Audio System: Removal & Installation Honda Insight ZE2

Audio Unit Removal/Installation

SRS components are located in this area. Review the SRS component location (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) in the SRS section before doing repairs or service.

Audio Remote Switch Replacement

SRS components are located in this area. Review the SRS component location (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) in the SRS section before doing repairs or service.

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. Remove the steering wheel (see «STEERING WHEEL REMOVAL»(ref-360267-S38670080522010042800000) ).
2. Remove the screws, and steering wheel rear cover (A).
3. On 2011 model, remove the screw (B), and earth terminal (C).
4. Remove the paddle shifter + (upshift switch) and paddle shifter - (downshift switch) (see «PADDLE SHIFTER + (UPSHIFT SWITCH) OR PADDLE SHIFTER - (DOWNSHIFT SWITCH) REPLACEMENT»(ref-360271-S32857026942010042800000) ).
5. Remove the screws and the steering wheel trim (A).
6. Disconnect the connectors, and remove the harness guide (A).
7. Remove the audio remote switch (A).
8. Install the audio remote switch in the reverse order of removal.

Scheme 10

1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-360315-S01822133382010042800000) ).
2. Remove the center console armrest (see «CENTER CONSOLE ARMREST REPLACEMENT»(ref-360315-S29526397252010042800000) ).
3. Remove the console box (see «CENTER CONSOLE ARMREST REPLACEMENT»(ref-360315-S29526397252010042800000) ).
4. Disconnect the connectors (A) from the USB adapter unit(B).
5. Remove the mounting bolts (C) and the USB adapter unit.
6. Install the USB adapter unit in the reverse order of removal.

Scheme 11

1. Remove the center lower trim (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(ref-360309-S00947382592010042800000) ).
2. Remove the 5P connector (A) from the auxiliary jack assembly (B).
3. Push out the auxiliary jack assembly from the center lower trim.
4. Install the auxiliary jack assembly (B) in the reverse order of removal.

Scheme 12

1. Remove the AM/FM antenna mast (A).
2. Remove the AM/FM antenna base (B). Remove the C-pillar trim (see «C-PILLAR TRIM»(ref-360313-S11041118632010042800000) ), and disconnect the connector (C). Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(ref-360313-S21929008092010042800000) ), and detach the clip (D). Remove the nut (E) from the AM/FM antenna base, and remove it.
3. Install the antenna in the reverse order of removal.
