Front Suspension: Component Locations Honda Element YH2 рестайлинг 2

Wheel Hubs 38 illustrations ~2397 words

Special Tools Required

  1. Ball joint thread protector, 12 mm 07AAF-SDAA100
  2. Hub dis/assembly tool 07GAF-SD40100
  3. Ball joint remover, 32 mm 07MAC-SL0A102
  4. Ball joint remover, 28 mm 07MAC-SL0A202
  5. Ball joint thread protector, 14 mm 071AF-S3VA000
  6. Attachment, 62 x 68 mm 07746-0010500
  7. Driver 07749-0010000
  8. Support base 07965-SD90100

Scheme 6

Scheme 6: Knuckle/Hub Replacement
Scheme 6: Knuckle/Hub Replacement

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. Raise the front of the vehicle, and support it with safety stands in the proper locations (see «LIFT AND SUPPORT POINTS»(ref-290856-S03262290762008072200000) ).
  2. Remove the wheel nuts and front wheel.
  3. Remove the brake hose bracket mounting bolt (A).
  4. Remove the brake caliper bracket mounting bolts (B), then remove the caliper assembly (C) from the knuckle. To prevent damage to the caliper assembly or brake hose, use a short piece of wire to hang the caliper assembly from the undercarriage. Do not twist the brake hose excessively.
  5. Raise the stake (A), then remove the spindle nut (B).
  6. Remove the brake disc (see «FRONT BRAKE DISC REPLACEMENT»(ref-290813-S12413789532008072200000) ).
  7. Check the front hub for damage and cracks.
  8. Remove the flange bolt (A) and wheel sensor (B) from the knuckle. Do not disconnect the wheel sensor connector.
  9. Remove the flange nut (A) while holding the joint pin (B) with a hex wrench (C), and disconnect the stabilizer link (D) from the lower arm (E). NOTE: Use a new flange nut during reassembly.
  10. Remove the lock pin (A) from the knuckle ball joint, then remove the castle nut (B). NOTE: During installation, insert the lock pin as shown after tightening the new nut.
  11. Disconnect the lower arm from the knuckle using the ball joint thread protector and ball joint remover (see «BALL JOINT REMOVAL»(ref-290815-S22087854772008072200000) ).
  12. Loosen the damper pinch bolts (A) while holding the nuts (B), and remove the bolts and the nuts. NOTE: During installation, install new damper pinch bolts and new nuts.
  13. Remove the driveshaft outboard joint (C) from the knuckle (D) by tapping the driveshaft end (E) with a plastic hammer while drawing the hub outward, then remove the knuckle. NOTE: Do not pull the driveshaft end outward. The driveshaft inboard joint may come apart. During installation, apply grease to the mating surfaces of the wheel bearing and the driveshaft outboard joint (see step 1 on page 16-18).
  14. Install the knuckle/hub in the reverse order of removal, and note these items: First install all the components, and lightly tighten the bolts and nuts, then raise the suspension with a floor jack to load it with the vehicle's weight before fully tightening to the specified torque values. Do not place the jack against the ball joint pin of the knuckle. Be careful not to damage the ball joint boot when installing the knuckle. Before connecting the knuckle ball joint to the lower arm, degrease the threaded section and tapered portion of the ball joint pin, the ball joint connecting hole, the threaded section, and mating surface of the castle nut. Torque the castle nut to the lower torque specification, then tighten it only far enough to align the slot with the ball joint pin hole. Do not align the castle nut by loosening it. Use a new spindle nut during reassembly. Before installing the spindle nut, apply a small amount of engine oil to the seating surface of the nut. After tightening, use a drift to stake the spindle nut shoulder against the driveshaft. Before installing the brake disc, clean the mating surfaces of the front hub and the inside of the brake disc. Before installing the wheel, clean the mating surfaces of the brake disc and the inside of the wheel. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(ref-290815-S14112056652008072200000) ).

Scheme 13

Scheme 13: Wheel Bearing Replacement
Scheme 13: Wheel Bearing Replacement

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Separate the hub (A) from the knuckle (B) using the hub dis/assembly tool and a hydraulic press. Hold the knuckle with the attachment (C) of the hydraulic press or equivalent tool. Be careful not to deform the splash guard (D). Hold onto the hub to keep it from falling when pressed clear.
  2. Press the wheel bearing inner race (A) out of the hub (B) using the hub dis/assembly tool, a commercially available bearing separator (C), and a press.
  3. Remove the snap ring (A) and the splash guard (B) from the knuckle (C).
  4. Press the wheel bearing (A) out of the knuckle (B) using the driver, the attachment, and a press.
  5. Wash the knuckle and hub thoroughly in a high flash point solvent before reassembly.
  6. Press a new wheel bearing (A) into the knuckle (B) using the old bearing (C), a steel plate (D), the support base, and a press. Be careful not to damage the bearing seal (E). NOTE: Install the wheel bearing with the magnetic encoder (F) (brown color) toward the inside of the knuckle. Remove any oil, grease, dust, metal debris, and other foreign material from the encoder surface. Keep magnetic tools away from the encoder surface. Be careful not to damage the encoder surface when you insert the wheel bearing.
  7. Install the snap ring (A) securely in the knuckle (B).
  8. Install the splash guard (C), and tighten the screws (D) to the specified torque value.
  9. Press a wheel bearing (A) onto the hub (B) using the driver, the attachment, the support base, and a press.
  1. Ball joint boot clip guide 07GAG-SD40700
  2. Front hub dis/assembly tool 07965-SA50500

