Wiring diagram: Headlights — Headlights circuit GMC Savana Special G3500

Components on these wiring diagrams 27

Click a component to highlight it on every diagram it appears on.

• 25 18 Headlamp Sw Sig Headlamp Lo Sig
• Ambient Light Sensor
• Body Control Module
• Computer Data Lines
• Drl 1 Drl 2 Fuse 67 Fuse 66
• Fusible Link 2
• Head 1 8
• Headlamp, Panel Dimmer Switch
• Ip Clstr Fuse 10
• Left High Beam Headlamp Left Headlamp
• Left Low Beam Headlamp
• Lo Beam Rly Ctrl
• Logic Instrument Panel Cluster
• Lt Lo Beam Fuse 53
• Park Brake Switch
• Park Brk Sw Sig
• Ppl 23 16 Lo Beam Ctrl Hi Beam Rly Ctrl
• Right Headlamp
• Right High Beam Headlamp
• Right Low Beam Headlamp
• Rt Hi Beam Fuse 52
• Rt Lo Lt Hi Beam Beam Fuse 54 Fuse 51
• Serial — Data
• System
• Turn Signal/ Multi-Function Switch
• Underhood Fuse Block
