Transmission Fluid Temperature (TFT) Sensor Specifications
| Temperature | Temperature | Minimum Resistance | Nominal Resistance | Maximum Resistance | Signal |
|---|---|---|---|---|---|
| °F | °C | Ohms | Ohms | Ohms | Volts |
| 40 | 40 | 90636 | 100707 | 110778 | 5.00 |
| 22 | 30 | 47416 | 52684 | 57952 | 4.78 |
| 4 | 20 | 25809 | 28677 | 31545 | 4.34 |
| 14 | 10 | 14558 | 16176 | 17794 | 3.89 |
| 32 | 0 | 8481 | 9423 | 10365 | 3.45 |
| 50 | 10 | 5104 | 5671 | 6238 | 3.01 |
| 68 | 20 | 3164 | 3515 | 3867 | 2.56 |
| 86 | 30 | 2013 | 2237 | 2461 | 1.80 |
| 104 | 40 | 1313 | 1459 | 1605 | 1.10 |
| 122 | 50 | 876 | 973 | 1070 | 3.25 |
| 140 | 60 | 600 | 667 | 734 | 2.88 |
| 158 | 70 | 420 | 467 | 514 | 2.56 |
| 176 | 80 | 299 | 332 | 365 | 2.24 |
| 194 | 90 | 217 | 241 | 265 | 1.70 |
| 212 | 100 | 159 | 177 | 195 | 1.42 |
| 230 | 110 | 119 | 132 | 145 | 1.15 |
| 248 | 120 | 89.9 | 99.9 | 109.9 | 0.87 |
| 266 | 130 | 69.1 | 76.8 | 84.5 | 0.60 |
| 284 | 140 | 53.8 | 59.8 | 65.8 | 0.32 |
| 302 | 150 | 42.5 | 47.2 | 51.9 | 0.00 |
Transmission Fluid Temperature (TFT) Sensor Specifications
Fastener Tightening Specifications
| Application | Metric | English |
|---|---|---|
| Accumulator Cover to Case Bolt | 8.0-14.0 N.m | 6-10 lb ft |
| Case Extension to Case Bolt | 42.0-48.0 N.m | 31-35 lb ft |
| Case Extension to Case Bolt (4WD Shipping) | 11.2-22.6 N.m | 8.3-16.7 lb ft |
| Converter Cover Bolt | 10 N.m | 89 lb in |
| Converter Housing to Case Screw | 65.0-75.0 N.m | 48-55 lb ft |
| Cooler Pipe Connector | 35.0-41.0 N.m | 26-30 lb ft |
| Detent Spring to Valve Body Bolt | 20.0-27.0 N.m | 15-20 lb ft |
| Floorshift Control Bolt | 10 N.m | 89 lb in |
| Flywheel to Torque Converter Bolt | 63 N.m | 46 lb ft |
| Forward Accumulator Cover to Valve Body Bolt | 8.0-14.0 N.m | 6-10 lb ft |
| Heat Shield to Transmission Bolt | 17 N.m | 13 lb ft |
| Line Pressure Plug | 8.0-14.0 N.m | 6-10 lb ft |
| Manual Shaft to Inside Detent Lever Nut | 27.0-34.0 N.m | 20-25 lb ft |
| Negative Battery Cable Bolt | 15 N.m | 11 lb ft |
| Oil Level Indicator Bolt | 47 N.m | 35 lb ft |
| Oil Pan to Transmission Case Bolt | 11 N.m | 97 lb in |
| Oil Passage Cover to Case Bolt | 8-14.0 N.m | 6-10 lb ft |
| Park Brake Bracket to Case Bolt | 27.0-34.0 N.m | 20-25 lb ft |
| Park/Neutral Position Switch Screw | 3 N.m | 27 lb in |
| Plate to Case Bolt (Shipping) | 27.0-34.0 N.m | 20-25 lb ft |
| Plate to Converter Bolt (Shipping) | 27.0-34.0 N.m | 20-25 lb ft |
| Plug Assembly, Automatic Transmission Oil Pan (C/K) | 30-40 N.m | 22.1-29.5 lb ft |
| Plug Assembly, Automatic Transmission Oil Pan (Y) | 28-32 N.m | 20.7-23.6 lb ft |
| Pressure Control Solenoid Bracket to Valve Body Bolt | 8.0-14.0 N.m | 6-10 lb ft |
| Pump Assembly to Case Bolt | 26.0-32.0 N.m | 19-24 lb ft |
| Pump Cover to Pump Body Bolt | 20.0-27.0 N.m | 15-20 lb ft |
| Shift Cable Grommet Screw | 1.7 N.m | 15 lb in |
| Shift Control Cable Attachment | 20 N.m | 15 lb ft |
| Speed Sensor Retainer Bolt | 10.5-13.5 N.m | 7.7-10 lb ft |
| Stud, Automatic Transmission Case Extension (Y-car) | 18.0-22.0 N.m | 13-16 lb ft |
