Removal and Installation
| WARNING | When repairing the starter motor (11002) or working underhood in the vicinity of the starter motor, note the heavy gauge input lead connected to the starter solenoid (11390) is hot at all times. Make sure the protective cap is installed over the terminal and is reinstalled after repairing. |
Scheme 16
Scheme 17
Scheme 18
Scheme 19
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-233724) .
- Raise and support the vehicle. For additional information, refer to «JACKING & LIFTING»(ref-233684) .
- Remove the bolts, pin-type retainers and the front splash shield.
- Remove the starter solenoid terminal cover.
- Remove the nuts and position the starter solenoid cables aside.
- Remove the bolts and the starter motor.
- To install, reverse the removal procedure. Install the upper and lower bolts finger-tight. Tighten the upper bolt to 25 Nm (18 lb-ft). Tighten the lower bolt to 25 Nm (18 lb-ft).
Removal
| WARNING | When repairing the starter motor (11002) or working underhood in the vicinity of the starter motor, note the heavy gauge input lead connected to the starter solenoid (11390) is hot at all times. Make sure the protective cap is installed over the terminal and is reinstalled after repairing. |
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-233724) .
- Raise and support the vehicle. For additional information, refer to «JACKING & LIFTING»(ref-233684) .
- Remove the bolts, pin-type retainers and the front splash shield.
- Remove the starter solenoid terminal cover.
- Remove the nuts and position the starter solenoid cables aside.
- Remove the nut and position the starter motor ground strap aside.
- Remove the upper starter motor nut and stud.
- Remove the bolt and the starter motor.
- To install, reverse the removal procedure. Install the upper starter stud and lower bolt finger-tight. Tighten the upper stud bolt to 25 Nm (18 lb-ft). Tighten the lower bolt to 25 Nm (18 lb-ft).