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Remove the knuckle (see «KNUCKLE/HUB REPLACEMENT»(ref-290841-S33507530782008072200000) ).
  2. Remove the boot. Check for a gap between the ball joint (A) and the knuckle. If there is a gap, replace the knuckle assembly. Do not press the ball joint back into the knuckle.
  3. Pack the interior and lip (B) of a new boot with fresh grease. Keep the grease off of the boot-to-knuckle mating surfaces (C).
  4. Wipe the grease off the tapered section of the ball joint pin (D), and pack fresh grease onto the base (E). Do not let dirt or other foreign materials get into the boot.
  5. Install the boot onto the ball joint pin, then squeeze it gently to force out any air.
  6. Except SC model: Press the boot with the hub dis/assembly tool until the bottom seats on the knuckle (A) all the way around.
  7. SC model: Adjust the ball joint boot clip guide with the adjusting bolt (A) until its base is just above the groove around the bottom of the boot. Then slide the clip (B) over the tool and into position on the boot.
  8. After installing a boot, wipe any grease off the exposed portion of the ball joint pin.
  9. Install the knuckle (see «KNUCKLE/HUB REPLACEMENT»(ref-290841-S33507530782008072200000) ).
  1. Ball joint thread protector, 12 mm 07AAF-SDAA100
  2. Ball joint remover, 32 mm 07MAC-SL0A102
  3. Ball joint remover, 28 mm 07MAC-SL0A202
  4. Ball joint thread protector, 14 mm 071AF-S3VA000

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25
  1. Raise the front of the vehicle, and support it with safety stands in the proper locations (see «LIFT AND SUPPORT POINTS»(ref-290856-S03262290762008072200000) ).
  2. Remove the front wheel.
  3. Remove the flange nut (A) while holding the joint pin (B) with a hex wrench (C), and disconnect the stabilizer link (D) from the lower arm (E). NOTE: Use a new flange nut during reassembly.
  4. Remove the lock pin (A) from the knuckle ball joint, then remove the castle nut (B). NOTE: During installation, insert the lock pin as shown after tightening the new nut.
  5. Disconnect the lower arm from the knuckle using the ball joint thread protector and ball joint remover (see «BALL JOINT REMOVAL»(ref-290815-S22087854772008072200000) ).
  6. Remove the flange bolts, and remove the lower arm (A). NOTE: Use new flange bolts during reassembly.
  7. Install the lower arm in the reverse order of removal, and note these items: First install all the components, and lightly tighten the bolts and nuts, then raise the suspension with a floor jack to load it with the vehicle's weight before fully tightening it to the specified torque values. Do not place the jack against the ball joint pin of the knuckle. Be careful not to damage the ball joint boot when connecting the lower arm to the knuckle. Before connecting the knuckle ball joint to the lower arm, degrease the threaded section and tapered portion of the ball joint pin, the ball joint connecting hole, the threaded section, and mating surface of the castle nut. Torque the castle nut to the lower torque specification, then tighten it only far enough to align the slot with the ball joint pin hole. Do not align the castle nut by loosening it. Before installing the wheel, clean the mating surfaces of the brake disc and the inside of the wheel. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(ref-290815-S14112056652008072200000) ).

Scheme 26

Scheme 26: Stabilizer Link Removal/Installation
Scheme 26: Stabilizer Link Removal/Installation

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Raise the front of the vehicle, and support it with safety stands in the proper locations (see «LIFT AND SUPPORT POINTS»(ref-290856-S03262290762008072200000) ).
  2. Remove the front wheel.
  3. Remove the self-locking nut (A) and flange nut (B) while holding the respective joint pin (C) with a hex wrench (D), and remove the stabilizer link (E).
  4. Install the stabilizer link (A) on the stabilizer bar (B) and lower arm (C) with the joint pins (D) set at the center of their range of movement. NOTE: Except SC model: The left stabilizer has a yellow paint mark (E), while the right stabilizer link has a white paint mark. SC model: The left stabilizer link has a red paint mark, while the right stabilizer link has a blue paint mark.
  5. Install a new self-locking nut and a new flange nut, and lightly tighten them.
  6. Place a jack under the lower arm, and raise the suspension to load it with the vehicle's weight. NOTE: Do not place the jack against the ball joint pin.
  7. Tighten the self-locking nut (A) and flange nut (B) to the specified torque values while holding the respective joint pin (C) with a hex wrench (D).
  8. Clean the mating surfaces of the brake disc and the inside of the wheel, then install the front wheel, and test-drive the vehicle.
  9. After 5 minutes of driving, torque the self-locking nut torque value again.

