Transfer Case - Nvg 263-NP1: Specifications GMC Sierra 3500

Transfer Case 7 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Crossmember Bolt70 N.m52 lb ft
Encoder Motor Cover Screws
Long Screw3 N.m26 lb in
Short Screw2 N.m18 lb in
Transfer Case Adapter Bolt50 N.m37 lb ft
Transfer Case Adapter Nut50 N.m37 lb ft
Transfer Case Drain/Fill Plug20 N.m15 lb ft
Transfer Case Encoder Motor Bolt20 N.m15 lb ft
Transfer Case Shield Bolt20 N.m15 lb ft
Transfer Case Speed Sensor15 N.m11 lb ft
Transmission Mount Bolt47 N.m35 lb ft
Transmission Mount Nut40 N.m30 lb ft

Fastener Tightening Specifications

Capacities - Approximate Fluid

ApplicationSpecification
MetricEnglish
Dexron® III Automatic Transmission Fluid GM P/N 12346143 (Canadian P/N 10952622)1.9 liters2.0 quarts

Capacities - Approximate Fluid

Scheme 35

Scheme 35: Transfer Case Control Schematics
Scheme 35: Transfer Case Control Schematics

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38: Transfer Case Control Component Views
Scheme 38: Transfer Case Control Component Views
CalloutComponent Name
1C350
2Vehicle Speed Sensor (VSS) Connector
3Vehicle Speed Sensor (VSS)
4Transfer Case
5Transfer Case Encoder Motor
6Transfer Case Encoder Motor Connector

Scheme 39

Scheme 39
Scheme 39
CalloutComponent Name
1I/P Harness
2Transfer Case Shift Control Module Connectors
3Transfer Case Shift Control Module
4Instrument Panel

Scheme 40

Scheme 40
Scheme 40
CalloutComponent Name
1Transfer Case Shift Control Switch
2Instrument Panel Switch and Deflector Housing

Scheme 41

Scheme 41
Scheme 41
CalloutComponent Name
1C150
2Frame
3Front Axle Actuator
4Front Axle Actuator Connector
