DTC P1259: VTEC System Malfunction Honda Civic VII

Special Tools Required

1. Pressure gauge adaptor 07NAJ-P07010A
2. A/T low pressure gauge w/panel 07406-0070300
3. A/T pressure hose 07406-0020201
4. A/T pressure hose, 2,210 mm 07MAJ-PY4011A
5. A/T pressure adaptor 07MAJ-PY40120
6. Oil pressure hose 07ZAJ-S5AA200

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

1. Reset the ECM/PCM (see «HOW TO RESET THE ECM/PCM»(ref-173106-S10389340332005031000000) ).
2. Check the engine oil level, and refill if necessary.
3. Start the engine. Hold the engine at 3,000 rpm with no load (in Park or neutral) unit the radiator fan comes on.
4. Road test the vehicle: Accelerate in 1st gear to an engine speed over 4,000 rpm. Hold the engine speed for at least 2 seconds. If DTC P1259 is not repeated during the first road test, repeat this test 2 more times. Is DTC P1259 indicated? YES - Go to step 5. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the VTEC solenoid valve, at the VTEC oil pressure switch, and at the ECM/PCM.
5. Turn the ignition switch OFF.
6. Remove the resonator (see «RESONATOR REMOVAL/INSTALLATION»(ref-173123-S23337851512005031000000) ).
7. Disconnect the VTEC oil pressure switch 2P connector.
8. Check for continuity between the VTEC oil pressure switch 2P connector terminals No. 1 and No. 2. Is there continuity? YES - Go to step 9. NO - Replace the VTEC oil pressure switch.
9. Turn the ignition switch ON (II).
10. Measure voltage between VTEC oil pressure switch 2P connector terminal No. 1 and body ground. Is there battery voltage? YES - Go to step 15 . NO - Go to step 11.
11. Measure voltage between ECM/PCM connector terminal B9 and body ground. Is there battery voltage? YES - Repair open in the wire between the VTEC oil pressure switch and the ECM/PCM (B9). NO - Go to step 12.
12. Turn the ignition switch OFF.
13. Disconnect ECM/PCM connector B (24P).
14. Check for continuity between ECM/PCM connector terminal B9 and body ground. Is there continuity? YES - Repair short in the wire between the VTEC oil pressure switch and the ECM/PCM (B9). NO - Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/, then recheck (see «ECM/PCM UPDATING, SUBSTITUTION AND REPLACEMENT»(ref-173106-S42338946762005031000000) ). If the symptom/indication goes away with a known-good ECM/, replace the original ECM/PCM.
15. Measure voltage between VTEC oil pressure switch 2P connector terminals No. 1 and No. 2. Is there battery voltage? YES - Go to step 16. NO - Repair open in the wire between the VTEC oil pressure switch and G101.
16. Turn the ignition switch OFF.
17. Disconnect the VTEC solenoid valve 1P connector.
18. Check for resistance between VTEC solenoid valve 1P connector and body ground. Is there 14-30 ohms? YES - Go to step 19. NO - Replace the VTEC solenoid valve (see «VTEC Solenoid Valve Test»(ref-173119-S01634280032005031000000) ).
19. Remove the VTEC oil pressure switch (A), and install the special tools as shown, then reinstall the VTEC oil pressure switch.
