Upper Dashboard Support Gusset Torque

Note. Take care not to scratch the body.

Scheme 2

Scheme 2: Upper Dashboard Support Gusset Torque

Rear Damper Gusset Torque

Note. Take care not to scratch the body.

Scheme 3

Scheme 3: Rear Damper Gusset Torque

Note. Before removing the subframe, make a mark where the subframe lines up with the body for reinstallation. After loosening the subframe mounting bolts, be sure to replace them with new ones. When installing, align both installation reference holes in the subframe with both reference holes in the body using a screwdriver or tapered punch as a guide. After reinstallation all removed parts, check and adjust the front wheel alignment (see WHEEL ALIGNMENT ).

Scheme 4

Scheme 4: Front Subframe Torque

Loosely install new front subframe mounting bolts, then tighten the bolts to the specified torque in the sequence shown.

Note. After loosening the subframe mounting bolts, be sure to replace them with new ones. When installing, align both installation reference holes in the subframe with both reference holes in the body using a screwdriver or tapered punch as a guide.
