# Instrument illumination circuit

# Instrument illumination circuit

Interior lights — Instrument illumination circuit — Instrument illumination circuit. GMC Sierra 2500 (2000-2004)
Components on the diagram

    # Instrument illumination circuit (1 of 2)

    Interior lights — Instrument illumination circuit — Instrument illumination circuit (1 of 2). GMC Sierra 2500 (2000-2004)
    Components on the diagram

      # Instrument illumination circuit (1 of 3)

      Interior lights — Instrument illumination circuit — Instrument illumination circuit (1 of 3). GMC Sierra 2500 (2000-2004)
      Components on the diagram

        # Instrument illumination circuit (2 of 2)

        Interior lights — Instrument illumination circuit — Instrument illumination circuit (2 of 2). GMC Sierra 2500 (2000-2004)
        Components on the diagram

          # Instrument illumination circuit (2 of 3)

          Interior lights — Instrument illumination circuit — Instrument illumination circuit (2 of 3). GMC Sierra 2500 (2000-2004)
          Components on the diagram

            # Instrument illumination circuit (3 of 3)

            Interior lights — Instrument illumination circuit — Instrument illumination circuit (3 of 3). GMC Sierra 2500 (2000-2004)
            Components on the diagram
