Inspection and Verification
- Verify the customer concern.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery junction box (BJB) fuse 3 (60A) Damaged wiring harness Loose or corroded connector(s) Circuitry Smart junction box (SJB)
- If an obvious cause of an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- If the cause is not visually evident, connect the diagnostic tool to the data link connector (DLC) and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
- If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool operating manual.
- Carry out the diagnostic tool data link test. If the diagnostic tool responds with: ISO or CAN circuits fault; all electronic control units no response/not equipped, refer to «MODULE COMMUNICATIONS NETWORK»(ref-233719) . No response/not equipped for SJB, GO to «PINPOINT TEST A»(ref-233722-S41063773592006052600000) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs, and carry out self-test diagnostics for the SJB.
- If the DTCs retrieved are related to the concern, go to the «DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(ref-233722-S09894588382006052600000) .
- If no DTCs related to the concern are retrieved, refer to the appropriate article to continue diagnosis.
Diagnostic Trouble Code (DTC) Index
| DTC | Description | Source | Action |
|---|---|---|---|
| B1202 | Fuel Sender Circuit Open | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1204 | Fuel Sender Circuit Short to Ground | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1205 | EIC Switch-1 Assembly Circuit Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1208 | EIC Switch-1 Assembly Circuit Short to Ground | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1217 | Horn Relay Coil Circuit Failure | SJB | REFER to HORN . |
| B1218 | Horn Relay Coil Circuit Short to battery | SJB | REFER to HORN . |
| B1231 | Longitudinal Acceleration Threshold Exceeded | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1249 | Blend Door Failure | EATC | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1251 | Air Temperature Internal Sensor Circuit Open | EATC | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1253 | Air Temperature Internal Sensor Circuit Short to Ground | EATC | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1255 | Air Temperature External Sensor Circuit Open | Instrument Cluster | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1257 | Air Temperature External Sensor Circuit Short to Ground | Instrument Cluster | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1259 | Solar Radiation Sensor Circuit Open | EATC | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1261 | Solar Radiation Sensor Circuit Short to Ground | EATC | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| B1302 | Accessory Delay Relay Coil Circuit Failure | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1304 | Accessory Delay Relay Coil Circuit Short to Battery | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1309 | Power Door Lock Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1314 | Battery Saver Relay Coil Circuit Open | SJB | REFER to INTERIOR LIGHTING . |
| B1315 | Battery Saver Relay Coil Circuit Short to Battery | SJB | REFER to INTERIOR LIGHTING . |
| B1317 | Battery Voltage High | Instrument Cluster | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | SJB | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | RCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | SJB | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | Instrument Cluster | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | RCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1322 | Driver Door Ajar Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B1330 | Passenger Door Ajar Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B1334 | Decklid Ajar Rear Door Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B1338 | Door Ajar RR Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B1341 | Power Door Unlock Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1342 | ECU Is Defective | Instrument Cluster | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new instrument cluster. REFER to INSTRUMENT CLUSTER . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU Is Defective | RCM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new RCM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU Is Defective | ABS Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new ABS Module. REFER to ANTI-LOCK CONTROL . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU Is Defective | EATC | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new EATC Module. REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU Is Defective | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new SJB. REFER to SMART JUNCTION BOX (SJB) . CLEAR the DTCs. REPEAT the self-test. |
| B1345 | Heated Backlite Input Circuit Short to Ground | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1347 | Heated Backlite Relay Circuit Failure | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1349 | Heated Backlite Relay Short to Battery | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1352 | Ignition Key-In Circuit Failure | Instrument Cluster | REFER to STEERING COLUMN SWITCHES . |
| B1352 | Ignition Key-In Circuit Failure | SJB | REFER to STEERING COLUMN SWITCHES . |
| B1359 | Ignition Run/Ace Circuit Failure | SJB | REFER to STEERING COLUMN SWITCHES . |
| B1371 | Illuminated Entry Relay Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B1373 | Illuminated Entry Relay Short to Battery | SJB | REFER to INTERIOR LIGHTING . |
| B1398 | Driver Power Window One Touch Window Relay Circuit Failure | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1400 | Driver Power Window One Touch Window Relay Circuit Short to Battery | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1405 | Driver Power Window Down Circuit Short to Battery | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1408 | Driver Power Window Up Circuit Short to Battery | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1432 | Wiper Brake/Run Relay Circuit Short to Battery | SJB | REFER to WIPERS AND WASHERS . |
| B1434 | Wiper Hi/Low Speed Relay Coil Circuit Failure | SJB | REFER to WIPERS AND WASHERS . |
| B1436 | Wiper Hi/Low Speed Relay Coil Circuit Short to Battery | SJB | REFER to WIPERS AND WASHERS . |
| B1438 | Wiper Mode Select Switch Circuit Failure | SJB | REFER to WIPERS AND WASHERS . |
| B1441 | Wiper Mode Select Switch Circuit Short to Ground | SJB | REFER to WIPERS AND WASHERS . |
| B1446 | Wiper Park Sense Circuit Failure | SJB | REFER to WIPERS AND WASHERS . |
| B1448 | Wiper Park Sense Circuit Short to Battery | SJB | REFER to WIPERS AND WASHERS . |
| B1450 | Wiper Wash/Delay Switch Circuit Failure | SJB | REFER to WIPERS AND WASHERS . |
| B1453 | Wiper Wash/Delay Switch Circuit Short to Ground | SJB | REFER to WIPERS AND WASHERS . |
| B1458 | Wiper Washer Pump Motor Relay Circuit Failure | SJB | REFER to WIPERS AND WASHERS . |
