Engine Cooling System: Removal & Installation Ford Transit VII

Cooling System (Mechanical) 5 illustrations ~601 words

Removal and Installation

Note. The thermostat and thermostat housing are serviced as an assembly.

Pinpoint Test C

C3 KS
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-356777-S14337744002010022700000) .
  2. Loosen the 3 coolant pump pulley bolts. To install, tighten to 20 Nm (177 lb-in).
  3. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(ref-356779) .
  4. Remove the 3 coolant pump pulley bolts and the pulley.
  5. Remove the 3 coolant pump bolts and the coolant pump. To install, tighten to 10 Nm (89 lb-in).
  6. To install, reverse the removal procedure.
  7. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-356777-S14337744002010022700000) .

Scheme 2

Scheme 2: Radiator
ItemPart NumberDescription
18B274Upper radiator hose
28K276Radiator-to-degas bottle hose
3W700964Cooling fan motor and shroud bolt (2 required)
4W702846Lower air deflectors pin-type retainer (4 required)
58B384Lower air deflector
68B273Lower radiator hose
7W703555Lower radiator support bolt (4 required)
88A297Lower radiator support
919712A/C condenser core
108005Radiator

RADIATOR ITEM DESCRIPTION

Scheme 3

Scheme 3: Removal and Installation
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-356777-S14337744002010022700000) .
  2. Remove the 2 bolts, pin-type retainer and the LH front splash shield.
  3. Disconnect the upper radiator and degas bottle hoses from the radiator.
  4. Remove the cooling fan motor and shroud. For additional information, refer to «COOLING FAN MOTOR AND SHROUD»(ref-356777-S00869855202010022700000) .
  5. Remove the 2 cooling fan and shroud bolts from the radiator.
  6. Remove the 4 pin-type retainers and position the lower air deflector aside.
  7. Disconnect the lower radiator hose from the radiator.
  8. Remove the A/C tube bracket nut from the RH side of the lower radiator support. To install, tighten 9 Nm (80 lb-in).
  9. Position a jackstand below the lower radiator support to support the cooling module.
  10. Remove the 4 bolts and the lower radiator support. To install, tighten 25 Nm (18 lb-ft).
  11. Slide the radiator towards the LH side of vehicle to separate the radiator from the A/C condenser core and remove the radiator.
  12. To install, reverse the removal procedure.
  13. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-356777-S14337744002010022700000) .

Scheme 4

Scheme 4: Cooling Fan Motor and Shroud
ItemPart NumberDescription
114489Cooling fan motor and shroud resistor electrical connector (part of 14290)
214A624RH cooling fan motor electrical connector (part of 14290)
314A464LH cooling fan motor electrical connector (part of 14290)
4LH cooling fan motor wiring harness pin-type retainer (part of 14290)
5W700430Cooling fan motor and shroud nut (2 required)
68C607Cooling fan motor and shroud

COOLING FAN MOTOR AND SHROUD ITEM DESCRIPTION

  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-356737) .
  2. Disconnect the cooling fan motor and shroud resistor electrical connector.
  3. Disconnect the RH and LH cooling fan motor electrical connector. Detach the LH cooling fan motor wiring harness pin-type retainer.
  4. Remove the 2 nuts and the cooling fan motor and shroud. To install, tighten to 5 Nm (44 lb-in).
  5. To install, reverse the removal procedure.

Scheme 5

Scheme 5: Block Heater
ItemPart NumberDescription
114A464Block heater electrical connector
26A051Block heater

BLOCK HEATER ITEM DESCRIPTION

  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-356777-S14337744002010022700000) .
  2. Disconnect the block heater electrical connector.
  3. Remove the block heater. To install, tighten to 40 Nm (30 lb-ft).
  4. To install, reverse the removal procedure.
  5. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-356777-S14337744002010022700000) .

Scheme 6

Scheme 6: Degas Bottle
ItemPart NumberDescription
18100Pressure relief cap
28K276Degas bottle-to-radiator hose
38K012Degas bottle-to-coolant outlet hose
48K289Lower degas bottle hose-to-radiator
5W503931Degas bottle bolt
68C418Degas bottle mounting bracket
78K218Degas bottle

DEGAS BOTTLE ITEM DESCRIPTION

  1. Release the pressure in the cooling system by slowly turning the pressure relief cap one-half turn counterclockwise. When the pressure is released, remove the pressure relief cap.
  2. Using hose clamp pliers, clamp the lower degas bottle hose.
  3. Using a suction device, siphon the coolant from the degas bottle.
  4. Disconnect the degas bottle-to-radiator hose.
  5. Disconnect the degas bottle-to-coolant outlet hose.
  6. Disconnect the lower degas bottle hose-to-radiator.
  7. Remove the degas bottle bolt. To install, tighten to 8 Nm (71 lb-in).
  8. Release the degas bottle mounting bracket tab on the rear of the degas bottle and remove the degas bottle.
  9. To install, reverse the removal procedure.
  10. Fill the degas bottle. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-356777-S14337744002010022700000) for the recommended coolant mixture and fill level.
