Starting System: Other Ford Taurus IV рестайлинг

Starter 5 illustrations ~705 words

Starter Motor

The starter motor (11002)

  1. is a permanent-magnet, gear reduction, 12V DC motor.
  2. has an integral starter solenoid.

Starter Relay

The starter relay

  1. is a mini ISO relay that switches power to the starter solenoid to engage the starter motor.
  2. receives a START signal from the ignition switch (11572).
  3. is controlled by the powertrain control module (PCM).

Component Tests

WARNINGWhen repairing the starter motor or working underhood in the vicinity of the starter motor, be aware that the heavy gauge battery input lead at the starter solenoid is electrically hot at all times.
CAUTIONA protective cap or boot is provided over the battery input terminal on all vehicle lines and must be reinstalled after repairing. Be sure to disconnect the battery ground cable before repairing the starter motor.

Always make the 73III Automotive Meter connections at the component terminal rather than at the wiring end connector. Making a connection at the wiring end connector could result in false readings because the meter will not pick up a high resistance between the wiring connector and the component.

Scheme 27

Scheme 27: Starter Motor-Motor Feed Circuit

Scheme 28

Scheme 28
  1. Make sure the battery is fully charged; carry out a battery load test. For additional information, refer to «CHARGING SYSTEM - GENERAL INFORMATION»(ref-233727) .
  2. Disconnect the inertia fuel shutoff (IFS) switch (9341).
  3. Connect a remote starter switch between the starter solenoid S-terminal and the battery positive (+) terminal.
  4. Connect the 73III Automotive Meter positive lead to the battery positive (+) post. Connect the negative lead to the starter solenoid M-terminal.
  5. Engage the remote starter switch. Read and record the voltage. The voltage reading should be 0.5 volt or less.
  6. If the voltage reading is 0.5 volt or less, go to the «STARTER MOTOR-GROUND CIRCUIT»(ref-233698-S19335816882006052600000) component test.
  7. If the voltage reading is greater than 0.5 volt, this is an indication of excessive resistance in the connections, the positive battery cable or in the starter solenoid. Move the 73III Automotive Meter negative lead to the starter solenoid B-terminal and repeat the test. If the voltage reading at the B-terminal is lower than 0.5 volt, the concern is either in the connections at the starter solenoid or in the solenoid contacts.
  8. Remove the cables from solenoid B-, S- and M-terminals. Clean the cables and connections and reinstall the cables to the correct terminals. Repeat Steps 3 through 6. If the voltage drop reading is still greater than 0.5 volt when checked at the M-terminal or less than 0.5 volt when checked at the B-terminal, the concern is in the solenoid contacts. Install a new starter motor.
  9. If the voltage reading taken at the solenoid B-terminal is still greater than 0.5 volt after cleaning the cables and connections at the solenoid, the concern is either in the positive (+) battery cable connection or in the positive battery cable itself.
  10. Clean the positive (+) battery cable connection. If this does not solve the problem, install a new positive battery cable.

Starter Motor-Ground Circuit

A slow cranking condition can be caused by resistance in the ground or return portion of the cranking circuit. Check the voltage drop in the ground circuit as follows

Scheme 29

Scheme 29: Starter Motor-Ground Circuit
  1. Connect the 73III Automotive Meter positive lead to the starter motor housing (the connection must be clean and free of rust or grease). Connect the negative lead to the negative (-) battery terminal.
  2. Engage the remote starter switch and crank the engine. Read and record the voltage reading. The reading should be 0.2 volt or less.
  3. If the voltage drop is more than 0.2 volt, clean the negative cable connections at the battery, the body ground connections and the starter ground connection. Retest.
  4. If the voltage drop is greater than 0.2 volt, install a new cable. If the voltage reading is less than 0.2 volt and the engine still cranks slowly, install a new starter motor.

Scheme 30

Scheme 30: Starter Drive/Flywheel Ring Gear Inspection
  1. Remove the starter motor. For additional information, refer to «STARTER MOTOR - 3.0L (2V)»(ref-233698-S13604451162006052600000) or «STARTER MOTOR - 3.0L (4V)»(ref-233698-S31483921152006052600000) .
  2. Check the wear patterns on the starter drive gear and the flywheel ring gear. If the wear pattern is normal, install the starter motor. For additional information, refer to «STARTER MOTOR - 3.0L (2V)»(ref-233698-S13604451162006052600000) or «STARTER MOTOR - 3.0L (4V)»(ref-233698-S31483921152006052600000) .
  3. If the starter drive gear and the flywheel ring gear are not fully meshing and both of the gears are scored or damaged, install a new starter motor. For additional information, refer to «STARTER MOTOR - 3.0L (2V)»(ref-233698-S13604451162006052600000) or «STARTER MOTOR - 3.0L (4V)»(ref-233698-S31483921152006052600000) . If necessary, install a new flywheel. For additional information, refer to «ENGINE - 3.0L (2V)»(ref-233691) (3.0L 2V), or «ENGINE - 3.0L (4V)»(ref-233692) (3.0L 4V).

Scheme 31

Scheme 31
