Scheme 75
Scheme 75: Engine Covers and Component Assemblies (1 of 2) (LF1, LFW or LFX)
| Callout | Component Name |
|---|
| 1 | Right Camshaft Cover Assembly |
| 2 | Ignition Coil Bolt |
| 3 | Ignition Coil |
| 4 | Spark Plug |
| 5 | Intake Manifold Assembly |
| 6 | Left Camshaft Cover Assembly |
| 7 | Fuel Rail Noise Shield |
| 8 | Fuel Pump Cover |
| 9 | Fuel Pump Cover Bolt |
| 10 | Engine Flywheel |
| 11 | Engine Flywheel Bolt |
| 12 | Engine Assembly |
| 13 | Oil Pan Assembly |
| 14 | Engine Front Cover Assembly |
| 15 | Crankshaft Balancer |
| 16 | Crankshaft Balancer Bolt |
| 17 | Crankshaft Position Sensor Heat Shield Bolt - Large |
| 18 | Crankshaft Position Sensor Heat Shield |
| 19 | Crankshaft Position Sensor Heat Shield Bolt - Small |
Scheme 76
Scheme 76: Engine Covers and Component Assemblies (2 of 2) (LF1, LFW or LFX)
| Callout | Component Name |
|---|
| 1 | Water Outlet Bolt |
| 2 | Water Outlet |
| 3 | Water Outlet O-ring |
| 4 | Water Outlet Seal |
| 5 | Knock Sensor Bolt |
| 6 | Knock Sensor |
| 7 | Engine Coolant Heater Assembly |
| 8 | Crankshaft Position Sensor Bolt |
| 9 | Crankshaft Position Sensor |
| 10 | Crankshaft Position Sensor O-ring |
| 11 | Right Cylinder Head Assembly |
| 12 | Right Cylinder Head Gasket |
| 13 | Lower Fuel Rail Noise Shield |
| 14 | Engine Cooling Thermostat Gasket |
| 15 | Engine Cooling Thermostat |
| 16 | Engine Cooling Thermostat Housing |
| 17 | Engine Cooling Thermostat Bolt - Short |
| 18 | Engine Cooling Thermostat Housing Bolt - Long |
| 19 | Fuel Feed Pipe Assembly |
| 20 | Fuel Feed Pipe Assembly Bolt |
| 21 | Fuel Feed Intermediate Pipe Assembly |
| 22 | Fuel Pump Gasket |
| 23 | Fuel Pump O-ring Seal |
| 24 | Fuel Pump |
| 25 | Fuel Pump Bolt |
| 26 | Left Cylinder Head Assembly |
| 27 | Left Cylinder Head Gasket |
| 28 | Oil Level Indicator |
| 29 | Oil Level Indicator Handle O-ring |
| 30 | Oil Level Indicator Tube Bolt |
| 31 | Oil Level Indicator Tube |
| 32 | Oil Level Indicator Tube O-ring |
| 33 | Oil Filter Adapter Assembly |
| 34 | Engine Short Block Assembly |
| 35 | Oil Pump Assembly |
| 36 | Timing Drive Assembly |
Scheme 77
Scheme 77: Camshaft Cover Assembly
| Callout | Component Name |
|---|
| 1 | Ignition Coil |
| 2 | Ignition Coil Bolt |
| 3 | Spark Plug |
| 4 | Left Camshaft Housing Cover Insulator |
| 5 | Left Camshaft Cover PCV Fitting |
| 6 | Left Camshaft Cover PCV Fitting O-ring |
| 7 | Left Camshaft Cover |
| 8 | Oil Fill Cap |
| 9 | Oil Fill O-ring |
| 10 | Oil Fill Tube |
| 11 | Left Camshaft Cover Gasket |
| 12 | Camshaft Cover Spark Plug Port Seal |
| 13 | Camshaft Cover Bolt |
| 14 | Camshaft Cover Bolt Insulator |
| 15 | Right Camshaft Cover Gasket |
| 16 | Right Camshaft Cover |
| 17 | Right Camshaft Cover PCV Fitting Orifice |
| 18 | Ignition Coil Bolt Thread Insert |
| 19 | Right Camshaft Housing Cover Insulator |
Scheme 78
Scheme 78: Camshaft Timing Components
| Callout | Component Name |
|---|
| 1 | Primary Timing Chain Tensioner Bolt |
| 2 | Left Secondary Timing Chain Shoe Bolt |
| 3 | Right Secondary Timing Chain Tensioner |
| 4 | Right Secondary Timing Chain Tensioner Gasket |
| 5 | Right Secondary Timing Chain Shoe |
| 6 | Secondary Timing Chain |
| 7 | Camshaft Position Actuator Bolt |
| 8 | Exhaust Camshaft Position Actuator |
| 9 | Camshaft Position Actuator Thrust Washer |
| 10 | Intake Camshaft Position Actuator |
