Coolant Flow Diagram
Note. Black arrows indicate hot, white arrows indicate cold.
Scheme 12
| Item | Part Number | Description |
|---|---|---|
| 1 | 8K218 | Degas bottle |
| 2 | 8501 | Coolant pump |
| 3 | 6010 | Engine block |
| 4 | 8K289 | Lower degas bottle hose |
| 5 | 8575 | Thermostat housing |
| 6 | 6A642 | Engine oil cooler |
| 7 | 18C266 | Heater hose |
| 8 | 8B273 | Lower radiator hose |
| 9 | 8005 | Radiator |
| 10 | 8K276 | Degas bottle-to-radiator hose |
| 11 | 8A582 | Bypass hose |
| 12 | 8K556 | Coolant outlet |
| 13 | 8B274 | Upper radiator hose |
| 14 | 18K579 | Heater core inlet hose |
| 15 | 18K580 | Heater core outlet hose |
| 16 | 18478 | Heater core |
| 17 | 8K012 | Degas bottle-to-coolant adapter hose |
| 18 | 6090 | Cylinder head |
| 19 | 6051 | Cylinder head gasket |
ENGINE COOLING ITEM DESCRIPTION
Material
| Item | Specification |
|---|---|
| Motorcraft® Specialty Orange Engine Coolant with Bittering Agent (US); Motorcraft® Specialty Orange Engine Coolant (Canada) VC-3-B (US); CVC-3-B (Canada); or equivalent | WSS-M97B44-D |
ENGINE COOLING MATERIAL SPECIFICATION
Thermostat
A new thermostat should be installed only after the following tests and checks have been carried out
- Pinpoint Test A, B or C
- Thermostat Visual Inspection
| Item | Specification |
|---|---|
| Motorcraft® Specialty Orange Engine Coolant with Bittering Agent (US); Motorcraft® Specialty Orange Engine Coolant (Canada) VC-3-B (US); CVC-3-B (Canada); or equivalent | WSS-M97B44-D |
ITEM SPECIFICATION
| Item | Specification |
|---|---|
| Premium Cooling System Flush VC-1 | ESR-M14P7-A |
ITEM SPECIFICATION - COOLING SYSTEM FLUSHING
| WARNING | Always allow the engine to cool before opening the cooling system. Do not unscrew the coolant pressure relief cap when the engine is operating or the cooling system is hot. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. Failure to follow these instructions may result in serious personal injury. |
Note. To remove rust, sludge and other foreign material from the cooling system, use cooling system flush that is safe for use with aluminum radiators. For additional information, refer to SPECIFICATIONS . This cleaning restores cooling system efficiency and helps prevent overheating. A pulsating or reversed direction of flushing water will loosen sediment more quickly than a steady flow in the normal coolant flow direction. In severe cases where cleaning solvents will not clean the cooling system efficiently, it will be necessary to use the pressure flushing method using cooling system flusher. Dispose of old coolant and flushing water contaminated with antifreeze and cleaning chemicals in accordance with local, state or federal laws.
- Add premium cooling system flush to the cooling system and follow the directions on the package.
- Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-356777-S14337744002010022700000) .
- Remove the radiator. For additional information, refer to «RADIATOR»(ref-356777-S01304553332010022700000) .
- Backflush the radiator with the radiator in an upside-down position and a high-pressure hose in the lower hose location.
- Remove the thermostat housing. For additional information, refer to «THERMOSTAT HOUSING»(ref-356777-S38155983432010022700000) .
- Position a high-pressure water hose into the engine through the engine return and backflush the engine.
- Install the thermostat housing. For additional information, refer to «THERMOSTAT HOUSING»(ref-356777-S38155983432010022700000) .
- Install the radiator. For additional information, refer to «RADIATOR»(ref-356777-S01304553332010022700000) .
- Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-356777-S14337744002010022700000) .
| Item | Specification |
|---|---|
| Motorcraft® Specialty Orange Engine Coolant with Bittering Agent (US); Motorcraft® Specialty Orange Engine Coolant (Canada) VC-3-B (US); CVC-3-B (Canada); or equivalent | WSS-M97B44-D |
ITEM SPECIFICATION - THERMOSTAT HOUSING
Scheme 13
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | Knock Sensor (KS) electrical connector |
| 2 | 14A624 | KS electrical connector pin-type retainer |
| 3 | 18C266 | Heater hose |
| 4 | 8B273 | Lower radiator hose |
| 5 | W500015 | Thermostat housing bolt (3 required) |
| 6 | 8575 | Thermostat housing |
| 7 | 8K530 | Thermostat housing seal |
THERMOSTAT HOUSING ITEM DESCRIPTION
| Item | Specification |
|---|---|
| Motorcraft® Specialty Orange Engine Coolant with Bittering Agent (US); Motorcraft® Specialty Orange Engine Coolant (Canada) VC-3-B (US); CVC-3-B (Canada); or equivalent | WSS-M97B44-D |
ITEM SPECIFICATION - COOLANT PUMP
Scheme 14
| Item | Part Number | Description |
|---|---|---|
| 1 | W500221 | Coolant pump pulley bolt (3 required) |
| 2 | 8509 | Coolant pump pulley |
| 3 | W500015 | Coolant pump bolt (3 required) |
| 4 | 8501 | Coolant pump |
| 5 | 8507 | Coolant pump O-ring seal |
COOLANT PUMP ITEM DESCRIPTION
