GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Generator | 2F1U-CC (3.0L 2V) 2F1U-BB (3.0L 4V) |
| Rating (6,000 gen. RPM) | 110 amp max. (3.0L 2V) 120 amp max. (3.0L 4V) |
| Generator pulley ratio | 2.58:1 (3.0L 2V) 2.06:1 (3.0L 4V) |
| Voltage regulator type | Electronic internal with generator |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Crankshaft pulley bolt | 100 |
| Degas bottle bolt/nut | 10 |
| Generator mounting bolts (4V) | 25 |
| Generator mounting bolt (2V upper) | 48 |
| Generator mounting bolt (2V lower) | 25 |
| Generator brace nut | 25 |
| Generator B+ nut | 8 |
| Power steering hose bracket nut | 18 |
| Power steering reservoir nuts | 4 |
| Power steering reservoir bolt | 11 |
| Power steering pump bolts | 25 |
| Wiring harness locator-to reservoir nut | 5 |
TORQUE SPECIFICATIONS
The generator (10300) on this vehicle has an internally mounted voltage regulator. The voltage regulator and generator are not repairable at the dealership level and must be replaced as a unit.
Refer to CHARGING SYSTEM - GENERAL INFORMATION .
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-233724) .
- Release the accessory drive belt tension and remove the belt from the generator pulley.
- Remove the bolt, the nut and position the degas bottle aside.
- Remove the generator electrical connectors. Remove B+ nut. Remove the stator and voltage regulator connectors.
- Remove the generator brace. Remove the bolt and nut.
- Remove the generator mounting bolt and remove the generator.
- To install, reverse removal procedure.
