Transmission 5.3l — Transfer case circuit, electronic GMC Sierra 2500

Components on these wiring diagrams 27

Click a component to highlight it on every diagram it appears on.

• 2-Hi Ind
• 4-Hi Ind
• 4-Lo Ind
• 4.3L
• 4.8L, 5.3L, 6.0L
• Auxiliary Battery Relay
• B+ Motor Motor Gnd
• Body Wiring Harness Junction Block
• Brake Control
• Control Module
• Data Link Connector
• Encoder Motor
• Encoder Rtn
• Engine Wiring Harness Junction Block
• Front Axle Actuator/ Switch
• Front Prop- Shaft Speed Sensor
• Ft Shaft Sig Ft Shaft Rtn
• Illumination Lamp
• Indicator Lamp
• Instrument — Cluster
• Module Gnd 4-Lo Ind 4-Hi Ind Neutral Ind Ft Axle Ctrl Rr Shaft Sig Rr Shaft Rtn
• Neutral Ind
• Powertrain
• Rear Prop- Shaft Speed Sensor Encoder Logic
• Splice Pack
• Transfer Case Select Switch
• Vehicle Control Module
