Engine Mechanical - 2.4L: Maintenance GMC Terrain I

Mechanical 23 illustrations ~217 words

Adhesives, Fluids, Lubricants, and Sealers

ApplicationType of MaterialGM Part Number
United StatesCanada
# 6 Intake Rear Camshaft CapSealant1237852188901148
Balance Shaft Bearings5W-301929300019286321
Cam Lobes5W-301929300019286321
Crank Sensor O-ring5W-301929300019286321
Cylinder Bores5W-301929300019286321
Cylinder Head PlugsThreadlocker1234538210953489
Engine Block Threaded PlugsSealant1234600410953480
Engine Block to BedplateSealant1237852188901148
Engine Oil5W-301929300019386321
Fuel Injector O-rings5W-301929300019386321
Fuel Injector Tip Insulators, for Multiple Port Injection Only5W-301929300019386321
Hydraulic Lash AdjustersLubricant8886258688862827
Ignition CoilsLubricant1926090119260902
Intake and Exhaust Valve StemsLubricant8886258688862827
Main BearingsLubricant8886258688862827
Oil Filter Cap- Threads and O-ring Lead-in Chamfers5W-301929300019286321
Oil Level Indicator Tube O-ringLubricant8886258688862827
Oil Pan to Bedplate JointSealant1237852188901148
Oil Pump- Pump Elements5W-301929300019286321
Oxygen Sensor ThreadsAnti-seize8886247788862478
Piston Pin to Piston/Rod- Pin Bores of Piston and Rod5W-301929300019286321
Rod Bearings- Rod Pins of Crankshaft5W-301929300019286321
Thread Repair Cutting OilLubricant1052864992881
Thread RepairCleaner8886265088901247
Timing Chain Guide Bolt Access Hole PlugThreadlocker1234538210953489
ValvesParts Immersion Solvent1234536810953514
Valve Rocker Arm/Valve TipLubricant12345501992704
Water Feed Tube O-ringsLubricant1926090119260902
Water Pump Drain PlugSealant1234600410953480

Adhesives, Fluids, Lubricants, and Sealers

Scheme 15

Scheme 15: Engine Block- Front View
Scheme 15: Engine Block- Front View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M8 x 1.2521020620720820923.50.9318.50.73
2M12 x 1.7585585685785885933.51.3226.51.04
3M10 x 1.521521121221321424.50.9619.50.77
4M6 x 1205201202203204200.787160.63

Engine Block- Front View

Scheme 16

Scheme 16: Engine Block- Back View
Scheme 16: Engine Block- Back View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M8 x 1.25210206207208209180.709THRU
2M10 x 1.5215211212213214291.161THRU
3M12 x 1.75855856857858859391.53533.51.32
4M16 x 1.5860861862863864210.827150.59

Engine Block- Back View

Scheme 17

Scheme 17: Engine Block- Right Side View
Scheme 17: Engine Block- Right Side View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M6 x 120520120220320420.50.807160.63
2M10 x 1.521521121221321423.50.92518.50.73
3M12 x 1.7586585685785885919.50.76812.50.49

Engine Block- Right Side View

Scheme 18

Scheme 18: Engine Block- Left Side View
Scheme 18: Engine Block- Left Side View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M6 x 120520120220320420.50.80716.50.65
2M10 x 1.521521121221321423.50.925180.71
3M8 x 1.25210206204720820930.51.20122.50.89
4M12 x 1.7586585685785885915.5.06112.50.49

Engine Block- Left Side View

Scheme 19

Scheme 19: Engine Block- Bottom View
Scheme 19: Engine Block- Bottom View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M8 x 1.25210206207208209281.102220.87
2M10 x 1.5514511N/A512513602.36253.52.11

Engine Block- Bottom View

Scheme 20

Scheme 20: Engine Block- Top View
Scheme 20: Engine Block- Top View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M8 x 1.2521020620720820923.50.92518.50.73
2M11 x 1.5507504N/A505506113.34.461107.34.22
3M12 x 1.7586585685785885913.50.53112.50.49

Engine Block- Top View

Scheme 21

Scheme 21: Lower Crankcase- Front View
Scheme 21: Lower Crankcase- Front View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M8 x 1.2521020620720820923.50.92518.50.73
2M8 x 1.2521020620720820930.51.20125.51.00

