Manual Climate Control Vacuum Application Chart
| Port Number | Line Color | Function | Function Selector Switch Position |
|---|
| MAX A/C | A/C | PANEL | OFF | PNL/ FLR | FLR | FLR/DEF | DEF |
| 1 | White | Outside/ recirculated air | V | NV | NV | V | NV | NV | NV | NV |
| 2 | Red | Full floor | NV | NV | NV | V | NV | V | NV | NV |
| 3 | Black | Source vacuum | V | V | V | V | V | V | V | V |
| 5 | Blue | Panel/ floor | NV | NV | NV | V | V | V | V | NV |
| 6 | Yellow | Defrost | V | V | V | NV | V | NV | NV | NV |
| V = vacuum NV = no vacuum |
MANUAL CLIMATE CONTROL VACUUM APPLICATION CHART
Scheme 89
Scheme 89: Electronic Automatic Temperature Control Vacuum Schematic
Scheme 90
Scheme 91
Scheme 91: Electronic Automatic Temperature Control Vacuum Connector End View
Scheme 92
Electronic Automatic Temperature Control Manual Override Vacuum Application Chart
| Port Number | Line Color | Function | Manual Override Selector Button |
|---|
| PANEL | OFF | PNL/ FLR | FLR | FLR/ DEF | DEF |
| 2 | Yellow | Defrost | V | NV | V | NV | NV | NV |
| 3 | Blue | Panel/ floor | NV | V | V | V | V | NV |
| 4 | Black | Source vacuum | V | V | V | V | V | V |
| 5 | White | Outside/ recirculated air | NV/V | V | NV/V | NV/V | NV/V | NV |
| 6 | Red | Full floor | NV | V | NV | V | NV | NV |
| V = vacuum NV = no vacuum |
