Shift Interlock System: Removal & Installation GMC Savana H2500

Removal Procedure

Scheme 965

1. Disable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160357-S31046009912004021000000) .
2. Put the shift lever clevis into the neutral position.
3. Remove the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT - LEFT»(ref-176310-S40559658652005050300000) .
4. Disconnect the electrical connector.
5. Use a small screwdriver to pry the A/T shift lock control actuator away from the steering column jacket assembly and the cable shift cam assembly.
6. Remove the A/T shift lock control actuator.

Scheme 966

Scheme 967

1. Firmly install the A/T shift lock control actuator onto the steering column jacket assembly and the cable shift cam assembly.
2. Connect the electrical connector.
3. Adjust the A/T shift lock control actuator with the shift lever clevis in the neutral position: Pull out the tab (1) on the adjuster block side (2) of the A/T shift lock control actuator. Press on the adjuster block (2) to compress the internal adjuster spring which disengages the adjuster teeth. Slide the adjuster block (2) as far away from the actuator as possible. Lock the adjuster block (2) in place by pushing in on the tab (1).
4. Inspect the A/T shift lock control actuator for the following items: The A/T shift lock control actuator must lock the shift lever clevis when the shift lever clevis is put into the park position. Depress the brake pedal to move the shift lever out of the park position. The actuator will be energized. Readjust the A/T shift lock control actuator if needed.
5. Install the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT - LEFT»(ref-176310-S40559658652005050300000) .
6. Enable the SIR system. Refer to «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160357-S31046009912004021000000) .