Lower Crankcase- Front View

Scheme 22

Scheme 22: Lower Crankcase- Back View
Scheme 22: Lower Crankcase- Back View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M10 x 1.521521121221321429.51.161THRU

Lower Crankcase- Back View

Scheme 23

Scheme 23: Lower Crankcase- Bottom View
Scheme 23: Lower Crankcase- Bottom View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M8 x 1.2521020620720820923.50.92518.50.73

Lower Crankcase- Bottom View

Scheme 24

Scheme 24: Lower Crankcase- Right View
Scheme 24: Lower Crankcase- Right View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M10 x 1.5215211212213214341.339271.063

Lower Crankcase- Right View

Scheme 25

Scheme 25: Lower Crankcase- Left View
Scheme 25: Lower Crankcase- Left View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M8 x 1.25210211212213214341.339271.063

Lower Crankcase- Left View

Scheme 26

Scheme 26: Cylinder Head- Top View
Scheme 26: Cylinder Head- Top View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M6 x 1205852N/A203204240.945200.787
2M6 x 1205201202203204200.787160.63
3M14 x 1.75854857N/A858859THRUTHRU
4M8 x 1.25854853N/A208209301.182271.063

Cylinder Head- Top View

Scheme 27

Scheme 27: Cylinder Head- Intake Manifold Deck View
Scheme 27: Cylinder Head- Intake Manifold Deck View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth MaximumTap Depth Maximum
EN 42385-850MMINMMIN
1M6 x 1205201202203204200.787160.63
2M8 x 1.25210206207208209200.787160.63
3M8 x 1.25205201202203204160.630120.473

Cylinder Head- Intake Manifold Deck View

Scheme 28

Scheme 28: Cylinder Head- Exhaust Manifold Deck View
Scheme 28: Cylinder Head- Exhaust Manifold Deck View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M6 x 1205201202203204200.78160.63
2M8 x 1.25210206207208209250.984200.78

Cylinder Head- Exhaust Manifold Deck View

Scheme 29

Scheme 29: Cylinder Head- Front View
Scheme 29: Cylinder Head- Front View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth (Maximum)Tap Depth (Maximum)
EN 42385-850MM(IN)MM(IN)
1M6 x 1205201202203204200.787160.63
2M8 x 1.25210206207208209250.984200.787
3M22 x 1.5No Service Tools AvailableTHRUTHRU

Cylinder Head- Front View

Scheme 30

Scheme 30: Cylinder Head- Back View
Scheme 30: Cylinder Head- Back View
Service Call OutThread SizeInsertDrillCounterbore ToolTapDriverDrill Depth MaximumTap Depth Maximum
EN 42385-850MMINMMIN
1M8 x 1.25210206207208209250.984200.787
2M12 x 1.75865856857858859180.709140.551
3M6 x 1205201202203204200.787160.63

Cylinder Head- Back View

Scheme 31

Scheme 31: Cylinder Head and Components
Scheme 31: Cylinder Head and Components
CalloutComponent Name
1Camshaft Position Actuator Solenoid Valve - Exhaust
2Camshaft Position Actuator Solenoid Valve Bolt
3Camshaft Position Actuator Solenoid Valve - Intake
4Upper Intake Manifold Sight Shield Grommet
5Ball Stud
6Ignition Coil Bolt
7Ignition Coil Bolt Retainer
8Ignition Coil
9Spark Plug
10Camshaft Cover Bolt
11Camshaft Cover Bolt Retainer
12Camshaft Cover
13Camshaft Housing Cover Insulator
14Camshaft Housing Cover Insulator Bolt
15Camshaft Cover Seal
16Camshaft Cover Seal
17Camshaft Bearing Cap Bolt
18Camshaft Bearing Front Cap
19Camshaft Bearing Cap
20Camshaft Bearing Front Cap
21Camshaft Rear Cap Bolt
22Intake Camshaft Rear Cap
23Camshaft Position Sensor Bolt
24Camshaft Position Sensor
25Camshaft Position Sensor O-Ring
26Exhaust Camshaft
27Intake Camshaft
28Roller Finger Follower
29Hydraulic Lash Adjuster
30Cylinder Head Bolt
31Engine Coolant Air Bleed Fitting
32Hydraulic Lash Adjuster
33Roller Finger Follower
34Valve Keys
35Valve Spring Retainer
36Valve Spring
37Valve Stem Seal
38Small Cylinder Head Bolt
39Cylinder Head
40Valve
41Timing Chain Guide Bolt Access Hole Plug
42Front Lift Bracket Bolt
43Front Lift Bracket
44Valve
45Camshaft Position Sensor Bolt
46Camshaft Position Sensor
47Camshaft Position Sensor O-Ring
48High Pressure Fuel Pump Roller Lifter
49Cylinder Head Gallery Plug
50Rear Lift Bracket
51Rear Lift Bracket Bolt
52Cylinder Head Cover Plate
53Cylinder Head Cover Plate Bolt
54Fuel Injector Retainer
55Fuel Injector Bushing
56Fuel Injector Seal
57Multiport Fuel Injector
58Fuel Injector Spacer
59Fuel Injector O-Ring
60Fuel Injection Fuel Pressure Sensor Assembly
61Multiport Fuel Injection Fuel Rail
62Fuel Injector Wiring Harness Bolt
63Fuel Injector Wiring Harness
64Fuel Injector Wiring Harness Bolt

