Relays: Other Honda Insight ZE2

Normally-open Four-terminal type

Check for continuity between the terminals

1. There should be continuity between terminals No. 1 and No. 2 when battery power is connected to terminal No. 4, and body ground is connected to terminal No. 3.
2. There should be no continuity between terminals No. 1 and No. 2 when power is disconnected.

Scheme 336

Five-terminal type

Check for continuity between the terminals

1. There should be continuity between terminals No. 1 and No. 2 when battery power is connected to terminal No. 5, and body ground is connected to terminal No. 3.
2. There should be continuity between terminals No. 1 and No. 4 when power is disconnected.

Scheme 337