| TCC Solenoid Assembly to Case Bolt | 8.0-14.0 N.m | 6-10 lb ft |
| Transmission Fluid Pressure Manual Valve Position Switch to Valve Body Bolt | 8.0-14.0 N.m | 6-10 lb ft |
| Transmission Mount to Transmission Bolt | 50 N.m | 37 lb ft |
| Transmission Oil Cooler Pipe Fitting | 35.0-41.0 N.m | 26-30 lb ft |
| Transmission Oil Pan to Case Bolt | 9.5-13.8 N.m | 7-10 lb ft |
| Transmission to Engine Bolt | 47 N.m | 35 lb ft |
| Valve Body to Case Bolt | 8.0-14.0 N.m | 6-10 lb ft |
Fastener Tightening Specifications
Transmission General Specifications
| Name | Hydra-matic 4L60-E |
|---|---|
| RPO Codes | M30 |
| Production Location | Toledo, Ohio Romulus, MI Ramos Arizpe, Mexico |
| Vehicle Platform (Engine/Transmission) Usage | G |
| Transmission Drive | Longitudinally-Mounted Rear Wheel Drive |
| 1st Gear Ratio | 3.059:1 |
| 2nd Gear Ratio | 1.625:1 |
| 3rd Gear Ratio | 1.000:1 |
| 4th Gear Ratio | 0.696:1 |
| Reverse | 2.294:1 |
| Torque Converter Size (Diameter of Torque Converter Turbine) | 245 mm 258 mm 298 mm 300 mm |
| Pressure Taps | Line Pressure |
| Transmission Fluid Type | DEXRON® III |
| Transmission Fluid Capacity (Approximate) | 245 mm Converter Dry: 8.3 l (8.8 qt) 258 mm Converter Dry: 8.8 l (9.3 qt) 298 mm Converter Dry: 11.25 l (11.9 qt) 300 mm Converter Dry: 11.50 l (12.1 qt) |
Transmission General Specifications (1 Of 2)
| Name | Hydra-matic 4L60-E |
|---|---|
| Transmission Type: 4 | Four Forward Gears |
| Transmission Type: L | Longitudinal Mount |
| Transmission Type: 60 | Product Series |
| Transmission Type: E | Electronic Controls |
| Position Quadrant | P, R, N, (D), D, 2, 1 P, R, N, (D), 3, 2, 1 |
| Case Material | Die Cast Aluminum |
| Transmission Weight Dry (Approximate) | 245 mm Converter 65.4 kg (144.30 lb) 258 mm Converter 79.9 kg (176.6 lb) 298 mm Converter 70.5 kg (155.70 lb) 300 mm Converter 86.17 kg (190.5 lb) |
| Transmission Weight Wet (Approximate) | 245 mm Converter 72.4 kg (159.55 lb) 258 mm Converter 89.2 kg (197.7 lb) 298 mm Converter 80.5 kg (176.16 lb) 300 mm Converter 98.4 kg (218.0 lb) |
| Maximum Trailer Towing Capacity | 5 448 kg (12,000 lb) |
| Maximum Gross Vehicle Weight (GVW) | 3 900 kg (8,600 lb) |
Transmission General Specifications (2 Of 2)
Fluid Capacity Specifications
| Application | Metric | English |
|---|---|---|
| Pan Removal | 4.7 liters | 5 quarts |
| Overhaul | 10.6 liters | 11 quarts |
Fluid Capacity Specifications
Scheme 294
Torque Converter End Play Specifications
| Torque Converter Size | Specification |
|---|---|
| 245 mm (9.65 in) | 0.0-0.38 mm (0.0-0.015 in) |
| 258 mm (10.16 in) | 0.1-0.50 mm (0.004-0.020 in) |
| 298 mm (11.73 in) | 0.1-0.48 mm (0.004-0.019 in) |
| 300 mm (11.81 in) | 0.1-0.5 mm (0.004-0.020 in) |
Torque Converter End Play Specification
Scheme 295
Upshift Control and Torque Converter Clutch (TCC) Apply
The PCM calculates the upshift points based primarily on two inputs: throttle angle and vehicle speed. When the PCM determines that conditions are met for a shift to occur, the PCM commands the shift by closing or opening the ground circuit for the appropriate solenoid.
