HVAC System - Control Components: Component Locations Ford Taurus IV рестайлинг

Heater 20 illustrations ~364 words

Special Tool(s)

SPECIAL TOOL DESCRIPTION Radio Removing Tool 415-001 (T87P-19061-A)

Scheme 11

Scheme 11: Special Tool(s)

All vehicles

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14
  1. Using the special tool, pull out the integrated control panel (18C858). Vehicles with manual climate control
  2. Label and disconnect the electrical connectors. Remove the integrated control panel. Vehicles with electronic automatic temperature control (EATC)
  3. Label and disconnect the electrical connectors and the in-car temperature sensor hose (19D888). Remove the integrated control panel. All vehicles
  4. To install, reverse the removal procedure.

Scheme 15

Scheme 15: Removal and Installation

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20
  1. Remove the integrated control panel. For additional information, refer to «CLIMATE CONTROL ASSEMBLY»(ref-233748-S39774374772006052600000) .
  2. Remove the right-side lower instrument panel insulator.
  3. Open the glove compartment. Pressing the tabs inward, lower the glove compartment towards the floor.
  4. Remove the screw.
  5. Remove the screw.
  6. Disconnect the remote climate control (RCC) module electrical connector.
  7. Remove the two nuts. Disconnect the plenum vacuum harness. Remove the RCC module (18C612).
  8. To install, reverse the removal procedure.

Scheme 21

Scheme 21: Removal and Installation

Scheme 22

Scheme 22
  1. Remove the integrated control panel (18C858). For additional information, refer to «CLIMATE CONTROL ASSEMBLY»(ref-233748-S39774374772006052600000) .
  2. Remove the knob (18519).
  3. Remove the screw. Rotating the blower motor switch counterclockwise, remove the blower motor switch (19986).
  4. To install, reverse the removal procedure.

Scheme 23

Scheme 23: Removal and Installation

Scheme 24

Scheme 24
  1. Remove the integrated control panel (18C858). For additional information, refer to «CLIMATE CONTROL ASSEMBLY»(ref-233748-S39774374772006052600000) .
  2. Remove the knob (18519).
  3. Remove the screw. Rotating the temperature control switch clockwise, remove the temperature control switch (19C733).
  4. To install, reverse the removal procedure.

Scheme 25

Scheme 25: Removal and Installation

Scheme 26

Scheme 26
  1. Remove the integrated control panel (18C858). For additional information, refer to «CLIMATE CONTROL ASSEMBLY»(ref-233748-S39774374772006052600000) .
  2. Remove the knob (18519).
  3. Disengage the retaining tabs. Remove the function selector switch (19B888).
  4. To install, reverse the removal procedure.

Scheme 27

Scheme 27: Removal and Installation

Scheme 28

Scheme 28

Scheme 29

Scheme 29
  1. Remove the four scrivets and the grille.
  2. Detach the ambient air temperature sensor (12A647).
  3. Disconnect the ambient air temperature sensor.
  4. To install, reverse the removal procedure.

Scheme 30

Scheme 30: Removal and Installation
  1. Remove the integrated control panel (18C858). For additional information, refer to «CLIMATE CONTROL ASSEMBLY»(ref-233748-S39774374772006052600000) .
  2. While pressing the retaining tabs inward, remove the in-car temperature sensor (19C734).
  3. To install, reverse the removal procedure.
