GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Brake shoe lining wear limit | 3.75 mm (0.154 in) |
| Drum inside diameter | Maximum diameter is molded into the brake drum |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Rear wheel cylinder bolts | 15 |
| Brake bleeder screw | 15 |
| Brake line-to-rear wheel cylinder fitting | 17 |
| ABS sensor bolt | 9 |
| Brake backing plate bolts | 70 |
TORQUE SPECIFICATIONS
The drum brake system
- is the single anchor type.
- has active self-adjustment.
- is split front and rear hydraulically.
Rear Brake