Scheme 29

Scheme 29: Stabilizer Bar Replacement
Scheme 29: Stabilizer Bar Replacement

Scheme 30

Scheme 30
Scheme 30
  1. Raise the front of the vehicle, and support it with safety stands in the proper locations (see «LIFT AND SUPPORT POINTS»(ref-290856-S03262290762008072200000) ).
  2. Remove the front wheels.
  3. Disconnect the stabilizer links from the stabilizer bar on the right and left sides (see «STABILIZER LINK REMOVAL/INSTALLATION»(ref-290841-S24143912802008072200000) ).
  4. Remove the flange bolts (A) and the bushing holders (B), then remove the bushings (C) and the stabilizer bar (D).
  5. Install the stabilizer bar in the reverse order of removal, and note these items: Note the right and left direction of the stabilizer bar. The paint mark (A) on the stabilizer bar shows the right side (except SC model). Do not set the bushings on the bent or curved part of the stabilizer bar. Note the fore/aft direction of the bushings and the bushing holders. Refer to stabilizer link removal/installation to connect the stabilizer bar to the links (see «STABILIZER LINK REMOVAL/INSTALLATION»(ref-290841-S24143912802008072200000) ). Before installing the wheel, clean the mating surfaces of the brake disc and the inside of the wheel.
  1. Ball joint thread protector, 12 mm 07AAF-SDAA100
  2. Ball joint remover, 28 mm 07MAC-SL0A202

Scheme 31

Scheme 31: Removal
Scheme 31: Removal

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Raise the front of the vehicle, and support it with safety stands in the proper locations (see «LIFT AND SUPPORT POINTS»(ref-290856-S03262290762008072200000) ).
  2. Remove the front wheel.
  3. Remove the cotter pin (A) from the tie-rod end ball joint, then remove the nut (B).
  4. Disconnect the tie-rod end from the steering arm on the damper using the ball joint thread protector and ball joint remover (see «BALL JOINT REMOVAL»(ref-290815-S22087854772008072200000) ).
  5. Remove the bolts, and remove the wheel sensor harness bracket (A) and brake hose bracket (B) from the damper. Do not disconnect the wheel sensor connector.
  6. Remove the damper pinch bolts (A) while holding the nuts (B).
  7. Remove the flange nuts (A) from the top of the damper.
  8. Lower the lower arm, and remove the damper assembly (A).

Scheme 36

Scheme 36: Installation
Scheme 36: Installation

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40
  1. Lower the lower arm, and position the damper assembly in the body. Turn the damper mounting base so the "delta L" or "delta R" mark (A) faces toward the outside of the vehicle.
  2. Loosely install the new flange nuts (A) onto the top of the damper.
  3. Position the damper on the knuckle, and install the new damper pinch bolts (A) and the new flange nuts (B), and lightly tighten the nuts.
  4. Place a jack under the lower arm, and raise the suspension to load it with the vehicle's weight. NOTE: Do not place the jack against the lower arm ball joint.
  5. Tighten the flange nuts on the top of the damper to the specified torque value.
  6. Tighten the damper pinch bolts to the specified torque value.
  7. Install the brake hose bracket (A) and the wheel sensor harness bracket (B) onto the damper, and tighten the bolt to the specified torque values.
  8. Clean off any grease contamination from the ball joint tapered section and threads, then connect the tie-rod end to the steering arm. Tighten the nut (A) to the specified torque value. Install the cotter pin (B) after tightening, and bend its end as shown.
  9. Clean the mating surfaces of the brake disc and the inside of the wheel, then install the front wheel.
  10. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(ref-290815-S14112056652008072200000) ).

Scheme 41

Scheme 41: Exploded View
Scheme 41: Exploded View

Note. When compressing the damper spring, use a commercially available strut spring compressor (Branick MST-580A or Model 7200 or equivalent) according to the manufacturer's instructions.

Scheme 42

Scheme 42: Disassembly
Scheme 42: Disassembly
  1. Compress the damper spring, then remove the self-locking nut (A) while holding the damper shaft (B) with a hex wrench (C). Do not compress the spring more than necessary to remove the nut.
  2. Release the pressure from the strut spring compressor, then disassemble the damper as shown in «EXPLODED VIEW»(ref-290841-S23935809002008072200000) .

Scheme 43

Scheme 43: Inspection
Scheme 43: Inspection
  1. Reassemble all the parts, except for the damper mounting bearing, the upper spring seat, upper spring mounting cushion, and damper spring.
  2. Compress the damper assembly by hand, and check for smooth operation through a full stroke, both compression and extension. The damper should extend smoothly and constantly when compression is released. If it does not, the gas is leaking and the damper should be replaced.
  3. Check for oil leaks, abnormal noises, and binding during these tests.
