Radio — Radio circuits GMC Savana Special G3500

Components on these wiring diagrams 31

Click a component to highlight it on every diagram it appears on.

• Antenna
• Convenience Center
• Dim Sig In Drain Rt Output Lt Output Audio Rtn Ground Line Battery
• Dim Sig Out Drain Rt Input Lt Input Audio Rtn Ground E&C Line Battery
• From Power Window Motor Breakout
• From Radio Speaker Breakout
• Gasoline
• I/P Fuse Block
• Into Radio Breakout Diesel
• Left Front Door Speaker
• Left Front Door Tweeter Speaker
• Left Overhead Speaker
• Left Rear Door Speaker
• Lf - Lf + Rf - Rf + Ground Dim Ctrl Illuminaton Pwr Antenna Ignition Battery
• Pillar
• Power Antenna Assembly
• Premium
• Radio I Fuse 17
• Radio-B Fuse 19
• Remote Compact Disk Player
• Right Front Door Speaker
• Right Front Door Tweeter Speaker
• Right Overhead Speaker
• Right Rear Door Speaker
• Speaker Breakout
• Vehicle Control Module
• Vehicle Speed Sensor Buffer
• Vss Signal
• Vss Signal Rr Rr Lr Lr
• W/O Upfitter
• Window Motor Breakout
