A/C Compressor Clutch Overhaul

Special Tools Required

A/C clutch holder, Robinair 10204, Kent-Moore J37872, or Honda Tool and Equipment KMT-J33939, commercially available

Scheme 85

Scheme 85: A/C Compressor Clutch Overhaul

Scheme 86

Scheme 86

Scheme 87

Scheme 87

Scheme 88

Scheme 88
  1. Remove the center bolt (A) while holding the pressure plate with a commercially available A/C clutch holder (B).
  2. Remove the pressure plate (A) and shim(s) (B), taking care not to lose the shim(s). If the clutch needs adjustment, increase or decrease the number and thickness of shims as necessary, then reinstall the pressure plate, and recheck its clearance (see «A/C COMPRESSOR CLUTCH CHECK»(ref-220611-S22559159482006022100000) ). NOTE: The shims are available in three thicknesses: 0.1 mm, 0.3 mm, and 0.5 mm.
  3. If you are replacing the field coil, remove the snap ring (A) with snap ring pliers, then remove the rotor pulley (B). Be careful not to damage the rotor pulley and A/C compressor.
  4. Remove the screw, the wire harness clip (A), and holder (B), then disconnect the field coil connector (C). Remove the snap ring (D) with snap ring pliers, then remove the field coil (E). Be careful not to damage the field coil and A/C compressor.
  5. Reassemble the clutch in the reverse order of disassembly, and note these items: Install the field coil with the wire side facing down, and align the boss on the field coil with the hole in the A/C compressor. Clean the rotor pulley and A/C compressor sliding surfaces with contact cleaner or other non-petroleum solvent. Install new snap rings, note the installation direction, and make sure they are fully seated in the groove. Make sure that the rotor pulley turns smoothly after it's reassembled. Route and clamp the wires properly or they can be damaged by the rotor pulley.

Scheme 89

Scheme 89: A/C Compressor Relief Valve Replacement
  1. Recover the refrigerant with a recovery/recycling/charging station (see «REFRIGERANT RECOVERY»(ref-220611-S19543847392006022100000) ).
  2. Remove the relief valve (A), and the O-ring (B). Plug the opening to keep foreign matter from entering the system and the A/C compressor oil from running out.
  3. Clean the mating surfaces.
  4. Replace the O-ring with a new one at the relief valve, and apply a thin coat of refrigerant oil before installing it.
  5. Remove the plug, and install and tighten the relief valve.
  6. Charge the system (see «SYSTEM CHARGING»(ref-220611-S02990373832006022100000) ).

Scheme 90

Scheme 90: A/C Condenser Replacement

Scheme 91

Scheme 91
  1. Recover the refrigerant with a recovery/recycling/charging station (see «REFRIGERANT RECOVERY»(ref-220611-S19543847392006022100000) ).
  2. Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(ref-220600-S34694565962006022100000) ).
  3. Remove the bolts, then disconnect the discharge line (A) and the A/C condenser line (B) from the A/C condenser. Plug or cap the lines immediately after disconnecting them to avoid moisture and dust contamination.
  4. Remove the bolts and mounting brackets (A), then remove the A/C condenser (B) by lifting it up. Be careful not to damage the radiator and A/C condenser fins when removing the A/C condenser.
  5. Install the A/C condenser in the reverse order of removal, and note these items: If you're installing a new A/C condenser, add refrigerant oil (DENSO ND-OIL 8) (see «A/C REFRIGERANT OIL REPLACEMENT»(ref-220611-S28467203692006022100000) ). Replace the O-rings with new ones at each fitting, and apply a thin coat of refrigerant oil before installing them. Be sure to use the correct O-rings for HFC-134a (R-134a) to avoid leakage. Immediately after using the oil, reinstall the cap on the container, and seal it to avoid moisture absorption. Do not spill the refrigerant oil on the vehicle; it may damage the paint; if the refrigerant oil contacts the paint, wash it off immediately. Be careful not to damage the radiator or the A/C condenser fins when installing the A/C condenser. Charge the system (see «SYSTEM CHARGING»(ref-220611-S02990373832006022100000) ).

Scheme 92

Scheme 92: Receiver/Dryer Desiccant Replacement
  1. Remove the A/C condenser (see «A/C CONDENSER REPLACEMENT»(ref-220611-S19153300402006022100000) ).
  2. Remove the cap (A) from the bottom of the A/C condenser, then remove the O-rings (B), the filter (C) and the desiccant (D).
  3. Install the desiccant in the reverse order of removal, and note these items: Replace the O-rings with new ones, and apply a thin coat of refrigerant oil (DENSO ND-OIL 8) before installing them. Be sure to use the correct O-rings for HFC-134a (R-134a) to avoid leakage.
