Design Specifications
| Item | Measurement | Qualification | Standard or New |
|---|---|---|---|
| DIMENSIONS | Overall length | LX | 4,300 mm (169.3 in.) |
| EX | 4,326 mm (170.3 in.) | ||
| SC | 4,341 mm (170.9 in.) | ||
| Overall width | 1,815 mm (71.5 in.) | ||
| Overall height | LX, EX | 1,788 mm (70.4 in.) | |
| SC | 1,763 mm (69.4 in.) | ||
| Wheelbase | 2,575 mm (101.4 in.) | ||
| Track | Front (LX, EX) | 1,577 mm (62.1 in.) | |
| Front (SC) | 1,578 mm (62.1 in.) | ||
| Rear (LX, EX) | 1,582 mm (62.3 in.) | ||
| Rear (SC) | 1,587 mm (62.5 in.) | ||
| Seating capacity | Four (4) | ||
| WEIGHT | Gross Vehicle Weight Rating (GVWR) | 2,020 kg (4,450 lbs) | |
| ENGINE | Type | Water cooled, 4-stroke DOHC i-VTEC gasoline engine | |
| Cylinder arrangement | Inline 4-cylinder, transverse | ||
| Bore and stroke | 87 x 99 mm (3.43 x 3.90 in.) | ||
| Displacement | 2,354 cm 3 (144 cu in.) | ||
| Compression ratio | 9.7 | ||
| Valve train | Chain drive, DOHC i-VTEC 4 valves per cylinder | ||
| Lubrication system | Forced, wet sump, with trochoid pump | ||
| Oil pump displacement | At 6,000 rpm | 52.8 L (55.8 US qt)/minute | |
| Water pump displacement | At 6,000 rpm | 95.5 L (101 US qt)/minute | |
| Fuel required | Regular UNLEADED gasoline with 87 Pump Octane Number or higher | ||
| STARTER | Type | Gear reduction | |
| Normal output | 1.6 kW | ||
| Nominal voltage | 12V | ||
| Hour rating | 30 seconds | ||
| Direction of rotation | Clockwise as viewed from drive end | ||
| CLUTCH | Type | Single plate dry, diaphragm spring | |
| Clutch friction material surface area | 174 cm 2 (26.97 sq in.) | ||
| MANUAL TRANSMISSION | Type | Synchronized, 5-speed forward, 1 reverse | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 3.533 | |
| 2nd | 2.042 | ||
| 3rd | 1.355 | ||
| 4th | 1.028 | ||
| 5th | 0.825 | ||
| Reverse | 3.583 | ||
| Final reduction | Type | Single helical gear | |
| Gear ratio | 4.765 | ||
| AUTOMATIC TRANSMISSION | Type | Electronically controlled automatic, 5-speed forward, 1 reverse, 3-element torque converter with lock-up clutch | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 2.786 | |
| 2nd | 1.614 | ||
| 3rd | 1.082 | ||
| 4th | 0.773 | ||
| 5th | 0.566 | ||
| Reverse | 2.000 | ||
| Transfer gear | Type | Single helical gear | |
| Gear ratio | 4.765 | ||
| Differential final gears | Type | Single helical gear | |
| Gear ratio | 4.500 | ||
| STEERING | Type | Hydraulic power-assisted rack and pinion | |
| Overall ratio | LX, EX | 16.2 | |
| SC | 15.34 | ||
| Turns, lock-to-lock | LX, EX | 3.26 | |
| SC | 2.98 | ||
| Steering wheel diameter | 386 mm (15.2 in.) | ||
| SUSPENSION | Type | Front | Independent strut with stabilizer, coil spring |
| Rear | Independent double wishbone with stabilizer, coil spring | ||
| Shock absorber | Front | Telescopic, hydraulic, nitrogen gas-filled | |
| Rear | Telescopic, hydraulic, nitrogen gas-filled | ||
| TIRES | Size of front and rear tires | LX, EX | P215/70R1699S |
| SC | P225/55R18 97H | ||
| Size of spear tires | T145/90D16 106M | ||
| WHEEL ALIGNMENT (LX, EX) | Camber | Front | 0° 13' |
| Rear | 1° 00' | ||
| Caster | Front | 1° 50' | |
| Total toe-in | Front | 0 mm (0 in.) | |
| Rear | 2 mm (0.08 in.) | ||
| WHEEL ALIGNMENT (SC) | Camber | Front | 0° 24' |
| Rear | 1° 06' | ||
| Caster | Front | 1° 50' | |
| Total toe-in | Front | 0 mm (0 in.) | |
| Rear | 2 mm (0.08 in.) | ||
| BRAKES | Type of service brake | Front | Power-assisted self-adjusting ventilated disc |
| Rear | Power-assisted self-adjusting solid disc | ||
| Type of parking brake | Mechanical actuating, rear wheels | ||
| Pad friction surface area | Front | 46.0 cm 2 (7.13 sq in.) x 2 | |
| Rear | 27.9 cm 2 (4.32 sq in.) x 2 | ||
| Parking brake shoe friction surface area | 49.0 cm 2 (7.6 sq in.) x 2 | ||
| AIR CONDITIONING | Compressor | Type | Swash plate |
| Capacity | 188 mL (11.47 cu in.)/rev. | ||
| Maximum speed | 7,922 rpm | ||
| Lubricant capacity | 160 mL (51/3 fl.oz) | ||
| Lubricant type | DENSO ND-OIL 8 | ||
| Condenser | Type | Corrugated fin | |
| Evaporator | Type | Corrugated fin | |
| Blower | Type | Radial fan | |
| Motor type | 190 W/12 V | ||
| Speed control | Infinite variable | ||
| Maximum capacity | 480 m 3 (16.900 cu ft)/h | ||
| Temperature control | Air-mix type | ||
| Compressor clutch | Type | Dry, single plate, poly-V belt drive | |
| Electrical power consumption at 68°F (20°C) | 35 W max. at 12 V | ||
| Refrigerant | Type | HFC-134a (R-134a) | |
| Capacity | 500-550 g (17.6-19.4 oz) | ||
| ELECTRICAL RATINGS | Battery | 12 V-47 Ah/20 HR (12 V-38 Ah/5HR) | |
| Fuses | Under-hood fuse/relay box | 100 A, 50 A, 40 A, 30 A, 20 A, 15 A, 10 A, 7.5 A | |
| Under-dash fuse/relay box | 20 A, 15 A, 10 A, 7.5 A | ||
| Light bulbs | Headlight high/low beam(LX, EX) | 12 V-60/55 W (H4/HB2) | |
| Headlight high beam (SC) | 12 V-60 W (HB3) | ||
| Headlight low beam (SC) | 12 V-55 W (H11) | ||
| Front turn signal/parking lights | 12V-21/5 W (LX, EX) 12V-28/8 W (SC) | ||
| Front side marker lights | 12 V-3CP (LX, EX) 12 V-5 W (SC) | ||
| Rear turn signal lights | 12 V-21 W (Amber) | ||
| Brake/rear side marker lights/taillights | 12 V-21/5 W | ||
| High mount brake light | 12 V-21 W | ||
| Back-up lights | 12 V-18 W | ||
| License plate lights | 12 V-5 W | ||
| Ceiling lights | 12 V-10 W | ||
| Spotlights | 12 V-8 W | ||
| Gauge lights | LED | ||
| Indicator lights | LED | ||
| Washer reservoir | Capacity | 4.5 L (4.7 US qt) |
DESIGN SPECIFICATIONS TABLE