| B1460 | Wiper Washer Pump Motor Relay Coil Circuit Short to Battery | SJB | REFER to WIPERS AND WASHERS . |
| B1465 | Wiper Brake/Run Relay Circuit Open | SJB | REFER to WIPERS AND WASHERS . |
| B1466 | Wiper Hi/Low Speed Not Switching | SJB | REFER to WIPERS AND WASHERS . |
| B1472 | Lamp Headlamp Input Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1484 | Brake Pedal Input Open Circuit | ABS Module | REFER to ANTI-LOCK CONTROL . |
| B1522 | Hood Switch Circuit Short to Ground | SJB | REFER to ANTI-THEFT - PERIMETER . |
| B1526 | Keyless Entry Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1551 | Decklid Release Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1553 | Decklid Release Circuit Short to Battery | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1554 | Decklid Release Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1555 | Ignition Run/Start Circuit Failure | SJB | REFER to STEERING COLUMN SWITCHES . |
| B1574 | Door Ajar LR Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B1577 | Lamp Park Input Circuit Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B1623 | Lamp Keypad Output Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1676 | Battery Voltage Out of Range | EATC | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1676 | Battery Voltage Out of Range | ABS Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1688 | Lamp Dome Input Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B1696 | Autolamp On Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1790 | Autolamp Sensor Input Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B1833 | Door Unlock Disarm Switch Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1869 | Lamp Air Bag Warning Indicator Circuit Open | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1870 | Lamp Air Bag Warning Indicator Circuit Short To Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1884 | PAD Warning Lamp Circuit Failure | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1890 | PAD Warning Lamp Circuit Short To Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1891 | Air Bag Tone Warning Indicator Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1892 | Air Bag Tone Warning Indicator Circuit Failure | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1921 | Air Bag Diagnostic Monitor Ground Circuit Open | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1982 | Driver Door Unlock Relay Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1983 | Driver Door Unlock Relay Circuit Short to Battery | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2097 | Compass Module Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B2143 | Odometer NVM Checksum Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B2183 | Wiper Mode Select Switch Circuit H Short to Ground | SJB | REFER to WIPERS AND WASHERS . |
| B2249 | Headlamp Relay Coil Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B2250 | All Doors Unlock Relay Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2251 | Parklamp Output Relay Driver Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2252 | Parklamp Output Relay Driver Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B2290 | Occupant Classification System Fault Front Passenger Side | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2291 | Occupant Position Systems Status, Front Passenger Side | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2292 | Restraint System Seatbelt Pretensioner Status | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2293 | Restraint System Airbag Status | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2294 | Restraint System Curtain Status | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2295 | Restraint System Side Airbag Status | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2296 | Restraint System Impact Sensor Status | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2425 | Remote Keyless Entry Out of Synchronization | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2434 | Drivers Seat Belt Buckle Switch Circuit Short To Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2435 | Drivers Seat Belt Buckle Switch Resistance Out Of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2438 | Passengers Seat Belt Buckle Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2439 | Passengers Seat Belt Buckle Switch Resistance Out Of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2477 | Module Configuration Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B2477 | Module Configuration Failure | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2598 | Headlamp Relay Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2691 | Front Drivers Seat Belt Buckle Switch Circuit Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2692 | Front Passengers Seat Belt Buckle Switch Circuit Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2909 | Belt Tension Sensor Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1093 | Traction Control Disable Switch Circuit Failure | Instrument Cluster | REFER to ANTI-LOCK CONTROL . |
| C1145 | Speed Wheel Sensor RF Input Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1155 | Speed Wheel Sensor LF Input Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1165 | Speed Wheel Sensor RR Input Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1167 | Park Brake Actuator Assembly Switch Released Circuit Short to Ground | SJB | REFER to ANTI-LOCK CONTROL . |
| C1175 | Speed Wheel Sensor LR Input Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1189 | Brake Fluid Level Sensor Input Short Circuit to Ground | SJB | REFER to ANTI-LOCK CONTROL . |
| C1222 | Speed Wheel Mismatch | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1266 | ABS Valve Power Relay Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1284 | Oil Pressure Switch Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| C1296 | Wheel Speed LF Signal Fault | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1297 | Wheel Speed RF Signal Fault | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1298 | Wheel Speed RR Signal Fault | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1299 | Wheel Speed LR Signal Fault | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1300 | ABS Module Pump Motor Circuit Failure | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1805 | Mismatched PCM and/or ABS/TC Module | ABS Module | REFER to ANTI-LOCK CONTROL . |
