brake	2.00 mm (0.079 in)	When worn or damaged
	Clutch plate thickness	Reverse brake	1.95 mm (0.077 in)	When discolored
	Reverse brake end-plate thickness	Mark 2	3.8 mm (0.150 in)	When discolored
		Mark B	3.9 mm (0.154 in)	When discolored
		Mark 3	4.0 mm (0.157 in)	When discolored
		Mark C	4.1 mm (0.161 in)	When discolored
		Mark 4	4.2 mm (0.165 in)	When discolored
		Mark D	4.3 mm (0.169 in)	When discolored
		Mark 5	4.4 mm (0.173 in)	When discolored
		Mark E	4.5 mm (0.177 in)	When discolored
		Mark 6	4.6 mm (0.181 in)	When discolored
		Mark F	4.7 mm (0.185 in)	When discolored
		Mark 7	4.8 mm (0.189 in)	When discolored
		Mark 8	5.0 mm (0.197 in)	When discolored
Input shaft	Diameter of needle bearing contact area	Flywheel side	19.987-20.000 mm (0.7869-0.7874 in)	When worn or damaged
	Diameter of needle bearing contact area	Forward clutch side	19.987-20.000 mm (0.7869-0.7874 in)	When worn or damaged
	Thrust clearance	CVTF pump drive sprocket hub	0.37-0.65 mm (0.015-0.026 in)
	Thrust clearance	Planetary carrier	0.050-0.115 mm (0.0020-0.0045 in)
	Feed pipe O.D.	Drive pulley feed pipe	6.97-6.98 mm (0.274-0.275 in)	6.95 mm (0.274 in)
	Feed pipe O.D.	Forward clutch feed pipe	11.470-11.480 mm (0.4516-0.4520 in)	11.450 mm (0.4508 in)
	Clutch feed pipe bushing I.D.	Drive pulley feed pipe	7.000-7.015 mm (0.2756-0.2762 in)	7.030 mm (0.2768 in)
	Clutch feed pipe bushing I.D.	Forward clutch feed pipe	11.500-11.518 mm (0.4528-0.4535 in)	11.533 mm (0.4541 in)
	Width of sealing ring groove		2.000-2.100 mm (0.079-0.083 in)	2.105 mm (0.083 in)
	22 x 28 mm thrust shim thickness (CVTF pump drive sprocket hub)	C	1.15 mm (0.045 in)	When worn or damaged
		D	1.40 mm (0.055 in)	When worn or damaged
		E	1.65 mm (0.065 in)	When worn or damaged
		F	1.90 mm (0.075 in)	When worn or damaged
		G	2.15 mm (0.085 in)	When worn or damaged
		H	2.40 mm (0.095 in)	When worn or damaged
	25 x 31 mm thrust shim thickness (planetary carrier)	A	1.05 mm (0.041 in)	When worn or damaged
		B	1.12 mm (0.044 in)	When worn or damaged
		C	1.19 mm (0.047 in)	When worn or damaged
		D	1.26 mm (0 050 in)	When worn or damaged
		E	1.33 mm (0.052 in)	When worn or damaged
		F	1.40 mm (0.055 in)	When worn or damaged
		G	1.47 mm (0.058 in)	When worn or damaged
		H	1.54 mm (0.061 in)	When worn or damaged
		I	1.61 mm (0.063 in)	When worn or damaged
		J	1.68 mm (0.066 in)	When worn or damaged
		K	1.75 mm (0.069 in)	When worn or damaged
		L	1.82 mm (0.072 in)	When worn or damaged
		M	1.085 mm (0.0427 in)	When worn or damaged
		N	1.155 mm (0.0455 in)	When worn or damaged
		O	1.225 mm (0.0482 in)	When worn or damaged
		P	1.295 mm (0.0510 in)	When worn or damaged
		Q	1.365 mm (0.0537 in)	When worn or damaged
		R	1.435 mm (0.0565 in)	When worn or damaged
		S	1.505 mm (0.0593 in)	When worn or damaged
		T	1.575 mm (0.0620 in)	When worn or damaged
		U	1.645 mm (0.0648 in)	When worn or damaged
