Generators & Regulators: Other Honda Accord VI

CHARGING CIRCUIT

If the charging system indicator does not illuminate or does not go off, or the battery is dead or low, test the following items in the order below.

1. Battery
2. Charging System Indicator
3. Alternator/Regulator Circuit
4. Alternator Control System

BRUSHES

Measure the length of both brushes "A" with a vernier caliper "B". (Scheme 42) If either brush is shorter than the service limit, replace the brush assembly. If brush length is OK, go to ROTOR SLIP RING.

Scheme 42

RECTIFIER

Check for continuity in each direction, between the B terminal "A" and P terminals "B", and between the E terminal "C" and P terminals of each diode pair. (Scheme 43)for 2.3L or (Scheme 44) for 3.0L. All diodes should have continuity in only one direction. Because the rectifier diodes are designed to allow current to pass in only one direction, and the rectifier is made up of 8 diodes (4 pairs) (6 diodes (3 pairs) for 2000-03 models), you must test each diode in both directions for continuity with an ohmmeter that has diode checking capability: a total of 16 checks (12 checks for 2000-03 models). If any diode is faulty, replace the rectifier assembly (Diodes are not available separately). If all the diodes are OK, go to BRUSHES inspection.

Scheme 43

Scheme 44

ROTOR SLIP RING

1. Check that there is continuity between the slip rings. If there is continuity, go to next step. If there is no continuity, replace the alternator.
2. Check that there is no continuity between each slip ring and the rotor and the rotor shaft. If there is no continuity, go to «STATOR»(ref-138691-S18695736822003040100000) test. If there is continuity, replace the alternator.

Scheme 45

STATOR

1. Check that there is continuity between each pair of leads. If there is continuity, go to next step. If there is no continuity, replace the alternator.
2. Check for no continuity between each lead and the coil core. If there is no continuity, go to next step. If there is continuity, replace the alternator.
3. Be careful not to get any grease or oil on the slip rings during reassembly.
4. If you remove the pulley, tighten locknut to specification. See «TORQUE SPECIFICATIONS»(ref-138691-S20793581092003040100000)

Scheme 46

ALTERNATOR-A/C COMPRESSOR BELT

For alternator-a/c compressor belt, see ALTERNATOR-A/C COMPRESSOR BELT under ADJUSTMENTS.