Perform the following steps
- Refer to the «Shift Speed»(ref-174512-S33850593312005050500000) table in this section and choose a throttle position of 12 percent, 25 percent or 50 percent. All throttle angles shown should be tested to cover the normal driving range.
- Monitor the following scan tool parameters: Throttle angle Vehicle speed Engine speed Output shaft speed Commanded gear Slip speed Solenoid states
- Place the gear selector in the OVERDRIVE position.
- Accelerate the vehicle using the chosen throttle angle. Hold the throttle steady.
- As the transmission upshifts, note the vehicle speed when the shift occurs for each gear change. There should be a noticeable shift feel or engine speed change within 1 to 2 seconds of the commanded gear change.
- Compare the shift speeds to the Shift Speed table. Refer to «Shift Speed»(ref-174512-S33850593312005050500000) . Shift speeds may vary slightly due to transmission fluid temperature or hydraulic delays in responding to electronic controls. Note any harsh, soft or delayed shifts or slipping. Note any noise or vibration.
- Repeat steps 1 through 6 to complete all throttle angles. Important: This transmission is equipped with an electronically controlled capacity clutch (ECCC). The pressure plate does not fully lock to the torque converter cover. Instead, the pressure plate maintains a small amount of slippage, about 20 RPM, in SECOND, THIRD and FOURTH gears, depending on the vehicle application. ECCC was developed to reduce the possibility of noise, vibration or chuggle caused by TCC apply. Typical apply speeds are 49-52 km/h (30-32 mph) in THIRD gear and 65-73 km/h (40-45 mph) in FOURTH gear. Full lockup is available at highway speeds on some applications. Important: The TCC will not engage until the engine is in closed loop operation and the vehicle speed is as shown in the Shift Speed table. Refer to «Shift Speed»(ref-174512-S33850593312005050500000) . The vehicle must be in a near-cruise condition, not accelerating or coasting, and on a level road surface.
- Check for TCC apply in THIRD and FOURTH gear. Note the TCC apply point. When the TCC - applies there should be a noticeable drop in engine speed and a drop in slip speed to below 100 RPM. If the TCC apply can not be detected: Check for DTCs. Refer to «Torque Converter Diagnosis Procedure»(ref-174512-S06326321952005040600000) . Refer to the «Shift Speed»(ref-174512-S33850593312005050500000) table for the correct apply speeds. Lightly tap and release the brake pedal. The TCC will release on most applications.
Torque Converter Diagnosis Procedure
The Torque Converter Clutch (TCC) is applied by fluid pressure, which is controlled by a PWM solenoid valve. This solenoid valve is located inside of the automatic transmission assembly. The solenoid valve is controlled through a combination of computer controlled switches and sensors.
Torque Converter Stator
The torque converter stator roller clutch can have two different malfunctions.
- The stator assembly freewheels in both directions.
- The stator assembly remains locked up at all times.
Torque Converter Clutch Shudder
The key to diagnosing Torque Converter Clutch (TCC) shudder is to note when it happens and under what conditions.
TCC shudder which is caused by the transmission should only occur during the apply or the release of the converter clutch. Shudder should never occur after the TCC plate is fully applied.
Indexing Torque Converter
To determine and correct a torque converter vibration, the following procedure may have to be performed several times to achieve the best possible torque converter to flywheel balance.
Scheme 296
- Raise and suitably support the vehicle.
- Rotate the torque converter one bolt position.
- Align the torque converter hub (2) in the engine crankshaft (3) and install the torque converter to flywheel bolts.
- Lower the vehicle.
- With the engine at idle speed and the transmission in PARK or NEUTRAL, observe the vibration. Refer to «Noise and Vibration Analysis»(ref-174512-S30931086142005040600000) . Repeat this procedure until you obtain the best possible balance.
- Install the transmission converter cover bolts and the cover.
