TORQUE CONVERTER
Note. Torque converter is a sealed unit and must be serviced as a complete assembly.
TORQUE CONVERTER END PLAY CHECK
- Inspect torque converter for hub scoring, cracks or weld area cracks before checking end play. Install End Play Checking Tool(J-35138) on torque converter. (Scheme 12)
- Note end play of torque converter. End play must be within specification. See «TORQUE CONVERTER END PLAY SPECIFICATIONS»(ref-124191-S14493264582001100100000) table. Replace torque converter if end play is not within specification or damage to hub area exists.
| Converter Diameter: In. (mm) | End Play: In. (mm) |
|---|---|
| 9.65 (245.0) | .0-.020 (.0-.51) |
| 11.73 (298.0) | .0-.024 (.0-.61) |
TORQUE CONVERTER END PLAY SPECIFICATIONS
Scheme 12
TRANSMISSION SPECIFICATIONS
| Application | In. (mm) | ||
|---|---|---|---|
| Clearance | |||
| Forward Clutch | .030-.063 (.75-1.60) | ||
| Reverse Input Clutch | .040-.076 (1.02-1.93) | ||
| 3-4 Clutch | .035-.083 (.89-2.11) | ||
| End Play | |||
| Reaction & Input Planetary Pinion Gear | .008-.024 (.20-.61) | ||
| Torque Converter | |||
| 9.65" (245 mm) | .0-.020 (.0-.51) | ||
| 11.73" (298 mm) | .0-.024 (.0-.61) | ||
| Transmission | .005-.036 (.13-.91) | ||
| Height | |||
| Low-Reverse Clutch | 1.15-1.18 (29.2-29.9) | ||
TRANSMISSION SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Converter Housing Bolt | 55 (75) |
| Cooler Pipe Connector | 28 (38) |
| Detent Spring-To-Valve Body Bolt | 18 (24) |
| Extension Housing Bolt | 26 (35) |
| Fill Tube Bolt | 35 (47) |
| Manual Shaft-To-Detent Lever Nut | 23 (31) |
| Oil Pump Cover-To-Body Bolt | 18 (24) |
| Oil Pump-To-Case Bolt | 18 (24) |
| Park Bracket-To-Case Bolt | 23 (31) |
| Torque Converter-To-Flexplate Bolt | 46 (62) |
| Transmission-To-Engine Bolt | 35 (47) |
| INCH Lbs. (N.m) | |
| Accumulator Cover-To-Case Bolt | 96 (11) |
| Line Pressure Plug | 96 (11) |
| Oil Pan-To-Case Bolt | 96 (11) |
| Oil Passage Cover Bolt | 96 (11) |
| Pressure Switch Assembly | 96 (11) |
| Solenoid Bolt | 96 (11) |
| Speed Sensor Bolt | 96 (11) |
| Valve Body-To-Case Bolt (1) | 96 (11) |
| (1) Tighten valve body bolts in a spiral pattern starting in center of valve body. | |
| (1) | Tighten valve body bolts in a spiral pattern starting in center of valve body. |
TORQUE SPECIFICATIONS