| 11 | Right Secondary Timing Chain Guide |
| 12 | Left Camshaft Intermediate Drive Shaft Sprocket |
| 13 | Camshaft Intermediate Drive Shaft Sprocket Bolt |
| 14 | Left Secondary Timing Chain Shoe |
| 15 | Left Secondary Timing Chain Tensioner Gasket |
| 16 | Left Secondary Timing Chain Tensioner |
| 17 | Left Secondary Timing Chain Guide |
| 18 | Lower Primary Timing Chain Guide |
| 19 | Lower Primary Timing Chain Guide Bolt |
| 20 | Crankshaft Sprocket |
| 21 | Primary Timing Chain |
| 22 | Right Camshaft Intermediate Drive Shaft Sprocket |
| 23 | Upper Primary Timing Chain Guide |
| 24 | Primary Timing Chain Tensioner Gasket |
| 25 | Primary Timing Chain Tensioner |
Scheme 79
Scheme 79: Intake Manifold (LF1, LFW or LFX)
| Callout | Component Name |
|---|
| 1 | EVAP Solenoid |
| 2 | PCV Tube O-ring Seal |
| 3 | PCV Tube |
| 4 | MAP Sensor Bolt |
| 5 | MAP Sensor |
| 6 | Upper Intake Manifold |
| 7 | Upper Intake Manifold Bolt |
| 8 | Throttle Body Gasket |
| 9 | Throttle Body |
| 10 | Throttle Body Bolt |
Scheme 80
Scheme 80: Fuel Rail (LF1, LFW or LFX)
| Callout | Component Name |
|---|
| 1 | Fuel Rail Bolt |
| 2 | Fuel Pressure Sensor |
| 3 | Fuel Injector Retainer |
| 4 | Fuel Injector O-ring Seal |
| 5 | Fuel Injector Spacer |
| 6 | Fuel Injector |
| 7 | Fuel Injector Teflon Seal |
| 8 | Fuel Rail |
Scheme 81
Scheme 81: Cylinder Head Assemblies
| Callout | Component Name |
|---|
| 300 | Left Cylinder Head |
| 301 | Right Cylinder Head |
| 302 | Left Cylinder Head Gasket |
| 303 | Right Cylinder Head Gasket |
| 310 | Cylinder Head Bolt |
| 311 | Cylinder Head Front Bolt |
| 313 | Cylinder Head Coolant Hole Threaded Plug |
| 318 | Spark Plug Sleeve |
| 319 | Cylinder Head Oil Gallery Expansion Plug - 14 mm |
| 320 | Exhaust Valve |
| 321 | Intake Valve |
| 322 | Valve Rocker Arm Assembly |
| 323 | Hydraulic Valve Lash Adjuster Assembly |
| 324 | Valve Stem Oil Seal |
| 325 | Valve Spring |
| 326 | Valve Spring Cap |
| 327 | Valve Stem Key |
| 328 | Cylinder Head Camshaft Front Thrust Bearing Cap |
| 328 | Cylinder Head Camshaft Front Thrust Bearing Cap |
| 329 | Camshaft Oil Seal Ring |
| 330 | Left Exhaust Camshaft |
| 331 | Left Intake Camshaft |
| 332 | Right Intake Camshaft |
| 333 | Right Exhaust Camshaft |
| 336 | Cylinder Head Camshaft Cap - Intermediate |
| 337 | Cylinder Head Camshaft Cap Bolt |
| 339 | Cylinder Head Oil Gallery Check Valve |
| 711 | Engine Coolant Temperature Sensor |
Scheme 82
Scheme 82: Engine Front Cover
| Callout | Component Name |
|---|
| 1 | Water Pump Pulley Bolt |
| 2 | Water Pump Pulley |
| 3 | Water Pump Assembly |
| 4 | Water Pump Pulley Gasket |
| 5 | Camshaft Position Actuator Solenoid Valve Seal |
| 6 | Camshaft Position Sensor Bolt |
| 7 | Camshaft Position Sensor |
| 8 | Camshaft Position Sensor O-ring Seal |
| 9 | Camshaft Position Actuator Solenoid Valve Bolt |
| 10 | Camshaft Position Actuator Solenoid Valve |
| 11 | Engine Front Cover Gasket |
| 12 | Engine Front Cover Locating Pin |
| 13 | Engine Front Cover |
| 14 | Engine Front Cover Bolt |
| 15 | Engine Front Cover Seal |
| 16 | Crankshaft Balancer |
| 17 | Crankshaft Balancer Bolt |
| 18 | Engine Front Cover Bolt |
| 19 | Water Pump Bolt |
Scheme 83
| Callout | Component Name |
|---|
| 151 | Lower Primary Timing Chain Guide |
| 154 | Lower Primary Timing Chain Guide Bolt |
| 463 | Oil Pump Housing |
| 464 | Oil Pump Cover |