		V	1 715 mm (0 0675 in)	When worn or damaged
		W	1.785 mm (0.0703 in)	When worn or damaged
Drive pulley shaft	Diameter of needle bearing contact area	Flywheel side	24 007-24.020 mm (0.945-0.946 in)	When worn or damaged
	Diameter of needle bearing contact area	Forward clutch side	24.007-24.020 mm (0.945-0.946 in)	When worn or damaged
	I.D.	Sealing ring	24.007-24.020 mm (0.945-0.946 in)	When worn or damaged
Driven pulley shaft	Diameter of needle bearing contact area	Start clutch side	43.981-43.991 mm (1.7315-1.7319 in)	When worn or damaged
	Thrust clearance	Start clutch side	0-0.13 mm (0-0.005 in)
	25.5 mm cotter thickness (start clutch hub)	A	2.90 mm (0 114 in)	When worn or damaged
		B	3.00 mm (0.118 in)	When worn or damaged
		C	3.10 mm (0.122 in)	When worn or damaged
		D	3 20 mm (0.126 in)	When worn or damaged
	Feed pipe O.D.	Canceler pressure	6.970-6.980 mm (0.2744-0.2748 in)	6.950 mm (0.2736 in)
	Feed pipe O.D.	Clutch pressure	8.97-8.98 mm (0.353-0.354 in)	8.95 mm (0.352 in)
	Driven pulley shaft feed pipe O.D.		11.470-11.480 mm (0.4516-0.4520 in)	11.450 mm (0.4508 in)
	Clutch feed pipe bushing I.D.	Canceler pressure	7.000-7.015 mm (0.2756-0.2762 in)	7.030 mm (0.2768 in)
	Clutch feed pipe bushing I.D.	Clutch pressure	9.000-9.015 mm (0.354-0.355 in)	9.030 mm (0.356 in)
	Driven pulley shaft feed pipe bushing I.D.		11.500-11.518 mm (0.4528-0.4535 in)	11.533 mm (0.4541 in)
	Secondary drive gear sealing ring groove width		2.500-2.650 mm (0.098-0.104 in)	2.655 mm (0.105 in)
	Start clutch end plate I.D.		88.900-88.935 mm (3.500-3.501 in)	When worn or damaged
Final drive shaft	Secondary drive gear thrust clearance		0-0.15 mm (0-0.006 in)
	25 x 35 mm thrust shim thickness	A	2.80 mm (0.110 in)	When worn or damaged
		B	2.90 mm (0.114 in)	When worn or damaged
		C	3.00 mm (0.118 in)	When worn or damaged
		D	3.10 mm (0.122 in)	When worn or damaged
		E	3.20 mm (0.126 in)	When worn or damaged
		F	3.30 mm (0.130 in)	When worn or damaged
		G	3.40 mm (0.134 in)	When worn or damaged
		H	3.50 mm (0.138 in)	When worn or damaged
		I	3.60 mm (0142 in)	When worn or damaged
		J	3.70 mm (0.146 in)	When worn or damaged
		K	3.80 mm (0.150 in)	When worn or damaged
		L	3.90 mm (0.154 in)	When worn or damaged
		M	4.00 mm (0.157 in)	When worn or damaged
Park gear and pawl			When worn or damaged
CVT differential carrier	Pinion shaft contact area I.D.		15.010-15.028 mm (0.591-0.592 in)
	Clearance between carrier and pinion shaft		0.026-0.062 mm (0.001-0.002 in)	0.1 mm (0.004 in)
	Driveshaft/intermediate shaft contact area I.D.		26.025-26.045 mm (1.0246-1.0254 in)
	Clearance between carrier and driveshaft/intermediate shaft		0.045-0.086 mm (0.002 - 0.003 in)	0.12 mm (0.005 in)
	Clearance between set ring and carrier bearing outer race		0-0.15 mm (0-0.006 in)	Adjust
CVT differential pinion gear	Backlash		0.05-0.15 mm (0.002-0.006 in)

