TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Negative Battery Cable-To-Battery Bolt | 13 (17) | |
| Starter Mounting Bolts | ||
| Diesel | 35 (47) | |
| Gas | 37 (50) | |
| INCH Lbs. (N.m) | ||
| Positive Battery Cable-To-Solenoid Nut (Diesel) | 97 (11) | |
| Positive Battery Cable-To-Solenoid Nut (Gas) | 89 (10) | |
| Solenoid Mounting Screws (Diesel) | 25 (2.8) | |
| Starter Shield Bolts (Gas) | 27 (3.0) | |
| Starter Shield Nut (Gas) | 44 (5.0) | |
| Starter Solenoid "S" Terminal Nut | 18 (2.0) | |
| Starter Through-Bolts (Diesel) | 97 (11) | |
| Starter-To-Starter Bracket Nut (Diesel) | 71 (8.0) | |