| 465 | Oil Pump Driven Gear |
| 466 | Oil Pump Drive Gear |
| 468 | Oil Pump Cover Bolt |
| 470 | Oil Pressure Relief Valve Bore Plug |
| 471 | Oil Pressure Relief Valve Spring |
| 472 | Oil Pressure Relief Valve |
| 474 | Oil Pressure Relief Valve Bore Plug Retainer Clip |
| 475 | Oil Pump Bolt |
Scheme 84
Scheme 84: Engine Block Assembly
| Callout | Component Name |
|---|
| 1 | Crankshaft |
| 2 | Crankshaft Key |
| 3 | Crankshaft Lower Bearing |
| 4 | Crankshaft Bearing Cap |
| 5 | Crankshaft Bearing Cap Outboard Bolt |
| 6 | Crankshaft Bearing Cap Inboard Bolt |
| 7 | Crankshaft Bearing Thrust Cap |
| 8 | Piston Oil Nozzle Bolt |
| 9 | Piston Oil Nozzle |
| 10 | Oil Pan Locating Pin |
| 11 | Crankshaft Bearing Cap Side Bolt - Long |
| 12 | Engine Block Oil Gallery Threaded Plug - 14 mm |
| 13 | Crankshaft Rear Oil Seal Housing Assembly |
| 14 | Crankshaft Rear Oil Seal Housing Assembly Bolt |
| 15 | Transaxle Locating Pin |
| 16 | Piston and Connecting Rod Assembly |
| 17 | Engine Block Coolant Drain Threaded Plug - 14 mm |
| 18 | Engine Block Core Coolant Expansion Plug - 34.3 mm |
| 19 | Cylinder Head Locating Pin |
| 20 | Engine Block |
| 21 | Engine Block Oil Gallery Expansion Plug- 14 mm |
| 22 | Engine Front Cover Stud |
| 23 | Engine Block Oil Gallery Threaded Plug - 20 mm |
| 24 | Engine Block Oil Gallery Expansion Plug - 10 mm |
| 25 | Crankshaft Bearing Cap Side Bolt - Short |
| 26 | Crankshaft Upper Thrust Bearing #3 |
| 27 | Crankshaft Upper Bearing |
Scheme 85
Scheme 85: Piston, Rings, Bearing and Connecting Rod
| Callout | Component Name |
|---|
| 200 | Connecting Rod |
| 201 | Connecting Rod Bolt |
| 202 | Connecting Rod Bushing |
| 203 | Connecting Rod Bearing |
| 210 | Piston |
| 211 | Piston Pin |
| 212 | Piston Pin Retainer |
| 213 | Piston Upper Compression Ring |
| 214 | Piston Lower Compression Ring |
| 215 | Piston Oil Control Rail Ring |
| 216 | Piston Oil Control Ring Spacer |
Scheme 86
Scheme 86: Oil Pan Assembly
| Callout | Component Name |
|---|
| 1 | Oil Pan Baffle Scraper |
| 2 | Oil Pan Baffle Scraper Bolt |
| 3 | Oil Pump Suction Pipe Seal |
| 4 | Oil Pump Suction Pipe Bolt |
| 5 | Oil Pump Suction Pipe |
| 6 | Oil Pan |
| 7 | Oil Pan Bolt - Long |
| 8 | Oil Pan Bolt |
| 9 | Oil Pan Drain Plug Seal |
| 10 | Oil Pan Drain Plug |
Scheme 87
Scheme 87: Oil Filter Adapter
| Callout | Component Name |
|---|
| 440 | Oil Filter Adapter |
| 441 | Oil Filter Adapter Gasket |
| 442 | Oil Filter Adapter Bolt |
| 443 | Oil Filter Adapter Bolt - Long |
| 445 | Oil Filter Fitting |
| 449 | Oil Filter |
| 728 | Engine Oil Pressure Sensor |
| 729 | Engine Oil Pressure Sensor O-ring |
Vehicle Identification Number
The Vehicle Identification Number (VIN) Derivative is located in two places on the engine and is a nine digit number stamped or laser etched onto the block at the vehicle assembly plant. If reading the identification number the following information can be obtained
- The first digit identifies the vehicle division.
- The second digit is the model year.
- The third digit identifies the assembly plant.
- The fourth through ninth digits are the last six digits of the Vehicle Identification Number (VIN).
Scheme 88
The engine block is marked with the VIN on a pad area on the left rear side (1).
Scheme 89
The engine block is marked with the VIN on a pad area on the center lower right side (1).
