Ignition Switch: Diagnosis Honda Insight ZE2

Key Interlock System Circuit Troubleshooting

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Check the A/T system DTCs with the HDS. Are DTCs indicated? YES -Go to DTC troubleshooting (see «DTC TROUBLESHOOTING INDEX»(ref-360271-S21713163902010042800000) ). NO -Go to step 2.
2. Check the A/T system Data List with the HDS. Is the transmission range switch indicated ON when the shift lever is in P, and is the transmission range switch indicated OFF when the shift lever is shifted to any position other than P? YES -Go to step 3. NO -Go to step 18 .
3. Move the shift lever to P and set the parking brake.
4. Remove the steering column covers (see «COLUMN COVER REMOVAL/INSTALLATION»(ref-360309-S16445770232010042800000) ).
5. Disconnect the steering lock assembly 6P connector.
6. Turn the ignition switch to ACCESSORY (I).
7. Check if the ignition switch can be turned to LOCK (0). Can the ignition switch be turned to LOCK (0)? YES -Go to step 8. NO -Faulty key interlock solenoid; replace the steering lock (see «STEERING LOCK REPLACEMENT»(ref-360267-S33056199332010042800000) ).
8. Check the No. 14 (7.5 A) fuse in the under-dash fuse/relay box. Is the fuse OK? YES -Go to step 9. NO -Replace the fuse. If the fuse blows again, repair a short to ground in the No. 14 (7.5 A) fuse circuit.
9. Make sure the ignition switch is turned to LOCK (0).
10. Disconnect under-dash fuse/relay box connector M (34P).
11. Check for continuity between steering lock assembly 6P connector terminal No. 3 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the key interlock solenoid and the MICU. NO -Go to step 12.
12. Check for continuity between under-dash fuse/relay box connector M (34P) terminal No. 17 and steering lock 6P connector terminal No. 3. Is there continuity? YES -Go to step 13. NO -Repair an open or high resistance in the wire between the key interlock solenoid and the MICU.
13. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-360315-S01822133382010042800000) ).
14. Disconnect the park pin switch 2P connector, and disconnect under-dash fuse/relay box connector Q (28P).
15. Do the park pin switch test (see «PARK PIN SWITCH TEST»(ref-360282-S22671495522010042800000) ). Is switch OK? YES -Go to step 16. NO -Check the park pin switch installation. If the switch installation is OK, replace the switch and retest (see «PARK PIN SWITCH REPLACEMENT»(ref-360271-S32486415232010042800000) ).
16. Check for continuity between park pin switch 2P connector terminal No. 2 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between park pin switch 2P connector terminal No. 2 and the MICU. NO -Go to step 17.
17. Check for continuity between park pin switch 2P connector terminal No. 1 and body ground. Is there continuity? YES -Go to step 19. NO -Repair an open or high resistance in the wire between the park pin switch and body ground (G502).
18. Do the transmission range switch test (see «TRANSMISSION RANGE SWITCH TEST»(ref-360271-S39812458602010042800000) ). Is switch OK? YES -Go to step 19. NO -Check the transmission range switch installation. If the switch installation is OK, replace the transmission range switch and retest (see «TRANSMISSION RANGE SWITCH REPLACEMENT»(ref-360271-S07549843332010042800000) ).
19. Disconnect under-dash fuse/relay box connector B (36P).
20. Disconnect the transmission range switch 8P connector.
21. Check for continuity between under-dash fuse/relay box connector B (36P) terminal No. 32 and transmission range switch 8P connector terminal No. 6. Is there continuity? YES -Go to step 22. NO -Repair an open or high resistance in the wire between the under-dash fuse/relay box and the transmission range switch.
22. Check for continuity between transmission range switch 8P connector terminal No. 2 and body ground. Is there continuity? YES -Faulty MICU, replace the under-dash fuse/relay box. See «USA MODELS»(ref-360306-S38132782692010042800000) . See «CANADA MODELS»(ref-360306-S18238482152010042800000) . NO -Repair an open or high resistance in the wire between the transmission range switch and body ground (G101).

Key Interlock Solenoid Test

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 9

1. Remove the steering column covers (see «GLOVE BOX STRIKER REPLACEMENT»(ref-360309-S24245984022010042800000) ).
2. Disconnect the steering lock assembly 6P connector (A).
3. Insert the ignition key in the key cylinder, then turn the ignition key to ACCESSORY (I).
4. Connect battery voltage to terminal No. 4 of the steering lock assembly, and ground terminal No. 3, then try turning the ignition switch to LOCK (0); the ignition switch should not turn.
5. Disconnect the power and ground from terminals, then turn the ignition switch to LOCK (0) and remove the key; the ignition switch should turn and the key can be removed.
6. If the key interlock solenoid does not work as specified, replace the steering lock assembly (see «STEERING LOCK REPLACEMENT»(ref-360267-S33056199332010042800000) ).

Scheme 10

1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-360315-S01822133382010042800000) ).
2. Disconnect the park pin switch 2P connector (A).
3. Check for continuity between connector terminals No. 1 and No. 2. There should be continuity when the shift lever is moved out of P. There should be no continuity when the shift lever is moved to P.
4. If the park pin switch fails the test, replace the park pin switch (see «PARK PIN SWITCH REPLACEMENT»(ref-360271-S32486415232010042800000) ).

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 11

Scheme 12

1. Do the 12 volt battery terminal disconnection procedure, (see «12 VOLT BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360280-S00079896582010042800000) )
2. Remove the steering column covers (see «GLOVE BOX STRIKER REPLACEMENT»(ref-360309-S24245984022010042800000) ).
3. Disconnect the 7P connector (A) from the ignition switch (B).
4. Check for continuity between the terminals in each switch position according to the table.
5. If the continuity is not as specified, replace the ignition switch (see «IGNITION SWITCH REPLACEMENT»(ref-360282-S42915447072010042800000) ).
6. Do the 12 volt battery terminal reconnection procedure, (see «12 VOLT BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360280-S00079896582010042800000) )

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 13

1. Do the 12 volt battery terminal disconnection procedure, (see «12 VOLT BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360280-S00079896582010042800000) )
2. Remove the steering column covers (see «GLOVE BOX STRIKER REPLACEMENT»(ref-360309-S24245984022010042800000) ).
3. Disconnect the 7P connector (A) from the ignition switch (B).
4. Remove the two screws and the ignition switch.
5. Install the parts in the reverse order of removal.
6. Do the 12 volt battery terminal reconnection procedure, (see «12 VOLT BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360280-S00079896582010042800000) )
