Power Mirror Actuator Replacement

Removal

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. Remove the these items: Mirror holder (see «MIRROR HOLDER REPLACEMENT»(ref-360116-S27534304642010042600000) ) Power mirror (see «POWER MIRROR REPLACEMENT»(ref-360116-S36118072792010042600000) )
2. Disconnect the power mirror 6P (or 13P)* connector from the power mirror. *: With Driving Position Memory System (DPMS)
3. Cut the mirror actuator wires with the wire cutter.
4. Remove the gasket (A), then remove the screw and retainer clip (B) from the mirror (C).
5. Remove the cover (A).
6. Remove the three screws, separate the housing (B) from the bracket (C).
7. Remove the two screws (A) and actuator housing (B) from the housing (C).
8. Remove the four screws (D) and the actuator (E) from the actuator housing. Installation
9. Install the new actuator to the housing in the reverse order of step 7 .
10. Route the wire harness of a new actuator through the hole in the bracket (A).
11. Reassemble the mirror in the reverse order of removal. Apply LOCTITE to the three screws (B) and tighten to 4.4 N.m (0.45 kgf.m, 3.2 lbf.ft).
12. Route the wire harness (A) of the new actuator through the hole in the retainer clip (B) and the gasket (C).
13. Insert the mirror actuator wires into the original terminal locations. With DPMS Without DPMS
14. Apply cushion tape (A) to seal the wire harness.
15. Install the retainer clip and gasket in the reverse order of removal.
16. Reassemble in the reverse order of disassembly. Be careful not to break the mirror holder when reinstalling it to the actuator (see «MIRROR HOLDER REPLACEMENT»(ref-360116-S27534304642010042600000) ).
17. Reinstall the mirror assembly on the door.
18. Operate the power mirror to make sure it works smoothly.
