GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Brake Pads | |
| Brake pad minimum thickness | 3.0 mm (0.118 in) |
| Brake pad maximum thickness variation (pad-to-pad) | 2.0 mm (0.079 in) |
| Brake pad maximum taper wear (in any direction) | 3.0 mm (0.118 in) |
| Brake Disc | |
| Front brake disc minimum thickness | 24.75 mm (0.97 in) |
| Minimum thickness to machine front brake disc | 25.35 mm (0.99 in) |
| Fluids | |
| High Performance DOT 3 Brake Fluid C6AZ-19542-AB (preferred fluid) | ESA-M6C25-A |
| High Performance DOT 4 Brake Fluid | SAE J1704 |
| Lubricants | |
| Silicone Brake Caliper Grease and Dielectric Compound WA-10 D7AZ-19A331-A | ESE-M1C171-A |
| High Temperature Nickel Anti-Seize Lubricant F6AZ-9L494-AA | ESE-M12A4-A |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Disc brake caliper bolt | 35 |
| Front brake hose bolt | 48 |
| Front disc brake caliper anchor plate | 103 |
| Disc brake caliper bleeder screw | 11 |
TORQUE SPECIFICATIONS
Front Disc Brake Components
Scheme 1
Disc Brake Caliper Components
Scheme 2
The front disc brake caliper (2C357)
- bolts to the front disc brake caliper anchor plate (2B134), which bolts to the front wheel knuckle.
- is a disc brake caliper locating pin, single piston design.
The front brake discs (1125)
- are of a ventilated full-cast design, with non-directional cooling fins.
- are bolted to the wheel hub (1104).
- are serviced with the disc brake caliper and front disc brake caliper anchor plate removed.
The front brake disc shield (2K005)
- is riveted to the front wheel knuckle.
- protects the front wheel bearings and inboard surface of the front brake disc.
The pads
- are housed in the front disc brake caliper anchor plate.
- are of a non-asbestos, semi-metallic composition.
