COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Brake Fluid Level Switch | In master cylinder reservoir cover. |
| Engine Compartment Fuse/Relay Box | Right rear corner of engine compartment, above strut tower. (Scheme 5) |
| Ground G201 | Right front corner of engine compartment. |
| Ground G301 | In left front corner of engine compart. |
| Ground G401 | Behind left side of dash, behind kick panel. |
| Ground G511 | Rear, center of car, below liftgate/trunk latch. |
| Ground G561 | In front, center of trunk, on upper panel. |
| Integrated Control Unit | On fuse/relay block behind left side of instrument panel. see scheme 2and see scheme 3. |
| Oil Pressure Switch | On engine block, to rear of alternator. see scheme 12 |
| Parking Brake Switch | Below parking brake lever. see scheme 13 |
| Passenger Compartment Fuse/Relay Box | Below left side of instrument panel. see scheme 2and see scheme 3. |
| Seat Belt Switch | In seat belt buckle. |
COMPONENT LOCATIONS
