Engine Cooling System: Removal & Installation Ford Taurus IV рестайлинг

Installation

1. Connect the hoses to the coolant pump.
2. Position the coolant pump and install the mounting bolts. Tighten the bolts in two stages: Stage 1: Tighten to 10 Nm (89 lb-in). Stage 2: Tighten an additional 90 degrees.
3. Install the radiator bypass hose assembly.
4. Connect the ECT sensor electrical connector and attach the pin-type retainer.
5. Connect the upper radiator hose, the heater hose and thermostat housing hose.
6. Install the radiator upper front cooling tube bolt.
7. Install the lower cooling tube bolt.
8. Connect the heater hose to the bottom of the coolant pump.
9. Install the coolant pump belt. For additional information, refer to «ACCESSORY DRIVE»(ref-233714) .
10. Install the battery and the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-233724) .
11. Install the air cleaner assembly. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-233699) .
12. Fill and bleed the engine cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-233700-S21960513852006052600000) .

Removal and Installation

Note. The RH and LH cooling fans can be serviced individually. The LH cooling fan is shown, the RH is similar.

Scheme 11

Scheme 12

Scheme 13

1. Remove the distribution box and position aside.
2. Disconnect the fan electrical connector and detach the retainer.
3. Remove the bolt and the electrical cooling fan.
4. To install, reverse the removal procedure.

Scheme 14

Scheme 15

Scheme 16

1. Drain the coolant below the degas bottle. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-233700-S21960513852006052600000) .
2. Disconnect the upper hoses.
3. Disconnect the lower hose.
4. Remove the bolt and the nut, remove the degas bottle.
5. To install, reverse the removal procedure.
