Wipers/washers: Other Honda Element YH2 рестайлинг 2

Wiper Arms Stop Position

1. When the wiper arms stop at the automatic stop position, confirm that they are at the standard position. Position at about 0.6 in. (16 mm) from the top of cowl cover (A) Position at about 0.6 in. (16 mm) from the top of cowl cover (A)

Scheme 25

1. When you turn on the washers, confirm 50% or more of the washer fluid lands within the spray area. If the spray area is not within the standard positions, adjust the nozzles. NOTE: Spray area on the passenger side is symmetrical. X shows the distance from the centerline of the windshield. Y shows the distance from the cowl cover. WASHER NOZZLE POSITION - c d e f g h i j X 18.3 in. (465 mm) 14.7 in. (374 mm) 16.7 in. (424 mm) 14.0 in. (355 mm) 9.8 in. (249 mm) 6.7 in. (170 mm) 10.2 in. (259 mm) 7.8 in. (198 mm) Y 10.8 in. (275 mm) 10.3 in. (262 mm) 4.8 in. (121 mm) 4.6 in. (117 mm) 10.0 in. (253 mm) 9.9 in. (252 mm) 4.5 in. (115 mm) 4.5 in. (114 mm)

Wiper Arm Stop Position

1. When the wiper arm stops at the automatic stop position, confirm that it is are at the standard position. Position at about 1.7 in. (44 mm) from the bottom of the windshield (A).

Scheme 26

1. When you turn on the washers, confirm the washer fluid lands within the spray area. If the spray area is not within the standard positions, adjust the nozzles. Position at about 0.6 in. (15 mm) from the top of the windshield (B).

Scheme 27

Scheme 28

1. Remove the right inner fender (see «FRONT INNER FENDER REPLACEMENT»(ref-290862-S10505627782008072200000) ).
2. Remove the washer nozzles and clips, then remove the tubes.
3. Install in the reverse order of removal. Take care not to pinch the washer tubes. Check the washer operation. NOTE: Make sure the washer tube is routed behind the side curtain airbag tether strap (see «SIDE CURTAIN AIRBAG REPLACEMENT»(ref-355246-S02684509642010012100000) ).

Scheme 29

Scheme 30

1. Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(ref-290870-S30778415792008072200000) ).
2. Disconnect the washer tubes (A).
3. Disconnect the 2P connectors (B) from the washer motors (C) and the washer fluid level switch (D) (Canada models).
4. Remove the three mounting bolts and washer reservoir (A).
5. Install in the reverse order of removal. Make sure the washer motors operate properly.
