Component Location Index
| WARNING | SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (lf HVAC maintenance is required) The Element SRS includes a driver's airbag in the steering wheel hub, a passenger's airbag in the dashboard above the glove box, seat belt tensioners in the front seat belt retractors, seat belt buckle tensioners in the front seat belt buckles, and side airbags in the front seat-backs. Information necessary to safely service the SRS is included in this information. To avoid rendering the SRS inoperative, which could lead to personal injury or death in the event of a severe frontal or side collision, all SRS service work must be performed by an authorized Honda dealer. Improper service procedures, including incorrect removal and installation of the SRS, could lead to personal injury caused by unintentional deployment of the airbags and/or side airbags. Do not bump or impact the SRS unit, front impact sensors, side impact sensors when the ignition switch is ON (II), or for at least 3 minutes after the ignition switch is turned OFF; otherwise, the system may fail in a collision, or the airbags may deploy. SRS electrical connectors are identified by yellow color coding. Related components are located in the steering column, front console, dashboard, dashboard lower panel, in the dashboard above the glove box, in the front seats, and around the floor. Do not use electrical test equipment on these circuits. |
Scheme 93
Scheme 94
Scheme 95
Special Tool Required
Leak detector, Honda Tool and Equipment YGK-H-10PM, commercially available
| WARNING | Compressed air mixed with R-134a forms a combustible vapor. The vapor can burn or explode causing serious injury. Never use compressed air to pressure test R-134a service equipment or vehicle air conditioning systems. |
| CAUTION | Air conditioning refrigerant or lubricant vapor can irritate your eyes, nose, or throat. Be careful when connecting service equipment. Do not breathe refrigerant or vapor. |
Use only service equipment that is U.L.-listed and is certified to meet the requirements of SAE J2210 to remove HFC-134a (R-134a) from the air conditioning system.
If accidental system discharge occurs, ventilate work area before resuming service.
R-134a service equipment or vehicle air conditioning systems should not be pressure tested or leak tested with compressed air.
Additional health and safety information may be obtained from the refrigerant and lubricant manufacturers.
Scheme 96
- Connect an R-134a refrigerant recovery/recycling/charging station (A) to the high-pressure service port (B) and the low-pressure service port (C), as shown, following the equipment manufacturer's instructions.
- Open high pressure valve to charge the system to the specified capacity, then close the supply valve, and remove the charging system couplers. Select the appropriate units of measure for your refrigerant charging station. Refrigerant Capacity: 500 to 550 g 0.50 to 0.55 kg 1.10 to 1.21 lbs 17.6 to 19.4 oz
- Check the system for leaks using an R-134a refrigerant leak detector with an accuracy of 14 g (0.5 oz) per year or better.
- If you find leaks that require the system to be opened (to repair or replace hoses, fittings, etc.), recover the system.
- After checking and repairing leaks, the system must be evacuated.