Leak at the Torque Converter End
- Converter leak in the weld area
- Converter seal lip cut. Check the converter hub for damage
- Converter seal bushing moved forward and damaged
- Converter seal garter spring missing from the seal
- Porous casting of the transmission case or the oil pump
Scheme 297
- Overfilled system
- Water or coolant in the fluid. The fluid will appear milky
- Transmission case porous
- Incorrect fluid level indicator
- Plugged vent
- Drain-back holes plugged
- Mispositioned oil pump to case gasket, if equipped
Torque Converter Clutch (TCC) Slip With Stall/Stumble
| Checks | Causes |
|---|---|
| TCC Apply Valve | Stuck open |
Torque Converter Clutch (TCC) Slip With Stall/Stumble
Torque Converter Clutch (TCC) Intermittent - OK Cold/Slips Hot
| Checks | Causes |
|---|---|
| PWM Solenoid | Leaks |
| Regulator Apply Valve | Sticking valve |
| Converter Clutch Shift Valve | Sticking valve |
Torque Converter Clutch (TCC) Intermittent - OK Cold/Slips Hot
Torque Converter Clutch Pulse Width Modulation (TCC PWM) Solenoid, TCC Solenoid, and Wiring Harness
Tools Required : J 28458 Seal Protector Retainer Installer
Scheme 298
Scheme 299
Scheme 300
Scheme 301
Scheme 302
Scheme 303
Scheme 304
- Raise and support the vehicle.
- Remove the transmission oil pan and the filter. Refer to «Automatic Transmission Fluid/Filter Replacement»(ref-174512-S40755408992005040600000) .
- Disconnect the transmission harness 20-way connector from the transmission internal harness pass-through connector. Depress both tabs on the connector and pull straight up; do not pry the connector. Important: Removal of the valve body is not necessary for the following procedure.
- Remove the 1-2 accumulator assembly. Do not remove the spacer plate. Refer to «Accumulator Assembly, Spacer Plate, and Gaskets»(ref-174512-S02204008572005040600000) .
- Disconnect the internal wiring harness electrical connectors from the following components: Transmission fluid pressure switch (1) 1-2 shift control solenoid (2) 2-3 shift control solenoid (3) Pressure control solenoid (4) TCC PWM solenoid (5) 3-2 control solenoid (6)
- Remove the TCC PWM solenoid retainer.
- Remove the TCC PWM solenoid in order to access one of the TCC solenoid retaining bolts.
- Remove the pressure control solenoid retainer.
- Remove the pressure control solenoid.
- Remove the TCC solenoid retaining bolts and the valve body bolts which retain the internal wiring harness.
- Using J 28458 , release the pass-through electrical connector from the transmission case. Use the small end of the J 28458 over the top of the connector. Twist in order to release the four tabs retaining the connector. Pull the harness connector down through the transmission case.
- Remove the TCC solenoid (with O-ring seal) and wiring harness assembly from the transmission case.
- Inspect the TCC solenoid and wiring harness assembly for the following defects: Damage Cracked connectors Exposed wires Loose pins
Scheme 305
Scheme 306
Scheme 307
Scheme 308
Scheme 309
Scheme 310
- Install the wiring harness and TCC solenoid assembly with a new O-ring seal to the transmission.
- Install the pass-through electrical connector to the transmission case. CAUTION: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) .
- Install the valve body bolts which retain the internal wiring harness and install the TCC solenoid retaining bolts. Tighten Tighten the control valve body retaining bolts to 11 N.m (97 lb in). Tighten the TCC solenoid retaining bolts to 11 N.m (97 lb in).
- Install the pressure control solenoid. Ensure that the electrical tabs are facing outboard.
- Install the pressure control solenoid retainer and retaining bolt. Tighten Tighten the pressure control solenoid retaining bolt to 11 N.m (97 lb in).
- Install the TCC PWM solenoid to the control valve body.
- Install the TCC PWM solenoid retainer.
- Connect the internal wiring harness electrical connectors to the following components: Transmission fluid pressure switch (1) 1-2 shift control solenoid (2) 2-3 shift control solenoid (3) Pressure control solenoid (4) TCC PWM solenoid (5) 3-2 control solenoid (6)
- Install the 1-2 accumulator. Refer to «Accumulator Assembly, Spacer Plate, and Gaskets»(ref-174512-S02204008572005040600000) .
- Connect the transmission harness 20-way connector to the transmission pass-through connector. Align the arrows on each half of the connector and insert straight down.
- Install the transmission oil pan and filter. Refer to «Automatic Transmission Fluid/Filter Replacement»(ref-174512-S40755408992005040600000) .
- Lower the vehicle.
- Fill the transmission to the proper level with DEXRON® III transmission fluid. Refer to «Transmission Fluid Checking Procedure»(ref-174512-S22482294682005040600000) .