Scheme 32

Scheme 32: Intake Manifold and Components
Scheme 32: Intake Manifold and Components
CalloutComponent Name
1Oil Fill Cap
2Intake Manifold Cover
3Oil Fill Tube Assembly
4Oil Fill Cap O-Ring
5Fuel Pump Housing Seal
6Fuel Pump Gasket
7Fuel Pump Assembly
8Fuel Pump Insulator
9Fuel Pump Cover
10Fuel Pump Cover Bolt
11Fuel Pump Cover Nut
12Fuel Feed Intermediate Pipe
13Low Pressure Fuel Pipe Assembly, model dependent
14Low Pressure Fuel Pipe Assembly Bolt
15Manifold Absolute Pressure (MAP) Sensor Bolt
16MAP Sensor
17MAP Sensor O-Ring
18Intake Manifold Nut
19Throttle Body
20Intake Manifold Stud
21Intake Manifold Insulator Bolt
22Intake Manifold Insulator
23Oil Indicator Tube
24Oil Indicator Tube Bolt
25Oil Indicator Tube O-Ring
26Oil Indicator
27Oil Indicator O-Ring
28Intake Manifold
29Fuel Injection Fuel Rail Noise Insulator
30Evaporative (EVAP) Emission Canister Purge Tube Assembly
31EVAP Emission Canister Purge Solenoid Valve

Scheme 33

Scheme 33: Exhaust Manifold and Components
Scheme 33: Exhaust Manifold and Components
CalloutComponent Name
1Secondary Air Injection Bolt
2Secondary Air Injection Check Stud
3Secondary Air Injection Pipe Assembly
4Secondary Air Injection Stud
5Secondary Air Injection Check Valve Gasket
6Secondary Air Injection Assembly
7Secondary Air Injection Bolt
8Secondary Air Injection Assembly Nut
9Exhaust Manifold Heat Shield Bolt
10Exhaust Manifold Heat Shield Bolt
11Exhaust Manifold Heat Shield Bolt
12Exhaust Manifold Heat Shield
13Oxygen Sensor
14Block Heater Bolt
15Block Heater
16Exhaust Manifold Nut
17Exhaust Manifold
18Exhaust Manifold Gasket
19Exhaust Manifold Stud

Scheme 34

Scheme 34: Engine Block and Components
Scheme 34: Engine Block and Components
CalloutComponent Name
1Water Pump to Engine Block Seal
2Water Pump
3Water Transfer Pipe O-ring Seals
4Water Transfer Pipe
5Coolant Temperature Sensor
6Thermostat Housing to Block Gasket
7Thermostat Housing
8Thermostat
9Thermostat Gasket
10Thermostat Housing Cap Bolt
11Thermostat Housing Cap
12Water Pipe Support Bracket
13Water Pipe Support Bracket Bolt Stud
14Water Pipe Support Bracket Bolt
15Cylinder Head Gasket
16Piston Ring Assembly
17Piston Assembly
18Connecting Rod
19Connecting Rod Bearing
20Connecting Rod Cap Bolt
21Cylinder Head Alignment Pin
22Oil Filter Cap
23Oil Filter Cap O-Ring
24Oil Filter
25Engine Block Gallery Plug
26Engine Block to Transaxle Alignment Pin
27Crankshaft Position Sensor
28Crankshaft Position Sensor Bolt
29Oil Pressure Switch
30Knock Sensor
31Piston Oil Nozzle
32Engine Block
33Crankshaft Thrust Bearing - Upper
34Crankshaft Bearing - Upper
35Crankshaft
36Crankshaft Thrust Bearing - Lower
37Crankshaft Bearing - Lower
38Crankshaft Rear Seal
39Flywheel
40Flywheel to Crankshaft Bolt
41Lower Crankcase
42Lower Crankcase Perimeter Bolt
43Starter
44Starter Bolt
45Engine Oil Pan Alignment Pins
46Engine Oil Pan
47Engine Oil Pan Long Bolt
48Engine Oil Pan Bolt
49Engine Oil Pan Drain Plug
50Lower Crankcase Main Bearing Bolt