CVT AND CVT DIFFERENTIAL SPECIFICATION

Steering

Item	Measurement	Standard or New
Steering wheel	Rotational play measured at outside edge with engine running	0-10 mm (0-0.39 in)
Steering wheel	Initial turning load measured at outside edge with engine running	34 N (3.5 kgf, 7.7 lbf)
Gearbox	Angle of rack guide screw loosened from locked position	17 ± 3°

STEERING SPECIFICATION

Suspension

Item	Measurement	Qualification	Standard or New	Service Limit
Wheel alignment	Camber	Front	0°00' ± 1 °
	Camber	Rear	1 °00' ± 1 °
	Caster	Front	3°20' ± 1 °
	Total toe-ian	Front	0 ± 3 mm (0 ± 0.12 in)
	Total toe-ian	Rear	2.5 ± 2.5 mm (0.10 ± 0.10 in)
	Front wheel turning angle	Inward	38°28' ± 2°
	Front wheel turning angle	Outward (reference)	32° 21' ±1 °
Wheel	Aluminum wheel runout	Axial	0-0.7 mm (0-0.03 in)	2.0 mm (0.08 in)
	Aluminum wheel runout	Radial	0-0.7 mm (0-0.03 in)	1.5 mm (0.06 in)
	Steel wheel runout	Axial	0-1.0 mm (0-0.04 in)	2.0 mm (0.08 in)
	Steel wheel runout	Radial	0-1.0 mm (0-0.04 in)	1.5 mm (0.06 in)
Wheel bearing	End play	Front	0-0.05 mm (0-0.002 in)
Wheel bearing	End play	Rear	0-0.05 mm (0-0.002 in)

SUSPENSION SPECIFICATION

Brakes

Item	Measurement	Standard or New	Service Limit
Parking brake	Distance traveled when lever pulled with 196 N (20 kgf, 44 lbf) of force	6 to 8 clicks
Brake pedal	Pedal height (carpet moved aside)	147 mm (5.79 in)
Brake pedal	Free play	1.0-5.0 mm (0.04-0.20 in)
Brake disc	Thickness	21.0 mm (0.83 in)	19.0 mm (0.75 in)
	Runout		0.04 mm (0.0016 in)
	Parallelism		0.015 mm (0.0006 in)
Brake pad	Thickness	10.0 mm (0.39 in)	1.6 mm (0.06 in)
Brake drum	Drum I.D.	200 mm (7.874 in)	201 mm (7.91 in)
Brake shoe	Shoe lining thickness	4.5 mm (0.18 in)	1.0 mm (0.04 in)

BRAKES SPECIFICATION

Air Conditioning

Item	Measurement	Qualification	Standard or New
Refrigerant	Type		HFC-134a(R-134a)
Refrigerant	Capacity of system		450-500 g (15.8-17.6 oz)
Refrigerant oil	Type		SP-10(P/N38897-P13-A01AH)
	Capacity of components	Condenser (Including receiver/dryer)	25mL(5/6 fl.oz)
		Evaporator	35 mL (1 1/6 fl.oz)
		Each line and hose	10 mL (1/3 fl.oz)
		Receiver/Dryer	10 mL (1/3 fl.oz)
		Compressor	80-90 mL (2 2/3-3 fL.oz)
Compressor	Field coil resistance	At 68 °F (20 °C)	3.15-3.45 ohms
Compressor	Pulley-to-armature plate clearance		0.35-0.65 mm (0.014-0.026 in)

