HVAC System - Control Components: Removal & Installation Ford Taurus IV рестайлинг

Removal and Installation

All vehicles

Scheme 1

Scheme 2

1. Remove the integrated control panel. For additional information, refer to «CLIMATE CONTROL ASSEMBLY»(ref-233748-S39774374772006052600000) .
2. Remove the right-side lower instrument panel insulator.
3. Lower the glove compartment. Vehicles with EATC
4. Remove the 2 remote climate control module screws and position the module aside. All vehicles
5. Remove the temperature blend door linkage shield.
6. Remove the temperature blend door actuator (19E660). Disconnect the electrical connector. Remove the screws. Remove the temperature blend door actuator.
7. To install, reverse the removal procedure.

Scheme 3

1. Remove the right-side instrument panel insulator (046A42).
2. Remove the blower motor resistor (18591). Disconnect the electrical connector. Remove the screws. Remove the blower motor resistor.
3. To install, reverse the removal procedure.

Scheme 4

1. Remove the right-side instrument panel insulator.
2. Remove the blower motor speed control (19E624). Disconnect the vacuum line. Disconnect the electrical connectors. Remove the screws and the blower motor speed control.
3. To install, reverse the removal procedure.

Scheme 5

1. Remove the instrument panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-233744) .
2. Remove the screws.
3. Rotate and remove the air inlet door vacuum control motor (18A318).
4. To install, reverse the removal procedure.

1. Working through the driver footwell, remove the two screws and the shield.
2. Label and disconnect the two vacuum hoses. Remove the screw. Lift, rotate and remove the panel/floor door vacuum control motor (18A318) from the door lever.
3. To install, reverse the removal procedure.

Scheme 6

1. Remove the passenger air bag module. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-233728) .
2. Remove the defrost door vacuum control motor (18A318). Disconnect the vacuum line. Remove the screws.
3. Rotate and remove the vacuum control motor from the defrost door lever.
4. To install, reverse the removal procedure.

Scheme 7

1. Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-233744) .
2. Remove the right-side instrument panel insulator (046A24).
3. Working the passenger footwell, remove the floor console register duct vacuum control motor (18A318). Disconnect the vacuum hose. Remove the screws.
4. Rotate and remove the vacuum control motor from the floor console register duct door.
5. To install, reverse the removal procedure.

Scheme 8

Scheme 9

Scheme 10

1. Remove the right front tire and wheel assembly. For additional information, refer to «WHEELS & TIRES»(ref-233696) .
2. Remove the rear half of the right front fender splash shield.
3. Remove the bolt.
4. Disconnect the vacuum hose. Remove the vacuum reservoir and bracket (19A566).
5. To install, reverse the removal procedure.