Scheme 35

Scheme 35: Timing Chain and Components
Scheme 35: Timing Chain and Components
CalloutComponent Name
1Timing Chain Tensioner Body
2Timing Chain Tensioner Washer
3Timing Chain Tensioner O-Ring Seal
4Timing Chain Tensioner Plunger
5Adjustable Timing Chain Guide
6Adjustable Timing Chain Guide Bolt
7Fixed Timing Chain Guide Bolt
8Fixed Timing Chain Guide
9Friction Washer
10Timing Chain Drive Sprocket
11Timing Chain Oil Nozzle Bolt
12Timing Chain Oil Nozzle
13Timing Chain
14Camshaft Position Actuator Bolt
15Exhaust Camshaft Position Actuator
16Upper Timing Chain Guide
17Upper Timing Chain Guide Bolt
18Intake Camshaft Position Actuator
19Exhaust Balance Shaft Assembly Bolt
20Intake Balance Shaft Assembly Bolt
21Exhaust Balance Shaft Assembly
22Intake Balance Shaft Assembly
23Balance Shaft Rear Bearing
24Balance Shaft Drive Chain Tensioner Assembly Bolt
25Balance Shaft Drive Chain Tensioner Assembly
26Adjustable Balance Shaft Drive Chain Guide Bolt
27Adjustable Balance Shaft Drive Chain Guide
28Balance Shaft Drive Chain Guide Bolt
29Balance Shaft Drive Chain Guide
30Balance Shaft Drive Chain
31Balance Shaft Drive Chain Guide Bolt
32Balance Shaft Drive Chain Guide
33Water Pump Drive Sprocket Bolt
34Water Pump Drive Sprocket
35Balance Shaft Drive Sprocket
36Engine Front Cover Alignment Pins
37Engine Front Cover Gasket
38Oil Pump Cover Bolt
39Oil Pump Cover
40Oil Pump Outer Gerotor
41Oil Pump Inner Gerotor
42Engine Front Cover
43Engine Front Cover Bolt
44Crankshaft Front Seal
45Crankshaft Balancer
46Crankshaft Balancer Washer
47Crankshaft Balancer Bolt
48Oil Pressure Relief Valve Plug
49Oil Pressure Relief Valve O-Ring Seal
50Oil Pressure Relief Valve Spring
51Oil Pressure Relief Valve Plunger
52Water Pump Bolt
53Engine Front Cover Access Plate Gasket
54Engine Front Cover Access Plate
55Engine Front Cover Access Plate Bolt
56Belt Tensioner Bolt
57Belt Tensioner

Scheme 36

Scheme 36: Engine Identification (LAF, LEA, or LUK)
Scheme 36: Engine Identification (LAF, LEA, or LUK)

Identification can be made through the use of the Broadcast Code label on the engine (1) and the use of the partial VIN etched in one of two places - the primary location is on the starter motor flange (2). The secondary location is the oil filter bowl.

Scheme 37

Scheme 37
Scheme 37
  1. Barcode (1)
  2. Sequence Number (2)
  3. Day (3)
  4. Month (4)
  5. Year (5)
  6. Engine Assembly Plant (6)
  7. Broadcast Code (7)
  8. Part Designation (8)
  9. Engine Assembly Number (9)
  10. Broadcast Code (10)

The partial VIN identifies the specific vehicle by sequence number.

More articles — Engine Mechanical - 2.4L
