Transfer Case - Nvg 261-NP2: Specifications GMC Sierra 3500

Transfer Case 4 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Control Rod Adjusting Bolt15 N.m11 lb ft
Crossmember Bolt70 N.m52 lb ft
Gear Shift Indicator Switch27 N.m20 lb ft
Transfer Case Adapter Bolt50 N.m37 lb ft
Transfer Case Adapter Nut50 N.m37 lb ft
Transfer Case Control Lever Bezel Screw2 N.m18 lb in
Transfer Case Drain/Fill Plug20 N.m15 lb ft
Transfer Case Shield Bolt/Screw20 N.m15 lb ft
Transfer Case Control Lever Bolt12 N.m106 lb in
Transfer Case Speed Sensor15 N.m11 lb ft
Transmission Mount Bolt47 N.m35 lb ft
Transmission Mount Nut40 N.m30 lb ft

Fastener Tightening Specifications

Capacities - Approximate Fluid

LubricantSpecification
MetricEnglish
Dexron® III Automatic Transmission Fluid, GM P/N 12346143 (Canadian P/N 10952622)1.9 liters2.0 quarts

Capacities - Approximate Fluid

Scheme 52

Scheme 52: Transfer Case Control Schematics
Scheme 52: Transfer Case Control Schematics

Scheme 53

Scheme 53: Transfer Case Control Component Views
Scheme 53: Transfer Case Control Component Views
CalloutComponent Name
1C350
2Transfer Case Shift Control Switch Connector
3Vehicle Speed Sensor (VSS)
4Transfer Case - NVG 261 - NP2

Scheme 54

Scheme 54
Scheme 54
CalloutComponent Name
1Ground 110 (G110)
2Vent Tube
3Vent Tube Connection
4Front Axle Actuator
5Front Axle Actuator Connector
6Left Inner Fender

Scheme 55

Scheme 55
Scheme 55
CalloutComponent Name
1Vent Tube
2Vent Tube Connection
3Front Axle Actuator
4Front Axle Actuator Connector
5Front Drive Axle Assembly (Mount)
6Ground 110 (G110)
7Left Inner Fender