AIR CONDITIONING SPECIFICATION

Item	Measurement	Qualification	Specification
DIMENSION	Overall length		4,377 mm (172.3 in)
	Overall width		1,695 mm (66.7 in)
	Overall height		1,427 mm (56.2 in)
	Wheelbase		2,550 mm (100.4 in)
	Track	Front	1,492 mm (58.7 in)
	Track	Rear	1,475 mm (58.1 in)
	Seating capacity		Five (5)
WEIGHT	Gross Vehicle Weight Rating (GVWR)		1,650 kg (3,638 lbs)
ENGINE	Type		Water-cooled, 4-stroke SOHC i-VTEC gasoline engine
	Cylinder arrangement		Inline 4-cylinder, transverse
	Bore and stroke		73x80 mm (2.87x3.15 in)
	Displacement		1,339 cm 3 (82 cu in)
	Compression ratio		10.8
	Valve train		Chain drive, SOHC i-VTEC 2 valves per cylinder
	Lubrication system		Forced, wet sump, with trochoid pump
	Fuel required		Regular UNLEADED gasoline with 87 Pump Octane Number or higher
STARTER	Type		Gear reduction
	Normal output		1.0 kW
	Hour rating		30 seconds
	Rotation direction		Counterclockwise as viewed from drive end
IMA MOTOR	Type		DC brushless-3 phases
BATTERY MODULE	Type		7.2VNi-MH
	Number		14
	Output		100 V
CVT	Type		Electronically-controlled continuously variable transmission, multi plates wet sump, hydraulic
	Primary reduction		Direct 1:1
	Gear ratio	Low-High	2.526-0.421
	Gear ratio	Reverse	4.508-1.874
	Final reduction	Type	Single helical gear
	Final reduction	Gear ratio	4.200
STEERING	Type		Electrical power-assisted rack and pinion
	Overall ratio		16.09
	Turns, lock-to-lock		3.29
	Steering wheel diameter		370 mm (14.6 in)
SUSPENSION	Type	Front	Independent strut with stabilizer, coil spring
	Type	Rear	Torsion beam, coil spring
	Shock absorber	Front and rear	Telescopic, hydraulic, nitrogen gas-filled
TIRES	Size	Front and rear	175/65R15 84S
TIRES	Size	Spare	T135/80D15 99M
WHEEL ALIGNMENT	Camber	Front	0°00'
	Camber	Rear	1°00'
	Caster	Front	3° 20'
	Total toe-in	Front	0 mm (0 in)
	Total toe-in	Rear	2.5 mm (0.10 in)
	Front wheel turning angle	Inward	38° 28'
	Front wheel turning angle	Outward (reference)	32° 21'
BRAKES	Type of service brake	Front	Power-assisted self-adjusting ventilated disc
	Type of service brake	Rear	Power-assisted self-adjusting drum
	Type of parking brake		Mechanical actuating, rear wheels
	Pad friction surface area (swept area)	Front	43.7 cm 2 (6.77 sq in) x 2
	Shoe friction surface area	Rear	57.6 cm 2 (8.93 sq in) x 2
AIR CONDITIONING	Compressor	Type	Scroll
		Capacity	77.1 mL (4.7 cu in)/rev.
		Maximum speed	10,000 rpm
		Lubricant capacity	80 mL (2 2/3 fl.oz)
		Lubricant type	SP-10
	Condenser	Type	Corrugated fin
	Evaporator	Type	Corrugated fin
	Blower	Type	Radial
		Motor type	220W/12V
		Speed control	Infinitely variable
		Maximum capacity	400 m 3 (14,126 cu ft)/h
	Temperature control		Air-mix type
	Compressor clutch	Type	Dry, single plate, Poly V-belt drive
	Compressor clutch	Electrical power consumption at 68 °F (20 °C)	42 W maximum at 12 V
	Refrigerant	Type	HFC-134a (R-134a)
	Refrigerant	Capacity	450-500 g (15.8-17.6 oz)
ELECTRICAL RATINGS	Battery		12 V-35 Ah/20 HR (12 V-28 Ah/5 HR)
	Fuses	Battery terminal fuse box	100 A, 60 A, 20 A
	Fuses	Under-dash fuse/relay box	50 A, 40 A, 30 A, 20 A, 15 A, 10 A, 7.5 A
	Light bulbs	Headlight high beam	12 V-60W
		Headlight low beam	12 V-55W
		Front turn signal lights	12 V-21 W
		Front side marker lights	12 V-5 W
		Front parking lights	12 V-5 W
		Side turn signal lights	LED
		Rear turn signal lights	12 V-21 W
		Rear side marker lights	12 V-3.8 W
		Brake/taillights	LED
		High mount brake light	LED
		Back-up lights	12 V-16 W
		License plate lights	12 V-5 W
		Ceiling lights	12 V-8 W
		Cargo area light	12 V-5 W
		Front individual map lights	12 V-8 W
		Glove box light	12 V-3.4 W
		Gauge lights	LED
		Indicator lights	LED
	Washer reservoir	Capacity (USA models)	2.5 L (2.6 US qt)
	Washer reservoir	Capacity (Canada models)	4.85 L (5.1 US qt)

DESIGN SPECIFICATIONS

Scheme 1

Scheme 1: Body Specifications

Specifications: Other Honda Insight ZE2