| C1947 | Driver Seat Track Position Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1948 | Driver Seat Track Position Switch Circuit Resistance Out Of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1981 | Front Drivers Seat Track Position Switch Circuit Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| P0705 | Digital TR sensor. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0708 | Digital TR sensor. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0712 | 171°C (340°F) indicated TFT sensor circuit grounded. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0713 | 43°C (-45°F) indicated TFT sensor circuit open. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0715 | Insufficient input from Turbine Shaft Speed (TSS) Sensor. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0717 | Insufficient input from Turbine Shaft Speed (TSS) sensor. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0718 | TSS signal intermittent. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0720 | Insufficient input from OSS sensor. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0721 | Output shaft speed sensor signal noisy. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0722 | Output shaft speed sensor signal intermittent. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0731 | SSA, SSB, or internal parts | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0732 | 2nd gear failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0733 | SSA, SSC, or internal parts | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0734 | SSA, SSC, or internal parts | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0741 | Converter Clutch Error. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0743 | TCC solenoid circuit failure during on-board diagnostic. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0750 | SSA solenoid circuit failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0753 | SSA solenoid circuit failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0755 | SSB solenoid circuit failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0756 | Shift Solenoid B functional failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0758 | SSB solenoid circuit failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0760 | SSC solenoid circuit failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0761 | Shift solenoid C functional failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P0763 | SSC solenoid circuit failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1112 | IAT sensor or circuit signal intermittent. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1117 | ECT sensor or circuit signal intermittent. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1700 | LOW OWC | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1702 | Digital TR sensor. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1704 | Digital TR sensor. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1705 | Digital TR sensor. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1711 | TFT out of on-board diagnostic range. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1713 | No change in TFT - low range. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1714 | SSA failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1715 | SSB failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1716 | SSB failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1718 | No change in TFT - high range. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1740 | TCC failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1741 | Continuous slip ERROR. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1742 | TCC Solenoid Failed ON. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1743 | TCC Solenoid Failed ON. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1744 | Excessive slip detected. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1746 | EPC | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1747 | EPC solenoid circuit failure, shorted circuit or output driver. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1751 | Shift solenoid A functional failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1756 | Shift solenoid B functional failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1760 | EPC solenoid circuit failure, shorted circuit or output driver. | PCM | Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1761 | Shift solenoid C functional failure. | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1779 | Check Transaxle Lamp | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1783 | Transaxle overtemp condition indicated (300°F). | PCM | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N . |
| P1882 | Engine Coolant Level Switch Circuit Short to Ground | SJB | REFER to ENGINE COOLING . |
| U0002 | High Speed CAN Communication Bus Performance | Instrument Cluster | Bus timeout occured. INSPECT high speed CAN wiring and instrument cluster connections. REFER to MODULE COMMUNICATIONS NETWORK . |
| U0020 | Low Speed CAN Communication Bus Performance | Instrument Cluster | Bus timeout occured. INSPECT CAN wiring and instrument cluster connections. REFER to MODULE COMMUNICATIONS NETWORK . |
| U0073 | Control Module Communication Bus Off | EATC | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0073 | Control Module Communication Bus Off | ABS Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1900 | CAN Communication Bus Fault - Receive Error | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1900 | CAN Communication Bus Fault - Receive Error | ABS Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1900 | CAN Communication Bus Fault - Receive Error | SJB | REFER to MODULE COMMUNICATIONS NETWORK . |
| U1901 | CAN Network #2 Communication Bus Fault -Receive Error | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U2006 | Audio Remote Climate Control Unit is Not Responding | EATC | REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION . |
| U2013 | Compass Module Not Responding | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| U2023 | Fault Received From External Node | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U2023 | Fault Received From External Node | ABS Module | REFER to MODULE COMMUNICATIONS NETWORK . |
DIAGNOSTIC TROUBLE CODE (DTC) INDEX
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the smart junction box (SJB) | Battery junction box (BJB) fuse 3 (60A) Circuitry SJB | GO to PINPOINT TEST A . |
SYMPTOM CHART
Scheme 22
Scheme 23
- A1 CHECK THE SJB POWER CIRCUIT FOR AN OPEN Key in OFF position. Disconnect: SJB C2280a. Key in ON position. Measure the voltage between the SJB C2280a pin 12, circuit 1001 (WH/YE), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to A2 . No : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
- A2 CHECK THE SJB GROUND CIRCUIT FOR AN OPEN Key in OFF position. Connect: SJB C2280a. Disconnect: SJB C2280c. Measure the resistance between the SJB C2280c pin 18, circuit 57 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : REFER to «MODULE COMMUNICATIONS NETWORK»(ref-233719) to continue communication diagnosis. No : REPAIR the circuit. CLEAR the DTCs. REPEAT the test.
Scheme 24
Scheme 25
Scheme 26
- Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-233724) .
- Disconnect the bulkhead connectors from the smart junction box (SJB).
- Disconnect the connectors from the bottom of the SJB.
- Remove the SJB. Remove the retaining nuts. Unclip and remove the SJB.
- To install, reverse the removal procedure.
