Mirror System (V6): Removal & Installation Honda Crosstour I

Power Mirror Replacement

Note. Take care not to scratch the door.

Scheme 2

Scheme 3

1. Remove the door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(ref-360114-S30434507362010042600000) ).
2. Disconnect the power mirror connector (A).
3. While holding the power mirror, remove the nuts securing the mirror.
4. While holding the power mirror (A), squeeze the retaining tabs (B) on the connector clips (C), then push out to remove the power mirror.
5. Install the mirror in the reverse order of removal, and note these items: Make sure the connectors are plugged in properly. Push the clips on the cover into place securely.

Mirror Holder Replacement

Note. Put on gloves to protect your hands. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 4

Scheme 5

Scheme 6

1. Carefully push on the top edge of the mirror holder (A) by hand.
2. Put a shop towel in the opening between the bottom edge of the mirror holder and the mirror housing (B) to prevent scratches. Insert a flat-tip screwdriver to the guide notches (C) of the mirror holder, and release the bottom hooks (D).
3. Apply heat with a heat gun to the gap between the mirror holder (A) and the mirror housing (B). Carefully pull out the bottom edge of the mirror holder to separate the adhesive (C), and then release the side hooks (D). NOTE: Do not heat the plastic parts too much or you may damage them.
4. Separate the mirror holder from the actuator (E) by releasing the hooks (F), and disconnect the mirror defogger terminals (G).
5. Before reinstalling the mirror holder to the inner holder actuator (A) on the actuator, check the actuator rods (8) and the actuator boots (C). NOTE: Make sure each actuator rods is inserted into the actuator securely, and each actuator boots is fully seated on the actuator.
6. Reconnect the mirror defogger terminals (D).
7. Reattach the hooks of the mirror holder to the actuator, then position the mirror holder on the actuator. Carefully push on the side hooks of the mirror holder until the mirror holder locks into place securely.
8. Check the actuator operation.

Scheme 7

Scheme 8

1. Remove the mirror holder (see «MIRROR HOLDER REPLACEMENT»(ref-360116-S27534304642010042600000) ).
2. From the mirror holder opening, release the hooks (A) of the mirror housing cover (B).
3. Release the hooks (A), then remove the mirror housing cover (B).
4. Install the mirror housing cover in the reverse order of removal, and push the hooks into place securely.

Scheme 9

Scheme 10

1. Turn the rearview mirror base (A) 90 °.
2. Slide the rearview mirror base (A) down toward the bottom of the windshield to detach it from the spring (B) in the mount (C).
3. If necessary, remove the spring from the mount.
4. Install the rearview mirror in the reverse order of removal.

Scheme 11

Scheme 12

Scheme 13

1. Remove the rearview mirror harness cover (A). Pry out the cover to release the hooks (B). Slide the cover rearward. release the cover from the hooks (C) of the rearview mirror harness cover base (D).
2. Disconnect the rearview mirror connector (A).
3. Loosen the TORX screw with a TORX T20 bit, then slide the rearview mirror (A) rearward and off the mount (B).
4. Install the mirror in the reverse order of removal, and note these items: Before installing the mirror, remove the TORX screw, and apply medium strength liquid thread lock to it. Make sure the connector is plugged in properly. Push the hooks into place securely.
