Audio remote switch does not work properly (without navigation) Honda Insight ZE2

Audio System 2 illustrations ~347 words

Audio remote switch does not work properly (without navigation)

Note. Check the vehicle battery condition first (see 12 VOLT BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 106

Scheme 106: Audio remote switch does not work properly (without navigation)
Scheme 106: Audio remote switch does not work properly (without navigation)

Scheme 107

Scheme 107
Scheme 107
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio unit and check the audio remote switch operation (volume up, volume down, CH +, CH -, MODE). Is the audio unit operation OK? YES -Intermittent failure, the audio remote switch is OK at this time. Check for loose connections. NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0).
  4. Do the audio remote switch test (see «AUDIO REMOTE SWITCH TEST»(ref-360324-S23578522112010042800000) ). Is the audio remote switch OK? YES -Go to step 5. NO -Replace the audio remote switch (see «AUDIO REMOTE SWITCH REPLACEMENT»(ref-360324-S08939560292010042800000) ), and recheck.
  5. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-360324-S16175579992010042800000) ).
  6. Disconnect audio unit connector A (24P). NOTE: Eject all the discs before removing the audio unit to prevent damaging the CD player's load mechanism.
  7. Reconnect the audio remote switch, and measure the resistance between audio unit connector A (24P) terminals No. 5 and No. 16 as specified in the table. AUDIO REMOTE SWITCH TABLE Position VOL DOWN VOL UP CH (-) CH (+) MODE No button pressed Resistance about 100 ohms about 357 ohms about 775 ohms about 1.7 kO about 3.7 kO about 3.7 kO Is the resistance OK? YES -Go to step 8. NO -Repair a short or open or high resistance in the circuit between the audio unit and the cable reel. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(ref-360291-S36823172832010042800000) ).
  8. Check for continuity between body ground and audio unit connector A (24P) terminals No. 5 and No. 16 individually. Is there continuity? YES -Repair a short to body ground in the wire(s) between the audio unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(ref-360291-S36823172832010042800000) ). NO -Replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-360324-S16175579992010042800000) ).
