Engine Cooling System: Component Locations Ford Taurus IV рестайлинг

Special Tool(s)

SPECIAL TOOL DESCRIPTION Pressure Test Kit 014-R1072 or equivalent 73III Automotive Meter 105-R0057 or equivalent Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool Battery/Antifreeze Tester 014-R1060 or equivalent

Scheme 18

Scheme 19

Scheme 20

SPECIAL TOOL DESCRIPTION RADKITPLUS 078-00497

Scheme 21

SPECIAL TOOL DESCRIPTION Disconnect Tool, Spring Lock Coupling 310-S039 (T90T-9550-S)

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. Remove the battery and battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-233724) .
2. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-233700-S21960513852006052600000) .
3. Disconnect the upper radiator hose.
4. Disconnect the degas return hose.
5. Using the special tool, disconnect the upper transmission cooler line.
6. Remove the two A/C condenser retaining bolts.
7. Raise and support the vehicle. For additional information, refer to «JACKING & LIFTING»(ref-233684) .
8. Remove the radiator support bracket bolts and the radiator support bracket.
9. Disconnect the lower radiator hose.
10. Disconnect the lower transmission cooler line.
11. Remove the two bolts retaining the condenser to the radiator.
12. Secure the A/C condenser.
13. Remove the bolt retaining the P/S cooler to the radiator.
14. Remove the nuts and the radiator support brackets.
15. Remove the radiator from the vehicle.
16. To install, reverse the removal procedure.
